Schematics, Boards Overlays, and Parts Lists: Main Board Block: 700–800 MHz (84012501002) 8-109
R2817 0613952Q41 RES,MF,47OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3002M22 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R3018M22 0613952R18 RES,MF,51KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3019M22 0613952R18 RES,MF,51KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3030M22 0613952R08 RES,MF,20KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3031M22 0613952R08 RES,MF,20KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3032M22 0613952Q31 RES,MF,18OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3034M22 0613952Q31 RES,MF,18OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3036M22 0613952R08 RES,MF,20KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3037M22 0613952R08 RES,MF,20KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3040M22 0613952Q50 RES,MF,110OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3043M22 0613952Q53 RES,MF,150OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3052M22 0613952R18 RES,MF,51KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3058M22 0613952R08 RES,MF,20KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3059M22 0613952Q31 RES,MF,18OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
R3061M22 0613952R08 RES,MF,20KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3063M22 0613952Q54 RES,MF,160OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3066M22 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R4005M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R4006M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R4007M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R4008M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R4009M2 0613952Q85 RES,MF,3.3KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R4010M2 0613952R32 RES,MF,200KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R4011M2 0613952R17 RES,MF,47000,5,.0625,SM,
0402,200,PB-FREE
R4012M2 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R4013M2 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R4014M2 0613952Q85 RES,MF,3.3KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R401M20 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R402M20 0613952R23 RES,MF,82KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R403M20 0613952Q85 RES,MF,3.3KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
R404M20 0613952Q45 RES,MF,68OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R405M20 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R406M20 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R407M20 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R408M20 0613952R23 RES,MF,82KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R409M20 0613952Q85 RES,MF,3.3KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R410M20 0613952Q45 RES,MF,68OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R411M20 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R412M20 0613952Q18 RES,MF,5.1OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R413M20 0613952Q11 RES,MF,2.7OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R447M20 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R448M20 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R450M20 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R451M20 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R452M20 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R453M20 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R454M20 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R455M20 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
Ref. Des. Part Number Description
R456M20 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R457M20 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R500M21 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R502M21 0613952Q36 RES,MF,30OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R512M21 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R525M21 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R526M21 0613958J74 RES,MF,0OHM,5%,.125W,S
M,0805,PB-FREE
R601M19 0613952Q41 RES,MF,47OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R602M19 0613952Q63 RES,MF,390OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R603M19 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R604M19 0613952Q63 RES,MF,390OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R605M19 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R606M19 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R607M19 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R608M19 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R609M19 0613952Q81 RES,MF,2200,5,.0625,SM,0
402,200,PB-FREE
Ref. Des. Part Number Description
