Motorola APX 3000

Schematics, Boards Overlays, and Parts Lists: Main Board Block: 700–800 MHz (84012501002) 8-103
E6502M6 2480067M02 FIXED INDUC-
TOR,FXD,200MA,.4OHM,F
ERR,0805,CHK RF CHIP
BE
F200M12 6575834B01 FUSE,FST
BLW,2A,32V,FUSE SUR MT
FL1301M3 9102190J23 FLTR,SAW,BAND-
PASS,1.57542GHZ
NOM,SM,1.4X1.0MM,SMD,
PB-FREE
FL1302M3 9109674L58 BAND PASS FILTER
FL1303M3 9102190J23 FLTR,SAW,BAND-
PASS,1.57542GHZ
NOM,SM,1.4X1.0MM,SMD,
PB-FREE
FL401M20 9175390A01 FLTR,DB,BAND-
PASS,762MHZ
MIN,870MHZ
MAX,50OHM,SM,SAW FIL-
TER, DL
FL402M20 9175390A01 FLTR,DB,BAND-
PASS,762MHZ
MIN,870MHZ
MAX,50OHM,SM,SAW FIL-
TER, DL
FL502M21 91009300001 FLTR,BAND-
PASS,109.65MHZ NOM,FIL-
TER,MONOLITHIC
CRYSTAL,BAND
J102M11 2880658Z08 RF CONNEC-
TOR,SMA,M,CONN SMA
J1301M3 40012057001 RF SWITCH,SWITCH,RF
J1M2 09012130001 CONN,RCPT,24CONT,.4MM
,CONNECTOR, BTB
RECEPTACLE, 24-PIN,
J2401M2 0989851N01 CONN,BTB,2
R OW, RC PT, 40 CO NT, .4 MM ,
GLD,SMD
J2M2 0971704L01 CONN,CUST,RCPT,12CON
T,CONNECTOR, 12-PIN
SOCKET, 0.4MM PIT
J3M2 09012073001 CONN,BTB,RCPT,34CONT,.
4MM,GLD,ST,CONNEC-
TOR, B2B RCPT 34PINS
Ref. Des. Part Number Description
L1001M16 2415429H37 IDCTR,WW,110NH,5%,300
MA,.61OHM,CER,SM,0603,
CHIP
L1002M16 2415429H10 IDCTR,WW,6.8NH,5%,700M
A,.11OHM,CER,SM,0603,C
HIP
L1003M16 2415429H37 IDCTR,WW,110NH,5%,300
MA,.61OHM,CER,SM,0603,
CHIP
L1007M16 2460591K40 IDCTR,FXD,15%,12
TURNS,COUNTERCLOCK-
WISE,28 AWG,SM,HI
L1009M16 2415428H04 IDCTR,AW,5.4NH,2%,1.6A,
AIR,SM,AIR WOUND
IDCTR
L1101M11 2415429H26 IDCTR,WW,33NH,5%,600M
A,.22OHM,CER,SM,0603,C
HIP
L1102M11 2415429H10 IDCTR,WW,6.8NH,5%,700M
A,.11OHM,CER,SM,0603,C
HIP
L1117M11 2415428H01 COIL,AW,1.65NH,10%,1.6A,
AIR,2 TURNS,SM,AIR
WOUND IDCTR
L1301M3 2414017P16 IDCTR,CHIP,18NH,5%,300
MA,.76OHM,CER,9
Q,1.9GHZ SRF,SM,0402,P
L1302M3 2475122C13 IDCTR,3.3NH,9.09%,300MA
,.17OHM,CER,4
TURNS,SM,IND, MULTI-LA
L1303M3 2414017P16 IDCTR,CHIP,18NH,5%,300
MA,.76OHM,CER,9
Q,1.9GHZ SRF,SM,0402,P
L1304M3 2475122C37 IDCTR,100NH,5%,300MA,.0
7OHM,CER,4
TURNS,SM,IND, MULTI-
LAY
L1305M3 24012011010 IDCTR,WW,4.7NH,2%,1.5A,
.06OHM,CER,6.85GHZ
SRF,SM,0402 HI Q
L1306M3 2414017P14 IDCTR,CHIP,12NH,5%,300
MA,.6OHM,CER,9 Q,2GHZ
SRF,SM,0402,PB-F
L1308M3 NOTPLACED IDCTR,WW,39NH,5%,600M
A,CER,SM,CHIP
Ref. Des. Part Number Description
L1316M3 24012011018 IDCTR,WW,9NH,2%,1.4A,.0
