Motorola APX 3000

Schematics, Boards Overlays, and Parts Lists: Main Board Block: UHF1 (84012513001_A) 8-47
L1306M3 2414017P14 IDCTR,CHIP,12NH,5%,300M
A,.6OHM,CER,9 Q,2GHZ
SRF,SM,0402,PB-F
L1308M3 NOT
PLACED
IDCTR,WW,39NH,5%,600MA
,CER,SM,CHIP
L1316M3 24012011018 IDCTR,WW,9NH,2%,1.4A,.07
OHM,CER,5GHZ
SRF,SM,0402 HI Q CHIP
L1601M16 24009331029 IDCTR,WW,15NH,5%,600MA
,SM,IDCTR,WW,15NH,5%,60
0MA,SM,060
L1602M16 2415429H37 IDCTR,WW,110NH,5%,300M
A,.61OHM,CER,SM,0603,CH
IP
L1603M16 2414015B14 IDCTR,FXD,110NH,2%,400M
A,.46OHM,CER,40
Q,900MHZ SRF,SM,0805
L1604M16 24009331005 IDCTR,WW,3.9NH,INDUCTO
R, 3.9NH, +/-0.5NH, 0603
L1605M16 24009331005 IDCTR,WW,3.9NH,INDUCTO
R, 3.9NH, +/-0.5NH, 0603
L1606M16 2460591E24 COIL AIR WOUND INDUC
23.75
L1609M16 2415428H02 IDCTR,AW,2.55NH,5%,1.6A,
AIR,3 TURNS,SM,AIR
WOUND IDCTR
L1610M16 2471968L10 IDCTR,AW,9NH,2%,4A,.0034
OHM,AIR,5 TURNS,120
Q,4GHZ SRF,SM,9.
L1803M17 24012026006 IDCTR,AW,13.7NH,2%,2.7A,
AIR,SM,ULTRA-MINIATURE
AIR CORE
L1809M17 24012026006 IDCTR,AW,13.7NH,2%,2.7A,
AIR,SM,ULTRA-MINIATURE
AIR CORE
L1811M17 24012026006 IDCTR,AW,13.7NH,2%,2.7A,
AIR,SM,ULTRA-MINIATURE
AIR CORE
L1900M20 NOT
PLACED
IDCTR,WW,10NH,2%,1.3A,.0
85OHM,CER,4.7GHZ
SRF,SM,0402 HI Q C
L1901M20 24009331005 IDCTR,WW,3.9NH,INDUCTO
R, 3.9NH, +/-0.5NH, 0603
Ref. Des. Part Number Description
L1908M20 2478057A04 IDCTR,3.6NH,2%,.031OHM,
CER,40 Q,9.7GHZ
SRF,PCMT,3.6 NH SU
L1909M20 2478057A23 IDCTR,18NH,2%,.066OHM,C
ER,41 Q,3.3GHZ
SRF,PCMT,18 NH SUR
L1910M20 2478057A23 IDCTR,18NH,2%,.066OHM,C
ER,41 Q,3.3GHZ
SRF,PCMT,18 NH SUR
L1912M20 2478057A04 IDCTR,3.6NH,2%,.031OHM,
CER,40 Q,9.7GHZ
SRF,PCMT,3.6 NH SU
L1913M20 2478057A23 IDCTR,18NH,2%,.066OHM,C
ER,41 Q,3.3GHZ
SRF,PCMT,18 NH SUR
L1914M20 2478057A23 IDCTR,18NH,2%,.066OHM,C
ER,41 Q,3.3GHZ
SRF,PCMT,18 NH SUR
L1915M20 2478057A12 IDCTR,7.2NH,2%,.052OHM,
CER,48 Q,5.4GHZ
SRF,PCMT,7.2NH SUR
L1917M20 2478057A04 IDCTR,3.6NH,2%,.031OHM,
CER,40 Q,9.7GHZ
SRF,PCMT,3.6 NH SU
L1934M20 2478057A35 CHIP
INDUCTOR,RF,47NH,2%,SM
,0603 HI Q CHIP IDCTR
L1935M20 2478057A23 IDCTR,18NH,2%,.066OHM,C
ER,41 Q,3.3GHZ
SRF,PCMT,18 NH SUR
L1936M20 2475994M09 IDCTR,CHIP,2.2NH,5%,2.1A,
.18OHM,CER,13 Q,15GHZ
SRF,PCMT,2.2
L200M12 2571269C01 IDCTR,COIL,1.5UH,20%,2.9
A,.059OHM,FERR,SM,WW
PWR W18 COMP
L2601M13 2471912M03 IDCTR,COIL,18.9NH,5%,2.6
A,.015OHM,AIR,40
Q,2.8GHZ SRF,SQ A
L2602M13 2415429H40 IDCTR,WW,180NH,5%,240M
A,1.25OHM,CER,SM,0603,C
