Motorola APX 3000

Schematics, Boards Overlays, and Parts Lists: Main Board Block: 700–800 MHz (84012501002) 8-95
C2467M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2468M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2469M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2470M3 21012119001 CAP,FXD,2.2UF,+20%,-
20%,6.3V-
DC,X5R,CAP,FXD,2.2UF,20
%,6.3V-D
C2471M3 2113945A05 CAP,CHIP,470PF,+10%,-
10%,50V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C2472M3 2113945A09 CAP,CHIP,1000PF,+10%,-
10%,50V-DC,0402,X7R,-
55DEG CMIN,125DEG CM
C2473M3 2113944A25 CAP,CHIP,10PF,.5PF+/-
,50V-DC,0402,C0G,-55DEG
CMIN,125DEG CMAX
C2474M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2475M3 2113945A09 CAP,CHIP,1000PF,+10%,-
10%,50V-DC,0402,X7R,-
55DEG CMIN,125DEG CM
C2477M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2478M3 2113956B54 CAP,FXD,10UF,+20%,-
20%,6.3V-DC,X5R,-55DEG
CMIN,85DEG CMAX
C2479M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2480M3 2113956A51 CAP,FXD,1UF,+10%,-
10%,6.3V-DC,0402,X5R,-
55DEG CMIN,85DEG
CMAX,P
Ref. Des. Part Number Description
C2482M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2483M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2504M6 2113945A09 CAP,CHIP,1000PF,+10%,-
10%,50V-DC,0402,X7R,-
55DEG CMIN,125DEG CM
C2506M6 2113945B02 CAP,CHIP,.01UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C2518M6 2113956B33 CAP,FXD,2.2UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG CMAX
C2520M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2527M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2528M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2531M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2532M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2534M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2535M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2536M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2538M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
Ref. Des. Part Number Description
C2539M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2540M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2541M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2542M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2543M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2544M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2545M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2546M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2548M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2549M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2550M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2551M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2552M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2553M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2554M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
Ref. Des. Part Number Description
C2555M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2806 NOTPLACED CAP,FXD,.1PF,.03PF+/-
,25V-DC,C0G,-55DEG
CMIN,125DEG CMAX,PB-F
C3005M22 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C3006M22 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C3007M22 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C3008M22 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C3012M22 2113946K02 CAP,CHIP,.1UF,+80%,-
20%,16V-DC,0402,Y5V,-
30DEG CMIN,85DEG CMAX
C3013M22 2113946K02 CAP,CHIP,.1UF,+80%,-
20%,16V-DC,0402,Y5V,-
30DEG CMIN,85DEG CMAX
C3014M22 2113944M06 CAP,FXD,3.3PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C3015M22 2113944M06 CAP,FXD,3.3PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C3016M22 2113944M02 CAP,FXD,2.2PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C3017M22 2113944M04 CAP,FXD,2.7PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C3018M22 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
Ref. Des. Part Number Description
