Motorola APX 3000

Schematics, Boards Overlays, and Parts Lists: Main Board Block: 700–800 MHz (84012501002) 8-113
R748M7 0613952Q47 RES,MF,82OHM,5%,.0625
W,SMD,0402,200PPM/
CEL,CER CHIP 82.0 OHM
5%
R751M7 0613952Q59 RES,MF,270OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R754M7 NOTPLACED RES,MF,680OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R757M7 NOTPLACED RES,MF,270OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R761M7 0613952Q29 RES,MF,15OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R762M7 0613952R08 RES,MF,20KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R763M7 0613952R19 RES,MF,56KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R766M7 0613952Q92 RES,MF,6.2KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R769M7 0613952Q29 RES,MF,15OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R771M7 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R776M7 0613952Q67 RES,MF,560OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R778M7 0613952Q29 RES,MF,15OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R779M7 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R785M7 0613952Q60 RES,MF,300OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R799M7 0613952Q60 RES,MF,300OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
R809M7 0613952Q31 RES,MF,18OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R822M7 NOTPLACED RES,MF,2OHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-
FREE
R823M7 NOTPLACED RES,MF,2OHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-
FREE
SH1 26012246001 SHLD,STL,SN PLT,SHIELD,
IF, APX CVT
SH10 26012250001 SHLD,STL,SN PLT,SHIELD,
ANTSWI, APX CVT
SH11 26012258001 SHLD,STL,SN PLT,SHIELD,
ABACUS, APX CVT
SH12 26012251001 SHLD,STL,SN PLT,SHIELD,
PAOP, APX CVT
SH13 26012260001 SHLD,STL,SN PLT,SHIELD,
DRIVER/PA, APX CVT
SH14 26012252001 SHLD,STL,SN PLT,SHIELD,
ALC/DC, APX CVT
SH15 26012261001 SHLD,STL,SN PLT,SHIELD,
VCO, APX CVT
SH16 26012254001 SHLD,STL,SN PLT,SHIELD,
CONTROLLER/AVR, APX
CVT
SH17 26012262001 SHLD,STL,SN PLT,SHIELD,
MACE/MAKO, APX CVT
SH2 26012253001 SHLD,STL,SN PLT,SHIELD,
MIXER, APX CVT
SH3 26012259001 SHLD,STL,SN PLT,SHIELD,
GPS/BT, APX CVT
SH4 26012247001 SHLD,STL,SN PLT,SHIELD,
2ND LO, APX CVT
SH5 26012255001 SHLD,STL,SN PLT,SHIELD,
ALC1, APX CVT
SH6 26012248001 SHLD,STL,SN PLT,SHIELD,
FGU, APX CVT
SH7 26012256001 SHLD,CAN,STL,SN
PLT,SHIELD, DC, APX CVT
SH8 26012249001 SHLD,STL,SN PLT,SHIELD,
TXFE, APX CVT
Ref. Des. Part Number Description
SH9 26012257001 SHLD,CAN,STL,SN
PLT,SHIELD, RXFE, APX
CVT
T506M21 2575851B01 XFMR,BALUN,RF XFMR
BALUN
T507M21 2575851B02 XFMR,BALUN,25,SM,RF
XFMR BALUN
U1001M16 5175143H01 IC,WIDE SPLY RANGE OP
AMP
U1002M16 51012101001 IC,SM,VHF/UHF/800/900
MHZ LDMOS DRVR IC
U1101M11 5188032U43 IC,SENSING CIR-
CUIT,INA138,SM,SOT-23/
5,1PER PKG,PB FREE
U1103M11 5185070Y01 IC,TEMP SENS
U1104M11 5185941F56 IC,OP AMP,1PER
PKG,RAIL-RAIL,SOIC,IC
SNGL LV LP OP AMP
U1105M11 5180390L83 IC,CNTLR,SM,1PER PKG
U1106M11 5175772B05 IC,LTC5532ES6,SOT-
23,1PER PKG,PRCN RF
DET
U1112M11 5175772B04 IC,HMC468LP3E,QFN,1 DB
LSB GAAS MMIC ATTEN
U1113M11 5185941F56 IC,OP AMP,1PER
PKG,RAIL-RAIL,SOIC,IC
SNGL LV LP OP AMP
U1114M11 5185941F56 IC,OP AMP,1PER
PKG,RAIL-RAIL,SOIC,IC
SNGL LV LP OP AMP
U1119M11 5109522E94 GATE,AND,1PER
PKG,SM,2 INPUT IN NANO
PKG
U1121M11 5114000B52 IC,XOR,LOGIC LEVEL
SHIFTER,1PER
PKG,SM,SOT-353,PB-FREE
U1125M11 5175206H01 IC,DAC,W/ 5 PPM/C INT
REF
U1126M11 5109817F77 IC,COMPTR,LMV7275,SC7
0-5
U1127M11 5171779H01 IC,ANLG SW,SC70,SC70-
6,1PER PKG,SPDT ANLG
SW
Ref. Des. Part Number Description
U1128M11 5188085K11 IC,NAND,SINGLE 2
INPUT,SN74LVC1G00YZPR
,SM,GATE, POS, 5 DSBGA,
U1129M11 5175143H01 IC,WIDE SPLY RANGE OP
AMP
U1130M11 5175143H01 IC,WIDE SPLY RANGE OP
AMP
U1131M11 5109817F77 IC,COMPTR,LMV7275,SC7
0-5
U1132M11 5114007M28 IC,D FLIP-FLOP,1PER
PKG,17SZ74,N-
I,SM,SOIC8,PB-FREE
U1133M11 5171779H01 IC,ANLG SW,SC70,SC70-
6,1PER PKG,SPDT ANLG
SW
U1136M11 5109522E94 GATE,AND,1PER
PKG,SM,2 INPUT IN NANO
PKG
U1137M11 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U1138M11 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U1139M11 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U1141M11 5185941F56 IC,OP AMP,1PER
PKG,RAIL-RAIL,SOIC,IC
SNGL LV LP OP AMP
U1142M11 5185941F56 IC,OP AMP,1PER
PKG,RAIL-RAIL,SOIC,IC
SNGL LV LP OP AMP
U1143M11 5185941F56 IC,OP AMP,1PER
PKG,RAIL-RAIL,SOIC,IC
SNGL LV LP OP AMP
U1144M11 5171779H01 IC,ANLG SW,SC70,SC70-
6,1PER PKG,SPDT ANLG
SW
U1146M11 5109522E93 GATE,OR,SN74LVC1G32Y
ZPR,1PER PKG,SM,2
INPUT IN NANO PKG
Ref. Des. Part Number Description
