Motorola APX 3000

8-158 Schematics, Boards Overlays, and Parts Lists: Main Board Block: VHF (84012512001_A)
L501M21 2414017P25 IDCTR,CHIP,100NH,5%,100
MA,5.5OHM,CER,8
Q,650MHZ SRF,SM,0402
L503M21 2414017N24 IDCTR,CHIP,100NH,5%,300
MA,2OHM,CER,14
Q,700MHZ SRF,SM,0603,P
L504M21 2478057A51 0306 HIGH Q CHIP INDUC-
TOR
L513M21 NOTPLACED 64AM DUMMY PART
NUMBER
L550M21 2414017N20 IDCTR,CHIP,47NH,5%,500
MA,.86OHM,CER,14
Q,900MHZ SRF,SM,0603
L601M19 2415429H43 CHIP INDUCTOR
L602M19 2466505A01 COIL INDUCTOR
L603M19 2466505A01 COIL INDUCTOR
L604M19 2414032D16 IDCTR,WW,120NH,5%,800
MA,.26OHM,CER,42
Q,1GHZ SRF,SM,PB-FREE
L605M19 2414017Q54 IDCTR,FXD,3.9UH,10%,30
MA,.9OHM,FERR,45
Q,38MHZ SRF,SM,0805,P
L611M19 2414032F39 IDCTR,WW,270NH,10%,280
MA,1OHM,CER,40
Q,800MHZ SRF,SM,PB-FRE
L6502M6 2471678H01 10UH INDCUTOR
L6504M6 24009268001 10UH 2.1A SHIELDED
INDUCTOR
L6505M6 2471678H01 10UH INDCUTOR
L704M7 2414017P17 IDCTR,CHIP,22NH,5%,300
MA,.88OHM,CER,9
Q,1.8GHZ SRF,SM,0402,P
L709M7 2415429H21 CHIP INDUCTOR
L720M7 2480646Z20 COIL MULTI-LAYER
CHIP(2.20UH)
L727M7 2480646Z20 COIL MULTI-LAYER
CHIP(2.20UH)
L728M7 2415429H47 CHIP INDUCTOR
L733M7 2480646Z20 COIL MULTI-LAYER
CHIP(2.20UH)
Ref. Des. Part Number Description
L735M7 2480646Z20 COIL MULTI-LAYER
CHIP(2.20UH)
L738M7 2480646Z20 COIL MULTI-LAYER
CHIP(2.20UH)
L739M7 2415429H47 CHIP INDUCTOR
L741M7 2480646Z20 COIL MULTI-LAYER
CHIP(2.20UH)
L746M7 2414017P04 IDCTR,CHIP,1.8NH,300MA,.
14OHM,CER,8 Q,6GHZ
SRF,SM,0402,PB-F
L753M7 2415347H06 IDCTR, 2200NH
L755M7 2415429H47 CHIP INDUCTOR
L758M7 2415429H47 CHIP INDUCTOR
L759M7 2415429H47 CHIP INDUCTOR
L765M7 2414017P16 IDCTR,CHIP,18NH,5%,300
MA,.76OHM,CER,9
Q,1.9GHZ SRF,SM,0402,P
L775M7 2415429H36 CHIP INDUCTOR
L901M16 2414017N10 IDCTR,CHIP,6.8NH,5%,600
MA,.22OHM,CER,10
Q,2.7GHZ SRF,SM,0603
L902M16 2415429H37 CHIP INDUCTOR
L903M16 2414015A07 IDCTR,FXD,180NH,2%,750
MA,.77OHM,CER,25
Q,700MHZ SRF,SM,1008
L904M16 2414017N19 IDCTR,CHIP,39NH,5%,500
MA,.74OHM,CER,12
Q,1GHZ SRF,SM,0603,PB
L905M16 2414017N14 IDCTR,CHIP,15NH,5%,600
MA,.4OHM,CER,12
Q,1.8GHZ SRF,SM,0603,P
L906M16 2460591K40 COIL AIR WOUND INDUC
59.71
L907M16 2471968L13 LOW PROFILE MINI
SPRING INDUCTOR
L908M16 2415428H01 AIR WOUND INDUCTOR
L909M16 2471968L10 9.0NH 2% LP AIRWOUND
