Schematics, Boards Overlays, and Parts Lists: Main Board Block: VHF (84012512001_A) 8-157
D3M2 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
D4001M2 4813978A25 SCHOTTKY 30V SOD-323
T&R PB FREE
D6101M6 4813978A25 SCHOTTKY 30V SOD-323
T&R PB FREE
D6401M6 4813978A25 SCHOTTKY 30V SOD-323
T&R PB FREE
D6501M6 4813978A25 SCHOTTKY 30V SOD-323
T&R PB FREE
D722M7 4815011H01 DIODE TRIPLE
D723M7 4815011H01 DIODE TRIPLE
E1101M11 2405688Z01 INDUCTOR FERRITE BEAD
E201M12 7686949J14 FLTR,FERRITE
BEAD,,,,2A,,,,,SM,0805,,CHI
P,220OHM
E2201M2 7685268E01 FERRITE BEAD 20X40 200
MA MAX CHIP
E2206M2 7685268E01 FERRITE BEAD 20X40 200
MA MAX CHIP
E2207M2 7685268E01 FERRITE BEAD 20X40 200
MA MAX CHIP
E2247M2 7685268E01 FERRITE BEAD 20X40 200
MA MAX CHIP
E2248M2 7685268E01 FERRITE BEAD 20X40 200
MA MAX CHIP
E2249M2 7685268E01 FERRITE BEAD 20X40 200
MA MAX CHIP
E302M20 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E601M19 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E602M19 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E603M19 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E604M19 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E605M19 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
Ref. Des. Part Number Description
E606M19 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E607M19 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E608M19 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E609M19 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E6501M6 2480067M02 CHK RF CHIP BEAD
INDUCTOR
E6502M6 2480067M02 CHK RF CHIP BEAD
INDUCTOR
F200M12 6575834B01 FUSE SURFACE MOUNT
FL1301M3 9102190J23 FLTR,SAW,BAND-
PASS,1.57542GHZ
NOM,SM,1.4X1.0MM,SMD,
PB-FREE
FL1302M3 9109674L58 PASSIVE FIL-
TER,CER,BAND-
PASS,2.45GHZ NOM
FL1303M3 9102190J23 FLTR,SAW,BAND-
PASS,1.57542GHZ
NOM,SM,1.4X1.0MM,SMD,
PB-FREE
FL502M21 91009300001 FILTER,MONOLITHIC
CRYSTAL,BAND-
PASS,109.65MHZ NOM
J102M11 2880658Z08 CONNECTOR SMA
J1301M3 40012057001 SWITCH,RF
J1M2 09012130001 CONNECTOR, BTB
RECEPTACLE, 24-PIN,
0.4MM PITCH
J2401M2 0989851N01 CONNECTOR, RECEPTA-
CLE, 0.4MM PITCH, 1.5MM
HEIGHT,40PIN
J2M2 0971704L01 CONNECTOR, 12-PIN
SOCKET, 0.4MM PIT
J3M2 09012073001 CONNECTOR, B2B
RECEPTACLE 34PINS
L1101M11 2415429H26 CHIP INDUCTOR
L1102M11 2415429H10 CHIP INDUCTOR
L1117M11 2415428H01 AIR WOUND INDUCTOR
Ref. Des. Part Number Description
L1203M17 2416066H02 INDUCTOR
L1209M17 2416066H02 INDUCTOR
L1211M17 2416066H02 INDUCTOR
L1301M3 2414017P16 IDCTR,CHIP,18NH,5%,300
MA,.76OHM,CER,9
Q,1.9GHZ SRF,SM,0402,P
L1302M3 NOTPLACED 64AM DUMMY PART
NUMBER
L1303M3 2414017P16 IDCTR,CHIP,18NH,5%,300
MA,.76OHM,CER,9
Q,1.9GHZ SRF,SM,0402,P
L1304M3 2475122C17 IND, MULTI-LAY, 4.7NH
?0.3%, 0402,
L1305M3 24012011010 0402 HIGH Q CHIP INDUC-
TOR
L1306M3 2414017P14 IDCTR,CHIP,12NH,5%,300
MA,.6OHM,CER,9 Q,2GHZ
SRF,SM,0402,PB-F
L1308M3 NOTPLACED 64AM DUMMY PART
NUMBER
L1316M3 24012011018 0402 HIGH Q CHIP INDUC-
TOR
L200M12 2571269C01 INDUCTOR WW POWER
20%
L2701M13 2416066H02 INDUCTOR
L2702M13 2415429H40 CHIP INDUCTOR
L312M20 2414032F35 IDCTR,WW,120NH,5%,400
MA,.51OHM,CER,35
Q,860MHZ SRF,SM,PB-FR
L313M20 2415429H28 CHIP INDUCTOR
L314M20 2415429H28 CHIP INDUCTOR
L315M20 2414017N22 IDCTR,CHIP,68NH,5%,400
MA,1.2OHM,CER,14
Q,800MHZ SRF,SM,0603
L316M20 2415429H34 CHIP INDUCTOR
L317M20 2414017P13 IDCTR,CHIP,10NH,5%,300
MA,.46OHM,CER,9
Q,2.5GHZ SRF,SM,0402,P
L318M20 2414032F35 IDCTR,WW,120NH,5%,400
MA,.51OHM,CER,35
Q,860MHZ SRF,SM,PB-FR
Ref. Des. Part Number Description
L319M20 2414032F35 IDCTR,WW,120NH,5%,400
MA,.51OHM,CER,35
Q,860MHZ SRF,SM,PB-FR
L3205M22 2414032F44 IDCTR,WW,680NH,10%,130
MA,4OHM,CER,30
Q,570MHZ SRF,SM,PB-FRE
L320M20 2415429H28 CHIP INDUCTOR
L3210M22 2415429H27 CHIP INDUCTOR
L3216M22 2415010H04 AIRWOUND COIL
L321M20 2415429H28 CHIP INDUCTOR
L3223M22 2414032F44 IDCTR,WW,680NH,10%,130
MA,4OHM,CER,30
Q,570MHZ SRF,SM,PB-FRE
L3229M22 2414032F44 IDCTR,WW,680NH,10%,130
MA,4OHM,CER,30
Q,570MHZ SRF,SM,PB-FRE
L3230M22 2414032F44 IDCTR,WW,680NH,10%,130
MA,4OHM,CER,30
Q,570MHZ SRF,SM,PB-FRE
L3245M22 2414032F44 IDCTR,WW,680NH,10%,130
MA,4OHM,CER,30
Q,570MHZ SRF,SM,PB-FRE
L3250M22 2415429H30 CHIP INDUCTOR
L3256M22 2414015C05 IDCTR,FXD,33NH,2%,1.3M
A,.09OHM,CER,75
Q,1.7GHZ SRF,SM,1008,P
L3261M22 2414032F44 IDCTR,WW,680NH,10%,130
MA,4OHM,CER,30
Q,570MHZ SRF,SM,PB-FRE
L3269M22 2414032F44 IDCTR,WW,680NH,10%,130
MA,4OHM,CER,30
Q,570MHZ SRF,SM,PB-FRE
L3270M22 2414032F44 IDCTR,WW,680NH,10%,130
MA,4OHM,CER,30
Q,570MHZ SRF,SM,PB-FRE
L327M20 2414032F35 IDCTR,WW,120NH,5%,400
MA,.51OHM,CER,35
Q,860MHZ SRF,SM,PB-FR
L329M20 2478057A30 0306 HIGH Q CHIP INDUC-
TOR
L500M21 2415429H43 CHIP INDUCTOR
Ref. Des. Part Number Description
