Motorola APX 3000

8-152 Schematics, Boards Overlays, and Parts Lists: Main Board Block: VHF (84012512001_A)
C3275M22 2113944A31 CAP CER CHP 33.0PF 50V
5%
C330M20 2113944A30 CAP CER CHP 27.0PF 50V
5%
C331M20 2113944A28 CAP CER CHP 18.0PF 50V
5%
C332M20 2113944A30 CAP CER CHP 27.0PF 50V
5%
C333M20 2113944A30 CAP CER CHP 27.0PF 50V
5%
C334M20 2113944A19 CAP CER CHP 5.6PF 50V
+/- 0.5PF
C335M20 2113944A84 CAP,FXD,43PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C336M20 2113944A21 CAP CER CHP 6.8PF 50V
+/- 0.5PF
C337M20 2113944A28 CAP CER CHP 18.0PF 50V
5%
C338M20 2113946D07 CAP,CHIP,4.7UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C339M20 2113944A29 CAP CER CHP 22.0PF 50V
5%
C340M20 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C341M20 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C342M20 2113946D07 CAP,CHIP,4.7UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C343M20 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C344M20 21012043009 CAPACI-
TOR,CERAMIC,1.0PF,50V-
DC,C0G,
C345M20 2113944A30 CAP CER CHP 27.0PF 50V
5%
C346M20 2113944A28 CAP CER CHP 18.0PF 50V
5%
C347M20 2113944A27 CAP CER CHP 15.0PF 50V
5%
Ref. Des. Part Number Description
C348M20 2113944A28 CAP CER CHP 18.0PF 50V
5%
C349M20 2113944A30 CAP CER CHP 27.0PF 50V
5%
C350M20 2113944A30 CAP CER CHP 27.0PF 50V
5%
C351M20 2113944A19 CAP CER CHP 5.6PF 50V
+/- 0.5PF
C352M20 2115153H48 CAP, CERAMIC, COG
C353M20 2113944A21 CAP CER CHP 6.8PF 50V
+/- 0.5PF
C354M20 2113944A28 CAP CER CHP 18.0PF 50V
5%
C357M20 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C360M20 2115153H37 CAP, CERAMIC, COG
C366M20 2113944A28 CAP CER CHP 18.0PF 50V
5%
C367M20 2113944A27 CAP CER CHP 15.0PF 50V
5%
C368M20 2115153H42 CAP, CERAMIC, COG
C369M20 NOTPLACED 64AM DUMMY PART
NUMBER
C370M20 21012043009 CAPACI-
TOR,CERAMIC,1.0PF,50V-
DC,C0G,
C4005M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C4006M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C4007M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C500M21 2113945B05 CAP,FXD,.033UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C501M21 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C502M21 2113945B05 CAP,FXD,.033UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
Ref. Des. Part Number Description
C503M21 2171051Y01 CAP,FXD,220PF,+1%,-
1%,50V-DC,C0G,-55DEG
CMIN,125DEG CMAX,PB-
C504M21 2113944A40 CAP CER CHP 100.0PF
50V 5%
C505M21 2113944A09 CAP CER CHP 2.2PF 50V
+/- 0.25PF
C506M21 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C507M21 2113945B05 CAP,FXD,.033UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C508M21 2113946D07 CAP,CHIP,4.7UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C509M21 2113945B05 CAP,FXD,.033UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C510M21 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C511M21 2113945B05 CAP,FXD,.033UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C512M21 2113946D07 CAP,CHIP,4.7UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C514M21 NOTPLACED 64AM DUMMY PART
NUMBER
C515M21 2115153H16 CAP, CERAMIC, COG
C516M21 2113944C04 CAP CER CHP 330.0PF
50V 5%
C532M21 2113944A32 CAP CER CHP 39.0PF 50V
5%
C533M21 2115153H52 CAP, CERAMIC, COG
C550M21 NOTPLACED 64AM DUMMY PART
NUMBER
C551M21 NOTPLACED 64AM DUMMY PART
NUMBER
C601M19 2113945B02 CAP CER CHP 10,000PF
25V 10%
C602M19 2113945B02 CAP CER CHP 10,000PF
25V 10%
Ref. Des. Part Number Description
C603M19 2113945B02 CAP CER CHP 10,000PF
25V 10%
C604M19 2113945B02 CAP CER CHP 10,000PF
25V 10%
C605M19 2115153H23 CAP, CERAMIC, COG
C606M19 2113946B04 CAP CER CHP 0.10UF 10V
10%
C607M19 2113944A40 CAP CER CHP 100.0PF
50V 5%
C608M19 2113944A12 CAP CER CHP 3.0PF 50V
+/- 0.25PF
C609M19 2113944A30 CAP CER CHP 27.0PF 50V
5%
C6104M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6105M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6106M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6107M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6108M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6109M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C610M19 2113944A40 CAP CER CHP 100.0PF
50V 5%
C6110M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6111M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6112M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6113M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6114M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6115M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C611M19 2113944A40 CAP CER CHP 100.0PF
50V 5%
Ref. Des. Part Number Description
