8-96 Schematics, Boards Overlays, and Parts Lists: Main Board Block: 700–800 MHz (84012501002)
C3022M22 2115153H09 CAP,FXD,1.8PF,.1PF+/-
,+5.56%,-5.56%,50V-
DC,0402,C0G
C3023M22 2115153H12 CAP,CERAMIC
CHIP,2.4PF,.1PF+/-,+.1%,-
.1%,50V-
DC,0402,C0G,CAP,
C3024M22 2115153H04 CAP,CERAMIC
CHIP,1.1PF,.1PF+/-,+.1%,-
.1%,50V-
DC,0402,C0G,CAP,
C3025M22 2115153H14 CAP,CERAMIC
CHIP,3PF,.1PF+/-,+.1%,-
.1%,50V-
DC,0402,C0G,CAP, CE
C3026M22 2115153H14 CAP,CERAMIC
CHIP,3PF,.1PF+/-,+.1%,-
.1%,50V-
DC,0402,C0G,CAP, CE
C3027M22 2115153H13 CAP,FXD,2.7PF,.1PF+/-
,+3.7%,-3.7%,50V-
DC,0402,C0G,CAP,
CERAMIC
C3028M22 2115153H15 CAP,CER
CHIP,3.3PF,.1PF+/-,+.1%,-
.1%,50V-
DC,0402,C0G,CAP, CERA
C3029M22 2115153H17 CAP,FXD,3.9PF,.1PF+/-
,50V-DC,0402,C0G,CAP,
CERAMIC, COG
C3042M22 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C3045M22 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C3046M22 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C3049M22 2113946K02 CAP,CHIP,.1UF,+80%,-
20%,16V-DC,0402,Y5V,-
30DEG CMIN,85DEG CMAX
Ref. Des. Part Number Description
C3050M22 2113944M02 CAP,FXD,2.2PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C3051M22 2113944M02 CAP,FXD,2.2PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C3054M22 2115153H07 CAP,FXD,1.5PF,.1PF+/-
,+6.67%,-6.67%,50V-
DC,0402,C0G
C3055M22 2115153H12 CAP,CERAMIC
CHIP,2.4PF,.1PF+/-,+.1%,-
.1%,50V-
DC,0402,C0G,CAP,
C3056M22 2115153H05 CAP,FXD,1.2PF,.1PF+/-
,50V-DC,0402,C0G
C3057M22 2188881Y12 CAP,CER
CHIP,1.8PF,.1PF+/-,16V-
DC,0402,NP0,-55DEG
CMIN,85DEG C
C3065M22 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C3067M22 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C3068M22 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C3069M22 2115153H33 CAP,CER CHIP,9PF,.1PF+/-
,+.1%,-.1%,50V-
DC,0402,C0G,CAP,
CERAMI
C4005M2 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C4006M2 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C4007M2 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
Ref. Des. Part Number Description
C402M20 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C404M20 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C405M20 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C406M20 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C407M20 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C412M20 2115153H26 CAP,CER
CHIP,9.1PF,.1PF+/-,+.1%,-
.1%,50V-
DC,0402,C0G,CAP, CERA
C413M20 2113944A33 CAP,CHIP,47PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C416M20 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C417M20 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C418M20 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C419M20 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C421M20 2113946D07 CAP,CHIP,4.7UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
Ref. Des. Part Number Description
C422M20 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C423M20 2115153H44 CAP,FXD,30PF,+1%,-
1%,50V-DC,0402,C0G
C424M20 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C425M20 2115153H20 CAP,FXD,5.1PF,.1PF+/-
,+2%,-2%,50V-
DC,0402,C0G,CAP,
CERAMIC, CO
C426M20 2113944A63 CAP,FXD,1PF,.25PF+/-,50V-
DC,0402,C0G,-55DEG
CMIN,125DEG CMAX,P
C427M20 2113946D07 CAP,CHIP,4.7UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C428M20 2113946D07 CAP,CHIP,4.7UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C429M20 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C430M20 2115153H44 CAP,FXD,30PF,+1%,-
1%,50V-DC,0402,C0G
C431M20 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C432M20 2115153H20 CAP,FXD,5.1PF,.1PF+/-
,+2%,-2%,50V-
DC,0402,C0G,CAP,
CERAMIC, CO
C433M20 2113944A63 CAP,FXD,1PF,.25PF+/-,50V-
DC,0402,C0G,-55DEG
CMIN,125DEG CMAX,P
C434M20 2113946D07 CAP,CHIP,4.7UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C484M20 2115153H03 CAP,CER CHIP,1PF,.1PF+/-
,+.1%,-.1%,50V-
DC,0402,C0G
Ref. Des. Part Number Description
