Motorola APX 3000 - Page 323

Schematics, Boards Overlays, and Parts Lists: Main Board Block: 700–800 MHz (84012501002) 8-101
C6594M6 2113946C07 CAP,FXD,.33UF,+10%,-
10%,10V-DC,0603,X5R,-
55DEG CMIN,85DEG CMAX
C6595M6 2113946S35 CAP,CHIP,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6596M6 NOTPLACED CAP,CHIP,22PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6601M6 2113944A28 CAP,CHIP,18PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6602M6 2113944A28 CAP,CHIP,18PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6670M6 NOTPLACED CAP,FXD,13PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C702M7 2185419D06 CAP,CHIP,.1UF,+10%,-
10%,25V-DC,1206,-55DEG
CMIN,125DEG CMAX
C703M7 2113945C26 CAP,FXD,.039UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG CMA
C704M7 2185419D06 CAP,CHIP,.1UF,+10%,-
10%,25V-DC,1206,-55DEG
CMIN,125DEG CMAX
C705M7 2115153H30 CAP,CER CHIP,6PF,.1PF+/-
,+.1%,-.1%,50V-
DC,0402,C0G,CAP,
CERAMI
C706M7 2171051Y11 CAP,FXD,.1UF,+5%,-
5%,1206,-55DEG
CMIN,125DEG CMAX,PB-
FREE
C707M7 2113945C01 CAP,CHIP,6800PF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG CM
C708M7 NOTPLACED CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
Ref. Des. Part Number Description
C709M7 2171051Y11 CAP,FXD,.1UF,+5%,-
5%,1206,-55DEG
CMIN,125DEG CMAX,PB-
FREE
C710M7 NOTPLACED CAP,CHIP,390PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C711M7 NOTPLACED CAP,CHIP,56PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C712M7 NOTPLACED CAP,CHIP,270PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C713M7 2113945C25 CAP,FXD,.033UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG CMA
C714M7 2171051Y11 CAP,FXD,.1UF,+5%,-
5%,1206,-55DEG
CMIN,125DEG CMAX,PB-
FREE
C715M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C716M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C717M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C718M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C719M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C720M7 2113944C55 CAP,CHIP,2200PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX
Ref. Des. Part Number Description
C721M7 NOTPLACED CAP,FXD,.22UF,+10%,-
10%,50V-DC,0805,X7R,-
55DEG CMIN,125DEG
CMAX
C724M7 2113955D37 CAP,FXD,10UF,+10%,-
10%,16V-DC,1206,X7R,-
55DEG CMIN,125DEG
CMAX
C725M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C726M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C727M7 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C730M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C731M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C732M7 2113944A32 CAP,CHIP,39PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C733M7 2113945A09 CAP,CHIP,1000PF,+10%,-
10%,50V-DC,0402,X7R,-
55DEG CMIN,125DEG CM
C734M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C735M7 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C736M7 2113945B02 CAP,CHIP,.01UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
Ref. Des. Part Number Description
C737M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C739M7 2113944A17 CAP,CHIP,4.7PF,.25PF+/-
,50V-DC,0402,C0G,-55DEG
CMIN,125DEG CMA
C740M7 2115153H45 CAP,CERAMIC
CHIP,33PF,+1%,-1%,50V-
DC,0402,C0G
C742M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C743M7 2113946B06 CAP,CHIP,.22UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C744M7 2113955D37 CAP,FXD,10UF,+10%,-
10%,16V-DC,1206,X7R,-
55DEG CMIN,125DEG
CMAX
C749M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C750M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C751M7 2113945A09 CAP,CHIP,1000PF,+10%,-
10%,50V-DC,0402,X7R,-
55DEG CMIN,125DEG CM
C752M7 2113944A43 CAP,CHIP,180PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C753M7 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C754M7 2113944A34 CAP,CHIP,56PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
Ref. Des. Part Number Description
