Motorola APX 3000

Schematics, Boards Overlays, and Parts Lists: Main Board Block: UHF1 (84012513001_A) 8-43
C6529M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C6530M6 2113946S35 CAP,CHIP,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6531M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C6532M6 2113946S35 CAP,CHIP,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6533M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C6534M6 2113956B33 CAP,FXD,2.2UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG CMAX
C6535M6 2113944A34 CAP,CHIP,56PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6536M6 2113944A28 CAP,CHIP,18PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6537M6 2113944A19 CAP,CHIP,5.6PF,.5PF+/-
,50V-DC,0402,C0G,-55DEG
CMIN,125DEG CMAX
C6538M6 2113956B33 CAP,FXD,2.2UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG CMAX
C6539M6 2113956B33 CAP,FXD,2.2UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG CMAX
C6540M6 2113945C13 CAP,CHIP,1000PF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG CM
C6541M6 2113944A19 CAP,CHIP,5.6PF,.5PF+/-
,50V-DC,0402,C0G,-55DEG
CMIN,125DEG CMAX
C6542M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
Ref. Des. Part Number Description
C6543M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C6544M6 2113945D04 CAP,CHIP,.1UF,+10%,-
10%,25V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C6545M6 2113945D04 CAP,CHIP,.1UF,+10%,-
10%,25V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C6546M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C6547M6 2113944A46 CAP,CHIP,330PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C6548M6 NOT
PLACED
CAP,CHIP,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6549M6 2113944A46 CAP,CHIP,330PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C6550M6 2113945D04 CAP,CHIP,.1UF,+10%,-
10%,25V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C6551M6 2113944A46 CAP,CHIP,330PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C6552M6 2113956E91 CAP,FXD,10UF,+10%,-
10%,16V-DC,1210,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6553M6 2113956E91 CAP,FXD,10UF,+10%,-
10%,16V-DC,1210,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6554M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
Ref. Des. Part Number Description
C6555M6 2113955D45 CAP,FXD,4.7UF,+10%,-
10%,10V-DC,1206,X7R,-
55DEG CMIN,125DEG
CMAX
C6556M6 2113956B33 CAP,FXD,2.2UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG CMAX
C6557M6 2113945D04 CAP,CHIP,.1UF,+10%,-
10%,25V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C6558M6 2113944A21 CAP,CHIP,6.8PF,.5PF+/-
,50V-DC,0402,C0G,-55DEG
CMIN,125DEG CMAX
C6559M6 2113946S35 CAP,CHIP,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6560M6 2113956C37 CAP,FXD,10UF,+10%,-
10%,16V-DC,0805,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6561M6 2113956C37 CAP,FXD,10UF,+10%,-
10%,16V-DC,0805,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6562M6 2113944A25 CAP,CHIP,10PF,.5PF+/-,50V-
DC,0402,C0G,-55DEG
CMIN,125DEG CMAX
C6563M6 2113945D04 CAP,CHIP,.1UF,+10%,-
10%,25V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C6564M6 2113944A46 CAP,CHIP,330PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C6565M6 2113956B33 CAP,FXD,2.2UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG CMAX
C6566M6 2113956E91 CAP,FXD,10UF,+10%,-
10%,16V-DC,1210,X5R,-
55DEG CMIN,85DEG
CMAX,P
Ref. Des. Part Number Description
C6567M6 2113956E91 CAP,FXD,10UF,+10%,-
10%,16V-DC,1210,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6568M6 2113956B33 CAP,FXD,2.2UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG CMAX
C6569M6 2113956E91 CAP,FXD,10UF,+10%,-
10%,16V-DC,1210,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6570M6 2113944A46 CAP,CHIP,330PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C6571M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C6572M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C6573M6 2113946S35 CAP,CHIP,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6574M6 2113946S35 CAP,CHIP,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6575M6 2113946S35 CAP,CHIP,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6576M6 2113956B33 CAP,FXD,2.2UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG CMAX
C6577M6 2113946S35 CAP,CHIP,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6578M6 2113946S35 CAP,CHIP,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,P
Ref. Des. Part Number Description
