Motorola APX 3000

8-48 Schematics, Boards Overlays, and Parts Lists: Main Board Block: UHF1 (84012513001_A)
L703M7 2475122C28 IDCTR,18NH,5%,300MA,.36
OHM,CER,4
TURNS,SM,IND, MULTI-
LAYE
L709M7 2475122C26 IDCTR,12UH,5%,300MA,.07
OHM,CER,4
TURNS,SM,IND, MULTI-
LAYE
L720M7 24012100001 IDCTR,FXD,2.2UH,10%,15M
A,35 Q,50MHZ
SRF,SM,IDCTR,2.2UH,1
L727M7 24012100001 IDCTR,FXD,2.2UH,10%,15M
A,35 Q,50MHZ
SRF,SM,IDCTR,2.2UH,1
L728M7 2415429H47 IDCTR,WW,390NH,5%,100M
A,CER,SM,CHIP
L730M7 2475122C25 IDCTR,10NH,5%,300MA,.26
OHM,CER,4
TURNS,SM,IND, MULTI-
LAYE
L733M7 24012100001 IDCTR,FXD,2.2UH,10%,15M
A,35 Q,50MHZ
SRF,SM,IDCTR,2.2UH,1
L735M7 24012100001 IDCTR,FXD,2.2UH,10%,15M
A,35 Q,50MHZ
SRF,SM,IDCTR,2.2UH,1
L738M7 24012100001 IDCTR,FXD,2.2UH,10%,15M
A,35 Q,50MHZ
SRF,SM,IDCTR,2.2UH,1
L739M7 2415429H47 IDCTR,WW,390NH,5%,100M
A,CER,SM,CHIP
L741M7 24012100001 IDCTR,FXD,2.2UH,10%,15M
A,35 Q,50MHZ
SRF,SM,IDCTR,2.2UH,1
L753M7 2415347H06 IDCTR,WW,2.2UH,5%,320M
A,1.2OHM,CER,SM,IDCTR,
2200NH
L755M7 2415429H47 IDCTR,WW,390NH,5%,100M
A,CER,SM,CHIP
L758M7 2415429H47 IDCTR,WW,390NH,5%,100M
A,CER,SM,CHIP
L759M7 2415429H47 IDCTR,WW,390NH,5%,100M
A,CER,SM,CHIP
L765M7 2415427H28 IDCTR,WW,18NH,5%,420MA
,CER,SM,0402,CHIP
Ref. Des. Part Number Description
L775M7 2415429H47 IDCTR,WW,390NH,5%,100M
A,CER,SM,CHIP
M1 1171905B02 ADHES,WHT,WHT I SHAPE
UNDERFILM COR
M101M12 39012039001 CONN,CMPRSN,3CONT,ST,
CONNECTOR, BAT
CONTACT, WWP
M1301M3 3987977Y04 CONT,CONN,1CONT,ANT
UNIV 4.5MM,UC 1.8
M1302M3 3987977Y04 CONT,CONN,1CONT,ANT
UNIV 4.5MM,UC 1.8
M2 1171905B02 ADHES,WHT,WHT I SHAPE
UNDERFILM COR
M2533M6 3987977Y04 CONT,CONN,1CONT,ANT
UNIV 4.5MM,UC 1.8
M6502M6 0985888K02 BATTERY
CONNECTOR,SKT,NI,LEAP
Q1101M11 4813973A32 XSTR,BIP GP
SS,NPN,SM,SC-
70,SMT,50V,.202W,100MA,P
B-FREE
Q1103M11 4813970A59 XSTR,FET GP PWR,P-
CH,ENHN,SM,SOT-
23,20V,.4W,PB-FREE
Q1601M16 48012094001 XSTR,FET RF
POWER,SM,25V,MOD,XSTR
,FET RF PWR, 135-941MH
Q1920M20 4813973A32 XSTR,BIP GP
SS,NPN,SM,SC-
70,SMT,50V,.202W,100MA,P
B-FREE
Q1922M20 4813973M75 XSTR,BIP GP
SS,PNP,BC858,SOT-
563,SMT,-30V,.357W,-
100MA,100MHZ
Q201M12 4813970A59 XSTR,FET GP PWR,P-
