Motorola APX 3000

Schematics, Boards Overlays, and Parts Lists: Main Board Block: 700–800 MHz (84012501002) 8-111
R6416M6 0613952Q61 RES,MF,330OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6417M6 0613952Q61 RES,MF,330OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6419M6 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6420M6 0613952R17 RES,MF,47000,5,.0625,SM,
0402,200,PB-FREE
R6421M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6422M6 0613952Q51 RES,MF,120,5,.0625,SM,04
02,200,PB-FREE
R6423M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6425M6 0613952Q80 RES,MF,2KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6426M6 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R6427M6 0613952R11 RES,MF,27KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6428M6 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6429M6 0613952R17 RES,MF,47000,5,.0625,SM,
0402,200,PB-FREE
R6430M6 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R6431M6 0613952Q81 RES,MF,2200,5,.0625,SM,0
402,200,PB-FREE
R6492M6 0613952Q79 RES,MF,1800,5,.0625,SM,0
402,200,PB-FREE
R6501M6 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R6502M6 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R6503M6 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
Ref. Des. Part Number Description
R6504M6 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R6505M6 0613952Q80 RES,MF,2KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6506M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6507M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6508M6 0613952R17 RES,MF,47000,5,.0625,SM,
0402,200,PB-FREE
R6509M6 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6510M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6511M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6512M6 0613952N01 RES,MF,10KOHM,1%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6513M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6514M6 0613952Q89 RES,MF,4700,5,.0625,SM,0
402,200,PB-FREE
R6515M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6516M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6517M6 0613952Q63 RES,MF,390OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6518M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6519M6 0613952Q89 RES,MF,4700,5,.0625,SM,0
402,200,PB-FREE
R6520M6 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
R6521M6 0615049H01 RES,MF,.2OHM,1%,.5W,120
6,KAMAYA 0.2 OHM CHIP
RES
R6522M6 0613952M66 RES,MF,4.75KOHM,1%,.06
25W,SM,0402,200PPM/
CEL,PB-FREE
R6523M6 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R6524M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6525M6 NOTPLACED RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6526M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6527M6 0613952N87 RES,MF,78.7KOHM,1%,.06
25W,SM,0402,200PPM/
CEL,PB-FREE
R6528M6 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6529M6 0615049H01 RES,MF,.2OHM,1%,.5W,120
6,KAMAYA 0.2 OHM CHIP
RES
R6530M6 0613952L30 RES,MF,200OHM,1%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6531M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6532M6 NOTPLACED RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6533M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6534M6 NOTPLACED RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6535M6 0613952N01 RES,MF,10KOHM,1%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6536M6 0613952Z72 RES,MF,91KOHM,1%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6537M6 0613952P09 RES,MF,121KOHM,1%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
R6538M6 0613952Q95 RES,MF,8.2KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6539M6 0613952P66 RES,MF,475KOHM,1%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6540M6 0613952P66 RES,MF,475KOHM,1%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6541M6 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6542M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6543M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6544M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6545M6 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6546M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6547M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6548M6 NOTPLACED RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6550M6 0613952Z64 RES,MF,39KOHM,1%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6551M6 0613952Z62 RES,MF,33KOHM,1%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6552M6 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6558M6 0613952P22 RES,MF,165KOHM,1%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6561M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6562M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
Ref. Des. Part Number Description
