Motorola APX 3000

8-46 Schematics, Boards Overlays, and Parts Lists: Main Board Block: UHF1 (84012513001_A)
D2601M13 4813974A19 DIODE
ARRAY,MXR,SM,SOT-
323,7V,.2W,SHTK,2,PB-
FREE
D2602M13 4815897H01 DIODE,PIN,UPP9401E,SM,D
O-
216,50A,50V,2.5W,POWERM
ITE
D2603M13 4815897H01 DIODE,PIN,UPP9401E,SM,D
O-
216,50A,50V,2.5W,POWERM
ITE
D2M2 4870359B01 DIODE,SUPR,SM,7.82V,.1W,
ESD PROT,V360
D3102M22 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/SC-
79,SOD-523/SC-79
D3103M22 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/SC-
79,SOD-523/SC-79
D3104M22 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/SC-
79,SOD-523/SC-79
D3105M22 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/SC-
79,SOD-523/SC-79
D3135M22 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/SC-
79,SOD-523/SC-79
D3136M22 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/SC-
79,SOD-523/SC-79
D3137M22 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/SC-
79,SOD-523/SC-79
D3138M22 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/SC-
79,SOD-523/SC-79
D3M2 4870359B01 DIODE,SUPR,SM,7.82V,.1W,
ESD PROT,V360
D4001M2 4813978A25 DIODE,SWG,BAT54,SM,SO
D-323/SC-
76,200MA,30V,.2W,SHTK,PB
-FREE, W18
Ref. Des. Part Number Description
D6101M6 4813978A25 DIODE,SWG,BAT54,SM,SO
D-323/SC-
76,200MA,30V,.2W,SHTK,PB
-FREE, W18
D6401M6 4813978A25 DIODE,SWG,BAT54,SM,SO
D-323/SC-
76,200MA,30V,.2W,SHTK,PB
-FREE, W18
D6501M6 4813978A25 DIODE,SWG,BAT54,SM,SO
D-323/SC-
76,200MA,30V,.2W,SHTK,PB
-FREE, W18
D722M7 4815011H01 DIODE,SWG,SM,300MA,80V,
TRP
D723M7 4815011H01 DIODE,SWG,SM,300MA,80V,
TRP
E1101M11 2405688Z01 IDCTR,BEAD,FERR BEAD
E1921M20 2471132D14 IDCTR,25%,200MA,.6OHM,F
ERR,SM,0402,IDCTR,FXD,4
70OHM,200M
E201M12 7686949J14 FLTR,FERRITE
BEAD,2A,SM,0805,CHIP,220
OHM
E2201M2 76852680E0
1
FLTR,FERRITE
BEAD,650MA,SM,0402,CHIP
,80OHM
E2206M2 76852680E0
1
FLTR,FERRITE
BEAD,650MA,SM,0402,CHIP
,80OHM
E2207M2 76852680E0
1
FLTR,FERRITE
BEAD,650MA,SM,0402,CHIP
,80OHM
E2247M2 76852680E0
1
FLTR,FERRITE
BEAD,650MA,SM,0402,CHIP
,80OHM
E2248M2 76852680E0
1
FLTR,FERRITE
BEAD,650MA,SM,0402,CHIP
,80OHM
E2249M2 76852680E0
1
FLTR,FERRITE
BEAD,650MA,SM,0402,CHIP
,80OHM
E601M19 2471132D14 IDCTR,25%,200MA,.6OHM,F
ERR,SM,0402,IDCTR,FXD,4
