Motorola APX 3000

8-104 Schematics, Boards Overlays, and Parts Lists: Main Board Block: 700–800 MHz (84012501002)
L503M21 2414017N24 IDCTR,CHIP,100NH,5%,300
MA,2OHM,CER,15
Q,700MHZ SRF,SM,0603,P
L504M21 2478057A51 CHIP INDUC-
TOR,RF,270NH,2%,SM,060
3 HI Q CHIP IDCTR
L513M21 NOTPLACED IDCTR,WW,22NH,5%,700M
A,.19OHM,CER,SM,0603,C
HIP
L550M21 2414017N10 IDCTR,CHIP,6.8NH,5%,600
MA,.22OHM,CER,12
Q,2.7GHZ SRF,SM,0603
L551M21 24012011026 IDCTR,WW,18NH,2%,900M
A,.12OHM,CER,3.55GHZ
SRF,SM,0402 HI Q
L601M19 2415429H43 IDCTR,WW,220NH,5%,300
MA,2.1OHM,CER,SM,0603,
CHIP
L602M19 2466505A01 CHIP INDUC-
TOR,CHIP,10UH,5%,150MA
,FERR,0 AWG,SM,PB-
FREE
L603M19 2466505A01 CHIP INDUC-
TOR,CHIP,10UH,5%,150MA
,FERR,0 AWG,SM,PB-
FREE
L604M19 2414032D16 IDCTR,WW,120NH,5%,800
MA,.26OHM,CER,42
Q,1GHZ SRF,SM,PB-FREE
L605M19 2414017Q54 IDCTR,FXD,3.9UH,10%,30
MA,.9OHM,FERR,45
Q,38MHZ SRF,SM,0805,P
L611M19 2414032F39 IDCTR,WW,270NH,10%,280
MA,1OHM,CER,40
Q,800MHZ SRF,SM,PB-FRE
L6502M6 2471678H01 IDCTR,10UH,20%,FERR,10
UH INDCUTOR
L6504M6 24009268001 IDCTR,PWR,10UH,20%,1.3
A,FERR,SM,10UH 2.1A
SHLD IDCTR
L6505M6 2471678H01 IDCTR,10UH,20%,FERR,10
UH INDCUTOR
L701M7 2475122C29 IDCTR,22NH,5%,300MA,.07
OHM,CER,4
TURNS,SM,IND, MULTI-
LAYE
Ref. Des. Part Number Description
L709M7 2414017N11 IDCTR,CHIP,8.2NH,5%,600
MA,.26OHM,CER,10
Q,2.5GHZ SRF,SM,0603
L720M7 24012100001 IDCTR,FXD,2.2UH,10%,15
MA,35 Q,50MHZ
SRF,SM,IDCTR,2.2UH,1
L727M7 24012100001 IDCTR,FXD,2.2UH,10%,15
MA,35 Q,50MHZ
SRF,SM,IDCTR,2.2UH,1
L728M7 2415429H47 IDCTR,WW,390NH,5%,100
MA,CER,SM,CHIP
L733M7 24012100001 IDCTR,FXD,2.2UH,10%,15
MA,35 Q,50MHZ
SRF,SM,IDCTR,2.2UH,1
L735M7 24012100001 IDCTR,FXD,2.2UH,10%,15
MA,35 Q,50MHZ
SRF,SM,IDCTR,2.2UH,1
L738M7 24012100001 IDCTR,FXD,2.2UH,10%,15
MA,35 Q,50MHZ
SRF,SM,IDCTR,2.2UH,1
L739M7 2414017N25 IDCTR,CHIP,120NH,5%,200
MA,2.4OHM,CER,12
Q,600MHZ SRF,SM,0603
L741M7 24012100001 IDCTR,FXD,2.2UH,10%,15
MA,35 Q,50MHZ
SRF,SM,IDCTR,2.2UH,1
L753M7 2415347H06 IDCTR,WW,2.2UH,5%,320M
A,1.2OHM,CER,SM,IDCTR,
2200NH
L755M7 2415429H38 IDCTR,WW,120NH,5%,300
MA,.65OHM,CER,SM,0603,
CHIP
L758M7 2415429H38 IDCTR,WW,120NH,5%,300
MA,.65OHM,CER,SM,0603,
CHIP
L759M7 2414017N25 IDCTR,CHIP,120NH,5%,200
MA,2.4OHM,CER,12