INDUCTOR
L910M16 2471968L07 LOW PROFILE MINI
SPRING INDUCTOR
Ref. Des. Part Number Description
L912M16 2414017P19 IDCTR,CHIP,33NH,5%,200
MA,1.5OHM,CER,8
Q,1.3GHZ SRF,SM,0402,P
M1 1171905B02 WHITE I SHAPE UNDER-
FILM CORNER
M101M12 39012039001 CONNECTOR, BATTERY
CONTACT
M1301M3 3987977Y04 CONT,CONN,,1CONT,,,ANT
UNIV 4.5MM,UC 1.8
M1302M3 3987977Y04 CONT,CONN,,1CONT,,,ANT
UNIV 4.5MM,UC 1.8
M2 1171905B02 WHITE I SHAPE UNDER-
FILM CORNER
M2533M6 3987977Y04 CONT,CONN,,1CONT,,,ANT
UNIV 4.5MM,UC 1.8
M6502M6 0985888K02 SKT RTC BTTY LEAP
PASTE 11007387003 SLDR,PASTE,500G,PLAS-
TIC JAR,AIR SEAL, 8.9E
LOW VOID
PCB 84012512001 BOARD, PC, VHF MAIN
BOARD
Q1101M11 4813973A32 XSTR,BIP GP
SS,NPN,SM,SC-
70,SMT,50V,.202W,100MA,
PB-FREE
Q1103M11 4813970A59 P-CH FET 1.0A 20V SOT-23
T&R
Q201M12 4813970A59 P-CH FET 1.0A 20V SOT-23
T&R
Q202M12 4813973A32 XSTR,BIP GP
SS,NPN,SM,SC-
70,SMT,50V,.202W,100MA,
PB-FREE
Q2202M2 4815261H01 TRANSISTOR,BIP GEN-
ERAL PURPOSE SMALL
NPN
Q2537M6 4888795V06 XSTR,FET GP PWR,,,MOS-
FET,,SM,,,SMT,20V,.25W,LE
AD-FREE
Q2547M6 4888795V06 XSTR,FET GP PWR,,,MOS-
FET,,SM,,,SMT,20V,.25W,LE
AD-FREE
Ref. Des. Part Number Description
Q2701M13 4815055H01 TSTR DUAL NPN/PNP UMH
5
Q303M20 4813973M75 XSTR,BIP GP
SS,PNP,BC858,SOT-
563,SMT,-30V,.357W,-
100MA,100MHZ
Q304M20 4813973A32 XSTR,BIP GP
SS,NPN,SM,SC-
70,SMT,50V,.202W,100MA,
PB-FREE
Q3227M22 4885061Y01 XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q3232M22 4815055H01 TSTR DUAL NPN/PNP UMH
5
Q3267M22 4885061Y01 XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q3272M22 4815055H01 TSTR DUAL NPN/PNP UMH
5
Q4001M2 4815261H01 TRANSISTOR,BIP GEN-
ERAL PURPOSE SMALL
NPN
Q601M19 4813973A04 XSTR,BIP GP
SS,NPN,TA13,SM,SOT-
23,SMT,30V,.225W,300MA,1
25MHZ,P
Q6101M6 4815261H01 TRANSISTOR,BIP GEN-
ERAL PURPOSE SMALL
NPN
Q6401M6 48012170001 FET
Q6501M6 4813970A62 XSTR,FET GP PWR,MOS-
FET,P-CH,ENHN,CF,-
20V,1.3W,PB-FREE
Q6502M6 48012154001 FET
Q6504M6 4809579E77 FET, NCH MOS FET, 1.2MM
X 1.2MM PACKAGE, SMD,
W18 COMPLIANT
Q6505M6 4813970A62 XSTR,FET GP PWR,MOS-
FET,P-CH,ENHN,CF,-
20V,1.3W,PB-FREE
Q6506M6 4809579E77 FET, NCH MOS FET, 1.2MM
X 1.2MM PACKAGE, SMD,
W18 COMPLIANT
Q6507M6 48012170001 FET
Ref. Des. Part Number Description
