8-102 Schematics, Boards Overlays, and Parts Lists: Main Board Block: 700–800 MHz (84012501002)
C756M7 2113955D37 CAP,FXD,10UF,+10%,-
10%,16V-DC,1206,X7R,-
55DEG CMIN,125DEG
CMAX
C757M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C760M7 2113944A44 CAP,CHIP,220PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C764M7 2113946B06 CAP,CHIP,.22UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C770M7 2113944A44 CAP,CHIP,220PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C772M7 2113945A09 CAP,CHIP,1000PF,+10%,-
10%,50V-DC,0402,X7R,-
55DEG CMIN,125DEG CM
C773M7 2113944A33 CAP,CHIP,47PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C777M7 2113944A44 CAP,CHIP,220PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C780M7 2113944A33 CAP,CHIP,47PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C781M7 2115153H45 CAP,CERAMIC
CHIP,33PF,+1%,-1%,50V-
DC,0402,C0G
C786M7 2113944A44 CAP,CHIP,220PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C803M7 2115153H45 CAP,CERAMIC
CHIP,33PF,+1%,-1%,50V-
DC,0402,C0G
C813M7 NOTPLACED CAP,FXD,1PF,.25PF+/-,50V-
DC,0402,C0G,-55DEG
CMIN,125DEG CMAX,P
Ref. Des. Part Number Description
C816M7 2113944A30 CAP,CHIP,27PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C817M7 2113944A44 CAP,CHIP,220PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C819M7 2113944A44 CAP,CHIP,220PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C823M7 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C824M7 2115153H45 CAP,CERAMIC
CHIP,33PF,+1%,-1%,50V-
DC,0402,C0G
D1M2 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
D200M12 4813978A19 DIODE,RECT,MBR120,SM,
SOD-123,1A,20V,SHTK,PB-
FREE
D2101M2 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
D2301M13 4813974A19 DIODE
ARRAY,MXR,SM,SOT-
323,7V,.2W,SHTK,2,PB-
FREE
D2302M13 4815897H01 DIODE,PIN,UPP9401E,SM,
DO-
216,50A,50V,2.5W,POWER-
MITE
D2303M13 4815897H01 DIODE,PIN,UPP9401E,SM,
DO-
216,50A,50V,2.5W,POWER-
MITE
D2304M2 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
D2305M2 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
D2306M2 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
D2307M2 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
Ref. Des. Part Number Description
D2521M6 4871785H01 DIODE,SWG,BAS116LT1G,
SOT-23/SC-59,SOT-
23,200MA,75V,.225W,SWG
DI
D2M2 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
D3M2 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
D4001M2 4813978A25 DIODE,SWG,BAT54,SM,SO
D-323/SC-
76,200MA,30V,.2W,SHTK,P
B-FREE, W18
D401M20 NOTPLACED DIODE
ARRAY,MXR,SM,SOT-
323,7V,.2W,SHTK,2,PB-
FREE
D6101M6 4813978A25 DIODE,SWG,BAT54,SM,SO
D-323/SC-
76,200MA,30V,.2W,SHTK,P
B-FREE, W18
D6401M6 4813978A25 DIODE,SWG,BAT54,SM,SO
D-323/SC-
76,200MA,30V,.2W,SHTK,P
B-FREE, W18
D6501M6 4813978A25 DIODE,SWG,BAT54,SM,SO
D-323/SC-
76,200MA,30V,.2W,SHTK,P
B-FREE, W18
D722M7 4815011H01 DIODE,SWG,SM,300MA,80
V,T RP
D723M7 4815011H01 DIODE,SWG,SM,300MA,80
V,T RP
E1101M11 2405688Z01 IDCTR,BEAD,FERR BEAD
E201M12 7686949J14 FLTR,FERRITE
BEAD,2A,SM,0805,CHIP,22
0OHM
E2201M2 7685268E01 FLTR,FERRITE
BEAD,650MA,SM,0402,CHI
P, 8 0O H M
E2206M2 7685268E01 FLTR,FERRITE
BEAD,650MA,SM,0402,CHI
P, 8 0O H M
E2207M2 7685268E01 FLTR,FERRITE
BEAD,650MA,SM,0402,CHI
P, 8 0O H M
Ref. Des. Part Number Description
E2247M2 7685268E01 FLTR,FERRITE
BEAD,650MA,SM,0402,CHI
P, 8 0 O HM
E2248M2 7685268E01 FLTR,FERRITE
BEAD,650MA,SM,0402,CHI
P, 8 0 O HM
E2249M2 7685268E01 FLTR,FERRITE
BEAD,650MA,SM,0402,CHI
P, 8 0 O HM
E401M20 2471132D14 IDCTR,25%,200MA,.6OHM,
FERR,SM,0402,IDCTR,FXD
,470OHM,200M
E402M20 2471132D14 IDCTR,25%,200MA,.6OHM,
FERR,SM,0402,IDCTR,FXD
,470OHM,200M
E601M19 2471132D14 IDCTR,25%,200MA,.6OHM,
FERR,SM,0402,IDCTR,FXD
,470OHM,200M
E602M19 2471132D14 IDCTR,25%,200MA,.6OHM,
FERR,SM,0402,IDCTR,FXD
,470OHM,200M
E603M19 2471132D14 IDCTR,25%,200MA,.6OHM,
FERR,SM,0402,IDCTR,FXD
,470OHM,200M
E604M19 2471132D14 IDCTR,25%,200MA,.6OHM,
FERR,SM,0402,IDCTR,FXD
,470OHM,200M
E605M19 2471132D14 IDCTR,25%,200MA,.6OHM,
FERR,SM,0402,IDCTR,FXD
,470OHM,200M
E606M19 2471132D14 IDCTR,25%,200MA,.6OHM,
FERR,SM,0402,IDCTR,FXD
,470OHM,200M
E607M19 2471132D14 IDCTR,25%,200MA,.6OHM,
FERR,SM,0402,IDCTR,FXD
,470OHM,200M
E608M19 2471132D14 IDCTR,25%,200MA,.6OHM,
FERR,SM,0402,IDCTR,FXD
,470OHM,200M
E609M19 2471132D14 IDCTR,25%,200MA,.6OHM,
FERR,SM,0402,IDCTR,FXD
,470OHM,200M
E6501M6 2480067M02 FIXED INDUC-
TOR,FXD,200MA,.4OHM,F
ERR,0805,CHK RF CHIP
BE
Ref. Des. Part Number Description