Q,600MHZ SRF,SM,0603
L768M7 2488090Y25 IDCTR,CHIP,100NH,5%,90
MA,CER,SM,0402,MULAY
PB FREE
L775M7 2415429H38 IDCTR,WW,120NH,5%,300
MA,.65OHM,CER,SM,0603,
CHIP
Ref. Des. Part Number Description
M1 1171905B02 ADHES,WHT,WHT I SHAPE
UNDERFILM COR
M101M12 39012039001 CONN,CMPRSN,3CONT,ST
,CONNECTOR, BAT CON-
TACT, WW P
M1301M3 3987977Y04 CONT,CONN,1CONT,ANT
UNIV 4.5MM,UC 1.8
M1302M3 3987977Y04 CONT,CONN,1CONT,ANT
UNIV 4.5MM,UC 1.8
M2 1171905B02 ADHES,WHT,WHT I SHAPE
UNDERFILM COR
M2533M6 3987977Y04 CONT,CONN,1CONT,ANT
UNIV 4.5MM,UC 1.8
M6502M6 0985888K02 BATTERY CONNEC-
TOR,SKT,NI,LEAP
Paste 11007387003 SLDR,PASTE,500G,PLAS-
TIC JAR,AIR SEAL, 8.9E
LOW VOID
PCB 84012501002 PCB, BOARD, PC, 7800 MN
BRD
Q1001M16 48012094001 XSTR,FET RF
POWER,SM,25V,MOD,XST
R,FET RF PWR, 135-
941MH
Q1101M11 4813973A32 XSTR,BIP GP
SS,NPN,SM,SC-
70,SMT,50V,.202W,100MA,
PB-FREE
Q1103M11 4813970A59 XSTR,FET GP PWR,P-
CH,ENHN,SM,SOT-
23,20V,.4W,PB-FREE
Q201M12 4813970A59 XSTR,FET GP PWR,P-
CH,ENHN,SM,SOT-
23,20V,.4W,PB-FREE
Q202M12 4813973A32 XSTR,BIP GP
SS,NPN,SM,SC-
70,SMT,50V,.202W,100MA,
PB-FREE
Q2202M2 4815261H01 XSTR,BIP GP
SS,NPN,DTC114Y,SC-
59,SC-
59,SMT3,50V,100MA,250M
HZ
Ref. Des. Part Number Description
Q2301M13 4815055H01 XSTR,GEN PURPOSE
SMALL SIG,NPN AND
PNP,UMC5NT2G,SM,50V,1
00A
Q2537M6 4888795V06 XSTR,FET GP PWR,MOS-
FET,SM,SMT,20V,.25W,LEA
D-FREE
Q2547M6 4888795V06 XSTR,FET GP PWR,MOS-
FET,SM,SMT,20V,.25W,LEA
D-FREE
Q3033M22 4813972A17 XSTR,FET GEN PURPOSE
SMALL SIG,MOS-
FET,N,ENHN,SM,SOT-
23,.4W,P
Q3035M22 4813972A17 XSTR,FET GEN PURPOSE
SMALL SIG,MOS-
FET,N,ENHN,SM,SOT-
23,.4W,P
Q3038M22 4871915M01 XSTR,BIP RF SML
SGNL,NPN,SC-
75A,SMT,12V,.1W,100MA,4.
5GHZ,XST
Q3039M22 4885061Y01 XSTR,BIP RF SMALL SIG-
NAL
Q3060M22 4813972A17 XSTR,FET GEN PURPOSE
SMALL SIG,MOS-
FET,N,ENHN,SM,SOT-
23,.4W,P
Q3062M22 4885061Y01 XSTR,BIP RF SMALL SIG-
NAL
Q4001M2 4815261H01 XSTR,BIP GP
SS,NPN,DTC114Y,SC-
59,SC-
59,SMT3,50V,100MA,250M
HZ
Q401M20 4813973A32 XSTR,BIP GP
SS,NPN,SM,SC-
70,SMT,50V,.202W,100MA,
PB-FREE
Q402M20 4813973M75 XSTR,BIP GP
SS,PNP,BC858,SOT-
563,SMT,-30V,.357W,-
100MA,100MHZ
Q403M20 4813973M75 XSTR,BIP GP
SS,PNP,BC858,SOT-
563,SMT,-30V,.357W,-
100MA,100MHZ
Ref. Des. Part Number Description
