8-44 Schematics, Boards Overlays, and Parts Lists: Main Board Block: UHF1 (84012513001_A)
C6579M6 2113946S35 CAP,CHIP,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6580M6 2113946S35 CAP,CHIP,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6581M6 2113956B33 CAP,FXD,2.2UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG CMAX
C6582M6 2113944A21 CAP,CHIP,6.8PF,.5PF+/-
,50V-DC,0402,C0G,-55DEG
CMIN,125DEG CMAX
C6583M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C6584M6 2113956C37 CAP,FXD,10UF,+10%,-
10%,16V-DC,0805,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6585M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C6586M6 2113956C35 CAP,FXD,4.7UF,+10%,-
10%,16V-DC,0805,X5R,-
55DEG CMIN,85DEG CMAX
C6587M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C6588M6 2113944A46 CAP,CHIP,330PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C6589M6 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C6590M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C6591M6 2113944A28 CAP,CHIP,18PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
Ref. Des. Part Number Description
C6592M6 2113944A09 CAP,CHIP,2.2PF,.25PF+/-
,50V-DC,0402,C0G,-55DEG
CMIN,125DEG CMA
C6593M6 2113956C37 CAP,FXD,10UF,+10%,-
10%,16V-DC,0805,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6594M6 2113946C07 CAP,FXD,.33UF,+10%,-
10%,10V-DC,0603,X5R,-
55DEG CMIN,85DEG CMAX
C6595M6 2113946S35 CAP,CHIP,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6596M6 NOT
PLACED
CAP,CHIP,22PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6601M6 2113944A28 CAP,CHIP,18PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6602M6 2113944A28 CAP,CHIP,18PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6670M6 NOT
PLACED
CAP,FXD,13PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C701M7 2115153H18 CAP,CER CHIP,4.3PF,.1PF+/
-,+.1%,-.1%,50V-
DC,0402,C0G,CAP, CERA
C702M7 2185419D06 CAP,CHIP,.1UF,+10%,-
10%,25V-DC,1206,-55DEG
CMIN,125DEG CMAX
C703M7 2113945C26 CAP,FXD,.039UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG CMA
C704M7 2185419D06 CAP,CHIP,.1UF,+10%,-
10%,25V-DC,1206,-55DEG
CMIN,125DEG CMAX
C705M7 2115153H34 CAP,CER CHIP,11PF,+1%,-
1%,50V-DC,0402,C0G,CAP,
CERAMIC, COG
Ref. Des. Part Number Description
C706M7 2185419D06 CAP,CHIP,.1UF,+10%,-
10%,25V-DC,1206,-55DEG
CMIN,125DEG CMAX
C707M7 2113945C01 CAP,CHIP,6800PF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG CM
C708M7 2115153H34 CAP,CER CHIP,11PF,+1%,-
1%,50V-DC,0402,C0G,CAP,
CERAMIC, COG
C709M7 2171051Y11 CAP,FXD,.1UF,+5%,-
5%,1206,-55DEG
CMIN,125DEG CMAX,PB-
FREE
C710M7 NOT
PLACED
CAP,CHIP,560PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C711M7 NOT
PLACED
CAP,CHIP,56PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C712M7 NOT
PLACED
CAP,CHIP,270PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C713M7 2113945C26 CAP,FXD,.039UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG CMA
C714M7 2171051Y11 CAP,FXD,.1UF,+5%,-
5%,1206,-55DEG
CMIN,125DEG CMAX,PB-
FREE
C715M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C716M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C717M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
Ref. Des. Part Number Description
C718M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C719M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C720M7 2113944C53 CAP,CHIP,1500PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX
C721M7 NOT
PLACED
CAP,FXD,.22UF,+10%,-
10%,50V-DC,0805,X7R,-
55DEG CMIN,125DEG
CMAX
C722M7 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C723M7 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C724M7 2113955D37 CAP,FXD,10UF,+10%,-
10%,16V-DC,1206,X7R,-
55DEG CMIN,125DEG
CMAX
C725M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C726M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C727M7 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C728M7 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C729M7 2115153H27 CAP,FXD,10PF,.1PF+/-
,+1%,-1%,50V-
DC,0402,C0G,CAP,
CERAMIC, COG
Ref. Des. Part Number Description