7OHM,CER,5GHZ
SRF,SM,0402 HI Q CHIP
L1408M17 24012026009 IDCTR,AW,8.1NH,2%,4.4A,
AIR,SM,ULTRA-MINIA-
TURE AIR CORE I
L1410M17 24012026009 IDCTR,AW,8.1NH,2%,4.4A,
AIR,SM,ULTRA-MINIA-
TURE AIR CORE I
L200M12 2571269C01 IDCTR,COIL,1.5UH,20%,2.9
A,.059OHM,FERR,SM,WW
PWR W18 COMP
L2301M13 24012026005 IDCTR,AW,10.2NH,2%,2.7A
,AIR,SM,ULTRA-MINIA-
TURE AIR CORE
L2302M13 2415429H35 IDCTR,WW,82NH,5%,400M
A,.54OHM,CER,SM,0603,C
HIP
L2303M13 2414017N11 IDCTR,CHIP,8.2NH,5%,600
MA,.26OHM,CER,10
Q,2.5GHZ SRF,SM,0603
L3001M22 2415429H18 IDCTR,WW,15NH,5%,700M
A,.17OHM,CER,SM,0603,C
HIP
L3002M22 2415429H18 IDCTR,WW,15NH,5%,700M
A,.17OHM,CER,SM,0603,C
HIP
L3003M22 2415429H18 IDCTR,WW,15NH,5%,700M
A,.17OHM,CER,SM,0603,C
HIP
L3008M22 2414032F36 IDCTR,WW,150NH,5%,400
MA,.56OHM,CER,35
Q,780MHZ SRF,SM,PB-FR
L3009M22 2414032F36 IDCTR,WW,150NH,5%,400
MA,.56OHM,CER,35
Q,780MHZ SRF,SM,PB-FR
L3010M22 2414017N25 IDCTR,CHIP,120NH,5%,200
MA,2.4OHM,CER,12
Q,600MHZ SRF,SM,0603
L3016M22 2414017N25 IDCTR,CHIP,120NH,5%,200
MA,2.4OHM,CER,12
Q,600MHZ SRF,SM,0603
L3019M22 2414017N25 IDCTR,CHIP,120NH,5%,200
MA,2.4OHM,CER,12
Q,600MHZ SRF,SM,0603
Ref. Des. Part Number Description
L3041M22 2414032F36 IDCTR,WW,150NH,5%,400
MA,.56OHM,CER,35
Q,780MHZ SRF,SM,PB-FR
L3044M22 2414032F36 IDCTR,WW,150NH,5%,400
MA,.56OHM,CER,35
Q,780MHZ SRF,SM,PB-FR
L3047M22 2414032F36 IDCTR,WW,150NH,5%,400
MA,.56OHM,CER,35
Q,780MHZ SRF,SM,PB-FR
L3064M22 2414032F36 IDCTR,WW,150NH,5%,400
MA,.56OHM,CER,35
Q,780MHZ SRF,SM,PB-FR
L401M20 2415427H21 IDCTR,WW,10NH,5%,480M
A,.2OHM,CER,SM,0402,CHI
P
L402M20 2415427H21 IDCTR,WW,10NH,5%,480M
A,.2OHM,CER,SM,0402,CHI
P
L403M20 2414017P07 IDCTR,CHIP,3.3NH,300MA,.
19OHM,CER,8 Q,4GHZ
SRF,SM,0402,PB-F
L404M20 2415427H26 IDCTR,WW,15NH,5%,560M
A,CER,SM,0402,CHIP
L405M20 2415427H21 IDCTR,WW,10NH,5%,480M
A,.2OHM,CER,SM,0402,CHI
P
L406M20 2415427H05 IDCTR,WW,2.4NH,5%,790M
A,.068OHM,CER,SM,0402,
CHIP
L407M20 2415427H16 IDCTR,WW,7.5NH,5%,680M
A,.1OHM,CER,SM,0402,CHI
P
L408M20 2415427H21 IDCTR,WW,10NH,5%,480M
A,.2OHM,CER,SM,0402,CHI
P
L489M20 2414017N11 IDCTR,CHIP,8.2NH,5%,600
MA,.26OHM,CER,10
Q,2.5GHZ SRF,SM,0603
L491M20 2478057A14 IDCTR,8.2NH,2%,.054OHM,
CER,46 Q,5.9GHZ
SRF,PCMT,8.2NH SUR
L500M21 2415429H43 IDCTR,WW,220NH,5%,300
MA,2.1OHM,CER,SM,0603,
CHIP
Ref. Des. Part Number Description
