Motorola APX 3000

Schematics, Boards Overlays, and Parts Lists: Main Board Block: VHF (84012512001_A) 8-151
C2480M3 2113956A51 CAP,FXD,1UF,+10%,-
10%,6.3V-DC,0402,X5R,-
55DEG CMIN,85DEG
CMAX,P
C2482M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2483M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2504M6 2113945A09 CAP CER CHP 1000PF 50V
10%
C2506M6 2113945B02 CAP CER CHP 10,000PF
25V 10%
C2518M6 2113956B33 CAP,FXD,2.2UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG CMAX
C2520M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2527M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2528M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2531M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2532M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2534M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2535M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2536M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2538M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2539M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2540M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2541M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
Ref. Des. Part Number Description
C2542M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2543M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2544M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2545M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2546M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2548M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2549M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2550M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2551M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2552M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2553M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2554M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2555M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2701M13 2113944C04 CAP CER CHP 330.0PF
50V 5%
C2702M13 2113944C48 CAP CER CHP 560.OPF
50V 5%
C2703M13 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C2704M13 2113944C04 CAP CER CHP 330.0PF
50V 5%
C2705M13 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C2706M13 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C2707M13 2113946K02 CAP CER CHP 0.10UF 16V
Ref. Des. Part Number Description
C2708M13 2113944M26 CAP,FXD,22PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C2709M13 2113944C36 CAP CER CHP 33.0PF 50V
5%
C2806 NOTPLACED 64AM DUMMY PART
NUMBER
C3200M22 2113944A40 CAP CER CHP 100.0PF
50V 5%
C3201M22 2113944A40 CAP CER CHP 100.0PF
50V 5%
C3202M22 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C3204M22 2113944A52 CAP CER CHP 1000.0 PF
50V 5%
C3208M22 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C3211M22 2113944M20 CAP,FXD,12PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C3212M22 2113944M22 CAP,FXD,15PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C3213M22 2113946B04 CAP CER CHP 0.10UF 10V
10%
C3214M22 2115153H29 CAP, CERAMIC, COG
C3215M22 2113944A42 CAP CER CHP 150.0PF
50V 5%
C3217M22 2113944M36 CAP,FXD,56PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C3219M22 2113944M32 CAP,FXD,39PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C3220M22 2113944M28 CAP,FXD,27PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
Ref. Des. Part Number Description
C3224M22 2113946B04 CAP CER CHP 0.10UF 10V
10%
C3225M22 2113944M38 CAP,FXD,68PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C3226M22 2113944A42 CAP CER CHP 150.0PF
50V 5%
C3235M22 2115153H42 CAP, CERAMIC, COG
C3240M22 2113944A40 CAP CER CHP 100.0PF
50V 5%
C3244M22 2113944A52 CAP CER CHP 1000.0 PF
50V 5%
C3251M22 2113944M17 CAP,FXD,9.1PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C3252M22 2113944M17 CAP,FXD,9.1PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C3253M22 2113946B04 CAP CER CHP 0.10UF 10V
10%
C3254M22 2115153H42 CAP, CERAMIC, COG
C3255M22 2113944A40 CAP CER CHP 100.0PF
50V 5%
C3258M22 2113944M36 CAP,FXD,56PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C3262M22 2113944M30 CAP,FXD,33PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C3263M22 2113944M26 CAP,FXD,22PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C3264M22 2113946B04 CAP CER CHP 0.10UF 10V
10%
C3265M22 2113944M38 CAP,FXD,68PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C3266M22 2113944A40 CAP CER CHP 100.0PF
50V 5%
Ref. Des. Part Number Description
