Motorola APX 3000

Schematics, Boards Overlays, and Parts Lists: Main Board Block: VHF (84012512001_A) 8-159
Q6508M6 48012154001 FET
Q731M7 4885061Y01 XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q745M7 4813973M75 XSTR,BIP GP
SS,PNP,BC858,SOT-
563,SMT,-30V,.357W,-
100MA,100MHZ
Q756M7 4805585Q32 TRANSITOR, NPN RF
Q767M7 4813973M75 XSTR,BIP GP
SS,PNP,BC858,SOT-
563,SMT,-30V,.357W,-
100MA,100MHZ
Q774M7 4805585Q32 TRANSITOR, NPN RF
Q785M7 4889394V04 XSTR,FET GEN PURPOSE
SMALL SIG,MOSFET,N-
CH,ENHN,SM,20V,.25W,P
Q901M16 48012094001 MOD,XSTR,FET RF PWR,
135-941MHZ
R1101M11 0613952R01 CER CHIP RES 10K OHM
5% 0402
R1102M11 0613952R25 CER CHIP RES 100K OHM
5% 0402
R1103M11 06009259001 LOW RESISTANCE THICK
FILM RESISTOR
R1104M11 0613952Q49 CER CHIP RES 100 OHM 5
0402
R1105M11 0613952Q49 CER CHIP RES 100 OHM 5
0402
R1106M11 0613952K73 CER CHIP RES 56.2 OHM
1% 0402
R1107M11 0613952Q45 CER CHIP RES 68.0 OHM 5
0402
R1108M11 0613952N81 CER CHIP RES 68.1K OHM
1 0402
R1110M11 0613952R01 CER CHIP RES 10K OHM
5% 0402
R1112M 11 N OTPLACED 64AM DUMM Y PART
NUMBER
R1114M11 0613952Q49 CER CHIP RES 100 OHM 5
0402
R1115M11 0613952Q49 CER CHIP RES 100 OHM 5
0402
Ref. Des. Part Number Description
R1116M11 0613952R01 CER CHIP RES 10K OHM
5% 0402
R1117M11 0613952R11 CER CHIP RES 27K OHM
5% 0402
R1121M11 0613952N47 CER CHIP RES 30.1K OHM
1 0402
R1122M11 0613952N85 CER CHIP RES 75.0K OHM
1 0402
R1124M11 0613952Q42 CER CHIP RES 51.0 OHM 5
0402
R1125M11 0613952Z60 RES,MF,27KOHM,1%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1126M11 0613952N05 CER CHIP RES 11.0K OHM
1 0402
R1127M11 0613952R08 CER CHIP RES 20K OHM 5
0402
R1128M11 0613952R01 CER CHIP RES 10K OHM
5% 0402
R1135M11 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1136M11 0613952R01 CER CHIP RES 10K OHM
5% 0402
R1137M11 0613952R01 CER CHIP RES 10K OHM
5% 0402
R1138M11 0613952R25 CER CHIP RES 100K OHM
5% 0402
R1139M11 0613952R25 CER CHIP RES 100K OHM
5% 0402
R1140M11 0613952R25 CER CHIP RES 100K OHM
5% 0402
R1141M11 0613952R42 CER CHIP RES 510K OHM
5 0402
R1142M11 0613952R25 CER CHIP RES 100K OHM
5% 0402
R1143M11 0613952R25 CER CHIP RES 100K OHM
5% 0402
R1144M11 0613952R25 CER CHIP RES 100K OHM
5% 0402
R1145M11 0613952R25 CER CHIP RES 100K OHM
5% 0402
Ref. Des. Part Number Description
R1146M11 0613952R25 CER CHIP RES 100K OHM
5% 0402
R1151M11 0613952R05 CER CHIP RES 15K OHM
5% 0402
R1152M11 0613952R01 CER CHIP RES 10K OHM
5% 0402
R1154M11 0613952N01 CER CHIP RES 10.0K OHM
1 0402
R1158M11 NOTPLACED 64AM DUMMY PART
NUMBER
R1160M11 0613952R03 CER CHIP RES 12K OHM
5% 0402
R1162M11 0613952R29 CER CHIP RES 150K OHM
5% 0402
R1163M11 0613952R06 CER CHIP RES 16K OHM 5
0402
R1164M11 0613952R01 CER CHIP RES 10K OHM
5% 0402
R1165M11 0613952Q56 CER CHIP RES 200 OHM 5
0402
R1166M11 0613952Q56 CER CHIP RES 200 OHM 5
0402
R1167M11 0613952R01 CER CHIP RES 10K OHM
5% 0402
R1168M11 0613952Q49 CER CHIP RES 100 OHM 5
0402
R1169M11 0613952P52 CER CHIP RES 340K OHM
1 0402
R1170M11 0613952N88 CER CHIP RES 80.6K OHM
1 0402
R1171M11 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1172M11 0613952Q89 CER CHIP RES 4700 OHM
5 0402
R1174M11 0613952N01 CER CHIP RES 10.0K OHM
1 0402
R1175M11 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1176M11 0613952M26 CER CHIP RES 1820 OHM
1% 0402
Ref. Des. Part Number Description
R1177M11 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1178M11 0613952R01 CER CHIP RES 10K OHM
5% 0402
R1180M11 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1182M11 0613952R01 CER CHIP RES 10K OHM
5% 0402
R1198M11 0613952J01 CER CHIP RES 10K OHM
5% 0603
R1202M11 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1301M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1302M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1303M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1304M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1305M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1306M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1307M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1308M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R1309M3 NOTPLACED 64AM DUMMY PART
NUMBER
R1310M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1311M3 NOTPLACED 64AM DUMMY PART
NUMBER
R1312M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1313M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1314M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
Ref. Des. Part Number Description