HIP
L3100M22 0613952R66 RES,MF,0OHM,5%,.0625W,S
M,0402,PB-FREE
Ref. Des. Part Number Description
L3101M22 2414032F41 IDCTR,WW,390NH,10%,200
MA,1.5OHM,CER,40
Q,730MHZ SRF,SM,PB-F
L3102M22 0613952R66 RES,MF,0OHM,5%,.0625W,S
M,0402,PB-FREE
L3106M22 2478057A21 IDCTR,15NH,2%,.078OHM,C
ER,48 Q,3.6GHZ
SRF,PCMT,15 NH SUR
L3112M22 2415428H04 IDCTR,AW,5.4NH,2%,1.6A,A
IR,SM,AIR WOUND IDCTR
L3119M22 2414032F73 IDCTR,WW,820NH,5%,180M
A,2.23OHM,CER,23
Q,215MHZ SRF,SM,PB-F
L3125M22 2414032F41 IDCTR,WW,390NH,10%,200
MA,1.5OHM,CER,40
Q,730MHZ SRF,SM,PB-F
L3126M22 2414032F73 IDCTR,WW,820NH,5%,180M
A,2.23OHM,CER,23
Q,215MHZ SRF,SM,PB-F
L3134M22 2414032F41 IDCTR,WW,390NH,10%,200
MA,1.5OHM,CER,40
Q,730MHZ SRF,SM,PB-F
L3139M22 2478057A21 IDCTR,15NH,2%,.078OHM,C
ER,48 Q,3.6GHZ
SRF,PCMT,15 NH SUR
L3145M22 2471968L11 IDCTR,AW,13NH,2%,4A,.003
9OHM,AIR,5 TURNS,100
Q,3GHZ SRF,SM,1
L3150M22 2414032F41 IDCTR,WW,390NH,10%,200
MA,1.5OHM,CER,40
Q,730MHZ SRF,SM,PB-F
L3158M22 2414032F41 IDCTR,WW,390NH,10%,200
MA,1.5OHM,CER,40
Q,730MHZ SRF,SM,PB-F
L3159M22 2414032F39 IDCTR,WW,270NH,10%,280
MA,1OHM,CER,40
Q,800MHZ SRF,SM,PB-FRE
L500M21 2415429H43 IDCTR,WW,220NH,5%,300M
A,2.1OHM,CER,SM,0603,CH
IP
L501M21 NOT
PLACED
IDCTR,WW,18NH,2%,900MA
,.12OHM,CER,3.55GHZ
SRF,SM,0402 HI Q
Ref. Des. Part Number Description
L503M21 2414017N24 IDCTR,CHIP,100NH,5%,300
MA,2OHM,CER,15
Q,700MHZ SRF,SM,0603,P
L504M21 2478057A51 CHIP
INDUCTOR,RF,270NH,2%,S
M,0603 HI Q CHIP IDCTR
L513M21 NOT
PLACED
IDCTR,WW,22NH,5%,700MA
,.19OHM,CER,SM,0603,CHI
P
L550M21 24009331029 IDCTR,WW,15NH,5%,600MA
,SM,IDCTR,WW,15NH,5%,60
0MA,SM,060
L601M19 2415429H43 IDCTR,WW,220NH,5%,300M
A,2.1OHM,CER,SM,0603,CH
IP
L602M19 2466505A01 CHIP
INDUCTOR,CHIP,10UH,5%,1
50MA,FERR,0 AWG,SM,PB-
FREE
L603M19 2466505A01 CHIP
INDUCTOR,CHIP,10UH,5%,1
50MA,FERR,0 AWG,SM,PB-
FREE
L604M19 2414032D16 IDCTR,WW,120NH,5%,800M
A,.26OHM,CER,42 Q,1GHZ
SRF,SM,PB-FREE
L605M19 2414017Q54 IDCTR,FXD,3.9UH,10%,30M
A,.9OHM,FERR,45 Q,38MHZ
SRF,SM,0805,P
L611M19 2414032F39 IDCTR,WW,270NH,10%,280
MA,1OHM,CER,40
Q,800MHZ SRF,SM,PB-FRE
L6502M6 2471678H01 IDCTR,10UH,20%,FERR,10
UH INDCUTOR
L6504M6 24009268001 IDCTR,PWR,10UH,20%,1.3A
,FERR,SM,10UH 2.1A SHLD
IDCTR
L6505M6 2471678H01 IDCTR,10UH,20%,FERR,10
UH INDCUTOR
L701M7 2415429H47 IDCTR,WW,390NH,5%,100M
A,CER,SM,CHIP
L702M7 2415429H47 IDCTR,WW,390NH,5%,100M
A,CER,SM,CHIP
Ref. Des. Part Number Description
