8-160 Schematics, Boards Overlays, and Parts Lists: Main Board Block: VHF (84012512001_A)
R1315M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1316M3 NOTPLACED 64AM DUMMY PART
NUMBER
R1317M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1318M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1319M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1320M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1321M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1322M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1323M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1324M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R1325M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1326M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1327M3 NOTPLACED 64AM DUMMY PART
NUMBER
R1328M3 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R1329M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1330M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1331M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1332M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1333M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R1337M3 NOTPLACED 64AM DUMMY PART
NUMBER
Ref. Des. Part Number Description
R1338M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1340M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1M2 0613952R17 CER CHIP RES 47K OHM
5% 0402
R2 NOTPLACED 64AM DUMMY PART
NUMBER
R20 NOTPLACED 64AM DUMMY PART
NUMBER
R201M12 0613952R25 CER CHIP RES 100K OHM
5% 0402
R202M12 0613952Q89 CER CHIP RES 4700 OHM
5 0402
R2104M2 0613952Q89 CER CHIP RES 4700 OHM
5 0402
R2105M2 0613952Q89 CER CHIP RES 4700 OHM
5 0402
R2106M2 NOTPLACED 64AM DUMMY PART
NUMBER
R2107M2 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R2109M2 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R2110M2 0613952Q33 CER CHIP RES 22.0 OHM 5
0402
R2111M2 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R2113M2 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R2114M2 0613952Q33 CER CHIP RES 22.0 OHM 5
0402
R2115M2 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R2116M2 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2117M2 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2118M2 0613952R01 CER CHIP RES 10K OHM
5% 0402
Ref. Des. Part Number Description
R2120M2 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2197M2 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2198M2 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2199M2 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R21M2 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2201M2 0613952R32 CER CHIP RES 200K OHM
5 0402
R2204M2 0613952Q85 CER CHIP RES 3300 OHM
5 0402
R2206M2 0613952Q85 CER CHIP RES 3300 OHM
5 0402
R2207M2 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2235M2 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2244M2 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R2245M2 0613952Q81 CER CHIP RES 2200 OHM
5 0402
R2246M2 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R2254M2 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2255M2 0613952Q66 CER CHIP RES 510 OHM 5
0402
R2256M2 0613952Q66 CER CHIP RES 510 OHM 5
0402
R2257M2 0613952Q66 CER CHIP RES 510 OHM 5
0402
R22M2 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2356M2 0613952Q09 CER CHIP RES 2.2 OHM 5
0402
R2357M2 0613952Q09 CER CHIP RES 2.2 OHM 5
0402
Ref. Des. Part Number Description
R2358M2 0613952Q66 CER CHIP RES 510 OHM 5
0402
R2359M2 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2360M2 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2361M2 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2362M2 0613952Q49 CER CHIP RES 100 OHM 5
0402
R2363M2 0613952Q53 CER CHIP RES 150 OHM 5
0402
R2364M2 0613952Q49 CER CHIP RES 100 OHM 5
0402
R2401M2 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2404M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2405M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2406M3 NOTPLACED 64AM DUMMY PART
NUMBER
R2407M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2408M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2412M3 0613952Q53 CER CHIP RES 150 OHM 5
0402
R2414M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2416M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2418M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2419M3 0613952Q49 CER CHIP RES 100 OHM 5
0402
R2433M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2434M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
Ref. Des. Part Number Description
