Motorola APX 3000

8-114 Schematics, Boards Overlays, and Parts Lists: Main Board Block: 700–800 MHz (84012501002)
U1147M11 5109522E94 GATE,AND,1PER
PKG,SM,2 INPUT IN NANO
PKG
U1148M11 5185941F56 IC,OP AMP,1PER
PKG,RAIL-RAIL,SOIC,IC
SNGL LV LP OP AMP
U1149M11 5109522E93 GATE,OR,SN74LVC1G32Y
ZPR,1PER PKG,SM,2
INPUT IN NANO PKG
U1150M11 51009381001 IC,MICROPOWER SOT-23
V REF
U1301M3 51007377001 IC,XCVR,NL5500,BGA,BLU-
ETOOTH, GPS, FM RX, FM
TX
U1304M3 5105739X13 IC,AMP,SIGE,QFN,QFN,18
DB,1.57GHZMIN,1.57GHZM
AX,.9DB,SIGE GPS LO
U1305M3 5187344N09 IC,LNR V
REGLTR,FXD,2.8V,100MA,L
OW NOISE
U1334M3 5102836C11 IC,ANLG
SW,FSA4157,SM,SPDT,PB
FREE
U1335M3 5102836C11 IC,ANLG
SW,FSA4157,SM,SPDT,PB
FREE
U200M12 5188493T01 IC,VREG/
SWG,LP2989,SM,MINI SO-
8 HI PRCN REG 5V
U201M12 5175771A99 IC,LNR V
REGLTR,FXD,100MA,VFBG
A,LOW NOISE, 100MA LIN-
EAR REGL
U202M12 5175772B02 IC,LNR V
REGLTR,FXD,1.8V,100MA,
VFBGA,LINEAR REGLTR
100MA 1.8
U203M12 5175772B01 IC,LNR V
REGLTR,FXD,1.5V,350MA,
VFBGA,LINEAR V REGLTR
350MA
U2101M2 5109522E84 IC,DL SCHT TRIG MICRO
PAK
U2102M2 5109522E84 IC,DL SCHT TRIG MICRO
PAK
Ref. Des. Part Number Description
U2202M2 5164852H47 IC,XLTR,2PER
PKG,TSSOP8,IC, I2C LEV
XLTR
U2205M2 5188682Y01 IC,POWER
DRIVER,40MA,SM,RGB
LED, I2C CONTORL, LLP
PKG
U2301M13 5103535B53 IC,INVTR,DL,NC7WZ04L6X
,2PER PKG,SC70
U2302M13 5185941F45 ATTEN,VAR,14.4DBMIN,15.
6DBMAX,0-2000 MHZ-
FREQ,50OHM,PCMT,SOT-
25
U2402M3 51002923001 IC,LNR V REGLTR,3.3V
LP2989,NOPB
U2403M3 51009735001 IC,RCVR,QFN,IC, RCVR,
ONE-CHAN, QFN, LF
WAKE-UP
U2406M3 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U2407M3 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U2408M3 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U2409M3 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U2410M3 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U2411M3 5175856M01 IC,INVTR,0MHZMAX,DL
INVTR
U2412M3 5114007M45 IC,NOR,1PER PKG,SOT-
353,PB-FREE
U2413M3 51010274001 IC,SDRAM,128MB,8MEG X
16,7.5NS,VFBGA,3.3V,IC,S
DRAM,128MBIT,8M
Ref. Des. Part Number Description
U2414M3 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U2415M3 51009372001 IC,UCNTLR,IC UCNTLR
AT32UC3A0512
U2416M3 51009669001 IC,SENSOR,SM,IC, ACCEL-
EROMETER, MOTION
SENSOR
U2473M3 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U2478M3 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U2510M6 5185912Y03 IC,MICROP,BGA,CRYPTO-
GRAPHIC PROCES-
SOR,IC,CRYPTOGRAPHIC
P
U2525M6 5171339H01 IC,MC78LC18,MICROPO-
WER V REGLTR
U2526M6 5171988H01 IC,COMPTR,CMOS
COMPTR
U4001M2 5164852H47 IC,XLTR,2PER
PKG,TSSOP8,IC, I2C LEV
XLTR
U4003M2 5188691V01 IC,MUX/
DEMUX,NC7SB3157P6X,S
M,SC70-6,1PER
PKG,BUS,PB FREE
U4004M2 5116783H01 IC,ANLG
SW,SN74LVC2G66YZPR,S
M,2PER
PKG,0CHANNELS,BILAT-
ERAL,DL
U402M20 5180428L15 SW,RF
SWITCH,SPDT,SMT,6W,3V
U403M20 5180428L15 SW,RF
SWITCH,SPDT,SMT,6W,3V
U404M20 5180428L15 SW,RF
SWITCH,SPDT,SMT,6W,3V
U405M20 5180428L15 SW,RF
SWITCH,SPDT,SMT,6W,3V
Ref. Des. Part Number Description
U406M20 4885316E32 XSTR,BIP RF SML
SGNL,SLCN,BFR380F,SM,
SMT,6V,380W,80A,14MHZ,T
R
U407M20 4885316E32 XSTR,BIP RF SML
SGNL,SLCN,BFR380F,SM,
SMT,6V,380W,80A,14MHZ,T
R
U408M20 5103535B53 IC,INVTR,DL,NC7WZ04L6X
,2PER PKG,SC70
U507M21 5164015H81 IC,MXR,SM
U601M19 5102495J14 IC,IF,IF DIGITILIZING SUB-
SYSTEM IC,AD9864,QFN
U602M19 4885316E32 XSTR,BIP RF SML
SGNL,SLCN,BFR380F,SM,
SMT,6V,380W,80A,14MHZ,T
R
U603M19 5109522E84 IC,DL SCHT TRIG MICRO
PAK
U604M19 5109522E84 IC,DL SCHT TRIG MICRO
PAK
U605M19 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U606M19 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U607M19 5186311J24 IC,BFR,1PER
PKG,NC7SZ125,ACTIVE
HIGH,BFR,3ST,SM,5.5
U6101M6 0180706J18 IC,PGM,PGM CPLD
U6102M6 5188691V01 IC,MUX/
DEMUX,NC7SB3157P6X,S
M,SC70-6,1PER
PKG,BUS,PB FREE
U6103M6 5175114H01 IC,SNGL AND GATE
MICROPAK
U6104M6 5175114H01 IC,SNGL AND GATE
MICROPAK
U6105M6 5175114H01 IC,SNGL AND GATE
MICROPAK
Ref. Des. Part Number Description
