Motorola APX 3000

8-110 Schematics, Boards Overlays, and Parts Lists: Main Board Block: 700–800 MHz (84012501002)
R6101M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6102M6 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R6103M6 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R6104M6 NOTPLACED RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6105M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6106M6 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6107M6 0613952Q55 RES,MF,180OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6108M6 0613952Q61 RES,MF,330OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6109M6 NOTPLACED RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R610M19 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6110M6 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6111M6 NOTPLACED RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6112M6 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6113M6 0613952Q51 RES,MF,120,5,.0625,SM,04
02,200,PB-FREE
R6114M6 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R6115M6 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
Ref. Des. Part Number Description
R6116M6 NOTPLACED RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6117M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6118M6 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R6119M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R611M19 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6120M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6121M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6122M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6125M6 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R612M19 0613952Q94 RES,MF,7.5KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R613M19 0613952Q82 RES,MF,2.4KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R614M19 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R615M19 NOTPLACED RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R616M19 NOTPLACED RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R617M19 NOTPLACED RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R618M19 NOTPLACED RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R619M19 NOTPLACED RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
Ref. Des. Part Number Description
R6204M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6205M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6206M6 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6207M6 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6208M6 0613952Q89 RES,MF,4700,5,.0625,SM,0
402,200,PB-FREE
R6209M6 0613952Q89 RES,MF,4700,5,.0625,SM,0
402,200,PB-FREE
R620M19 NOTPLACED RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6210M6 0613952Q89 RES,MF,4700,5,.0625,SM,0
402,200,PB-FREE
R6211M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6212M6 NOTPLACED RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6213M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6215M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6217M6 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6218M6 0613952Q80 RES,MF,2KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R621M19 NOTPLACED RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R623M19 NOTPLACED RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R624M19 NOTPLACED RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
Ref. Des. Part Number Description
R6301M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6304M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6306M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6310M6 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6311M6 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6312M6 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6313M6 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6314M6 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6316M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6401M6 0613952R18 RES,MF,51KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6402M6 0613952R32 RES,MF,200KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6404M6 0613952Q81 RES,MF,2200,5,.0625,SM,0
402,200,PB-FREE
R6405M6 0613952Q75 RES,MF,1.2KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6406M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6410M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6411M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
Ref. Des. Part Number Description
