Motorola APX 3000

Schematics, Boards Overlays, and Parts Lists: Main Board Block: 700–800 MHz (84012501002) 8-105
Q601M19 4813973A04 XSTR,BIP GP
SS,NPN,TA13,SM,SOT-
23,SMT,30V,.225W,300MA,1
25MHZ,P
Q6101M6 4815261H01 XSTR,BIP GP
SS,NPN,DTC114Y,SC-
59,SC-
59,SMT3,50V,100MA,250M
HZ
Q6401M6 48012170001 XSTR,FET GP
PWR,N,SM,SMT,20V,.15W
Q6501M6 4813970A62 XSTR,FET GP PWR,MOS-
FET,P-CH,ENHN,CF,-
20V,1.3W,PB-FREE
Q6502M6 48012154001 XSTR,FET GP
PWR,P,SM,SMT,-
20V,.5W,FET
Q6504M6 4809579E77 XSTR,FET GP SS,MOS-
FET,N-
CH,SM,30V,1.2X1.2MM
PKG W18 COMP
Q6505M6 4813970A62 XSTR,FET GP PWR,MOS-
FET,P-CH,ENHN,CF,-
20V,1.3W,PB-FREE
Q6506M6 4809579E77 XSTR,FET GP SS,MOS-
FET,N-
CH,SM,30V,1.2X1.2MM
PKG W18 COMP
Q6507M6 48012170001 XSTR,FET GP
PWR,N,SM,SMT,20V,.15W
Q6508M6 48012154001 XSTR,FET GP
PWR,P,SM,SMT,-
20V,.5W,FET
Q731M7 4885061Y01 XSTR,BIP RF SMALL SIG-
NAL
Q745M7 4813973M75 XSTR,BIP GP
SS,PNP,BC858,SOT-
563,SMT,-30V,.357W,-
100MA,100MHZ
Q756M7 4805585Q32 XSTR,BIP RF SML
SGNL,NPN,NE662M04,SM,
SOT-343,3.3V,TRANSITO
Q767M7 4813973M75 XSTR,BIP GP
SS,PNP,BC858,SOT-
563,SMT,-30V,.357W,-
100MA,100MHZ
Ref. Des. Part Number Description
Q774M7 4805585Q32 XSTR,BIP RF SML
SGNL,NPN,NE662M04,SM,
SOT-343,3.3V,TRANSITO
Q785M7 4889394V04 XSTR,FET GEN PURPOSE
SMALL SIG,MOSFET,N-
CH,ENHN,SM,20V,.25W,P
R1001M16 0613952R13 RES,MF,33KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1002M16 0613952R17 RES,MF,47000,5,.0625,SM,
0402,200,PB-FREE
R1003M16 0613952R21 RES,MF,68KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1004M16 0613952R12 RES,MF,30KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1005M16 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1006M16 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1007M16 0613952H53 RES,MF,150OHM,5%,.1W,S
M,0603,200PPM/CEL,PB-
FREE
R1064M16 0613952Q64 RES,MF,430OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1065M16 0613952Q26 RES,MF,11OHM,5%,.0625W
,SM,0402,200PPM/CEL,PB-
FREE
R1066M16 0613952Q64 RES,MF,430OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1101M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1102M11 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1103M11 06009259001 RES,SHUNT,.02OHM,.33W,
SMD,LOW RESISTANCE
THK FLM RES
R1104M11 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
Ref. Des. Part Number Description
R1105M11 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R1106M11 0613952Q21 RES,MF,6.8OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1107M11 0613952Q45 RES,MF,68OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1108M11 0613952N81 RES,MF,68.1KOHM,1%,.06
25W,SM,0402,200PPM/
CEL,PB-FREE
R1110M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1112M11 NOTPLACED RES,MF,51OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1114M11 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R1115M11 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R1116M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1117M11 0613952R22 RES,MF,75KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1121M11 0613952N47 RES,MF,30.1KOHM,1%,.06
25W,SM,0402,200PPM/
CEL,PB-FREE
R1122M11 0613952N85 RES,MF,75KOHM,1%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1124M11 0613952Q42 RES,MF,51OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1125M11 0613952R14 RES,MF,36KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1126M11 0613952R06 RES,MF,16KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1127M11 0613952R08 RES,MF,20KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
R1128M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1135M11 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1136M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1137M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1138M11 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1139M11 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1140M11 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1141M11 0613952R42 RES,MF,510KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1142M11 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1143M11 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1144M11 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1145M11 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1146M11 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1151M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1152M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