70OHM,200M
Ref. Des. Part Number Description
E602M19 2471132D14 IDCTR,25%,200MA,.6OHM,F
ERR,SM,0402,IDCTR,FXD,4
70OHM,200M
E603M19 2471132D14 IDCTR,25%,200MA,.6OHM,F
ERR,SM,0402,IDCTR,FXD,4
70OHM,200M
E604M19 2471132D14 IDCTR,25%,200MA,.6OHM,F
ERR,SM,0402,IDCTR,FXD,4
70OHM,200M
E605M19 2471132D14 IDCTR,25%,200MA,.6OHM,F
ERR,SM,0402,IDCTR,FXD,4
70OHM,200M
E606M19 2471132D14 IDCTR,25%,200MA,.6OHM,F
ERR,SM,0402,IDCTR,FXD,4
70OHM,200M
E607M19 2471132D14 IDCTR,25%,200MA,.6OHM,F
ERR,SM,0402,IDCTR,FXD,4
70OHM,200M
E608M19 2471132D14 IDCTR,25%,200MA,.6OHM,F
ERR,SM,0402,IDCTR,FXD,4
70OHM,200M
E609M19 2471132D14 IDCTR,25%,200MA,.6OHM,F
ERR,SM,0402,IDCTR,FXD,4
70OHM,200M
E6501M6 2480067M02 FIXED
INDUCTOR,FXD,200MA,.4O
HM,FERR,0805,CHK RF
CHIP BE
E6502M6 2480067M02 FIXED
INDUCTOR,FXD,200MA,.4O
HM,FERR,0805,CHK RF
CHIP BE
F200M12 6575834B01 FUSE,FST
BLW,2A,32V,FUSE SUR MT
FL1301M3 9102190J23 FLTR,SAW,BANDPASS,1.57
542GHZ
NOM,SM,1.4X1.0MM,SMD,P
B-FREE
FL1302M3 9109674L58 BAND PASS FILTER
FL1303M3 9102190J23 FLTR,SAW,BANDPASS,1.57
542GHZ
NOM,SM,1.4X1.0MM,SMD,P
B-FREE
Ref. Des. Part Number Description
FL502M21 91009300001 FLTR,BANDPASS,109.65MH
Z
NOM,FILTER,MONOLITHIC
CRYSTAL,BAND
J102M11 2880658Z08 RF
CONNECTOR,SMA,M,CONN
SMA
J1301M3 40012057001 RF SWITCH,SWITCH,RF
J1M2 9012130001 CONN,RCPT,24CONT,.4MM,
CONNECTOR, BTB
RECEPTACLE, 24-PIN,
J2401M2 0989851N01 CONN,BTB,2
ROW,RCPT,40CONT,.4MM,
GLD,SMD
J2M2 0971704L01 CONN,CUST,RCPT,12CONT,
CONNECTOR, 12-PIN
SOCKET, 0.4MM PIT
J3M2 9012073001 CONN,BTB,RCPT,34CONT,.
4MM,GLD,ST,CONNECTOR,
B2B RCPT 34PINS
L1101M11 2415429H26 IDCTR,WW,33NH,5%,600MA
,.22OHM,CER,SM,0603,CHI
P
L1102M11 2415429H10 IDCTR,WW,6.8NH,5%,700M
A,.11OHM,CER,SM,0603,CH
IP
L1117M11 2415428H01 COIL,AW,1.65NH,10%,1.6A,
AIR,2 TURNS,SM,AIR
WOUND IDCTR
L1301M3 2414017P16 IDCTR,CHIP,18NH,5%,300M
A,.76OHM,CER,9 Q,1.9GHZ
SRF,SM,0402,P
L1302M3 2475122C13 IDCTR,3.3NH,9.09%,300MA,
.17OHM,CER,4
TURNS,SM,IND, MULTI-LA
L1303M3 2414017P16 IDCTR,CHIP,18NH,5%,300M
A,.76OHM,CER,9 Q,1.9GHZ
SRF,SM,0402,P
L1304M3 2475122C37 IDCTR,100NH,5%,300MA,.0
7OHM,CER,4
TURNS,SM,IND, MULTI-LAY
L1305M3 24012011010 IDCTR,WW,4.7NH,2%,1.5A,.
06OHM,CER,6.85GHZ
SRF,SM,0402 HI Q
Ref. Des. Part Number Description