CH,ENHN,SM,SOT-
23,20V,.4W,PB-FREE
Q202M12 4813973A32 XSTR,BIP GP
SS,NPN,SM,SC-
70,SMT,50V,.202W,100MA,P
B-FREE
Ref. Des. Part Number Description
Q2202M2 4815261H01 XSTR,BIP GP
SS,NPN,DTC114Y,SC-
59,SC-
59,SMT3,50V,100MA,250MH
Z
Q2537M6 4888795V06 XSTR,FET GP
PWR,MOSFET,SM,SMT,20V,
.25W,LEAD-FREE
Q2547M6 4888795V06 XSTR,FET GP
PWR,MOSFET,SM,SMT,20V,
.25W,LEAD-FREE
Q2601M13 4815055H01 XSTR,GEN PURPOSE
SMALL SIG,NPN AND
PNP,UMC5NT2G,SM,50V,10
0A
Q3123M22 4871915M01 XSTR,BIP RF SML
SGNL,NPN,SC-
75A,SMT,12V,.1W,100MA,4.5
GHZ,XST
Q3128M22 4815055H01 XSTR,GEN PURPOSE
SMALL SIG,NPN AND
PNP,UMC5NT2G,SM,50V,10
0A
Q3156M22 4871915M01 XSTR,BIP RF SML
SGNL,NPN,SC-
75A,SMT,12V,.1W,100MA,4.5
GHZ,XST
Q3161M22 4815055H01 XSTR,GEN PURPOSE
SMALL SIG,NPN AND
PNP,UMC5NT2G,SM,50V,10
0A
Q4001M2 4815261H01 XSTR,BIP GP
SS,NPN,DTC114Y,SC-
59,SC-
59,SMT3,50V,100MA,250MH
Z
Q601M19 4813973A04 XSTR,BIP GP
SS,NPN,TA13,SM,SOT-
23,SMT,30V,.225W,300MA,1
25MHZ,P
Q6101M6 4815261H01 XSTR,BIP GP
SS,NPN,DTC114Y,SC-
59,SC-
59,SMT3,50V,100MA,250MH
Z
Q6401M6 48012170001 XSTR,FET GP
PWR,N,SM,SMT,20V,.15W
Ref. Des. Part Number Description
Q6501M6 4813970A62 XSTR,FET GP
PWR,MOSFET,P-
CH,ENHN,CF,-20V,1.3W,PB-
FREE
Q6502M6 48012154001 XSTR,FET GP
PWR,P,SM,SMT,-
20V,.5W,FET
Q6504M6 4809579E77 XSTR,FET GP
SS,MOSFET,N-
CH,SM,30V,1.2X1.2MM PKG
W18 COMP
Q6505M6 4813970A62 XSTR,FET GP
PWR,MOSFET,P-
CH,ENHN,CF,-20V,1.3W,PB-
FREE
Q6506M6 4809579E77 XSTR,FET GP
SS,MOSFET,N-
CH,SM,30V,1.2X1.2MM PKG
W18 COMP
Q6507M6 48012170001 XSTR,FET GP
PWR,N,SM,SMT,20V,.15W
Q6508M6 48012154001 XSTR,FET GP
PWR,P,SM,SMT,-
20V,.5W,FET
Q731M7 4885061Y01 XSTR,BIP RF SMALL
SIGNAL
Q745M7 4813973M75 XSTR,BIP GP
SS,PNP,BC858,SOT-
563,SMT,-30V,.357W,-
100MA,100MHZ
Q756M7 4805585Q32 XSTR,BIP RF SML
SGNL,NPN,NE662M04,SM,S
OT-343,3.3V,TRANSITO
Q767M7 4813973M75 XSTR,BIP GP
SS,PNP,BC858,SOT-
563,SMT,-30V,.357W,-
100MA,100MHZ
Q774M7 4805585Q32 XSTR,BIP RF SML
SGNL,NPN,NE662M04,SM,S
OT-343,3.3V,TRANSITO
Q785M7 4889394V04 XSTR,FET GEN PURPOSE
SMALL SIG,MOSFET,N-
CH,ENHN,SM,20V,.25W,P
R1101M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
