Motorola APX 3000

Schematics, Boards Overlays, and Parts Lists: Main Board Block: VHF (84012512001_A) 8-161
R2435M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2436M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2437M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2441M3 0613952Q41 CER CHIP RES 47.0 OHM 5
0402
R2442M3 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R2443M3 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R2444M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2449M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2450M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2451M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2452M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2453M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2454M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2455M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2456M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2457M3 0613952R05 CER CHIP RES 15K OHM
5% 0402
R2458M3 0613952Q89 CER CHIP RES 4700 OHM
5 0402
R2459M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2460M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2461M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
Ref. Des. Part Number Description
R2465M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2466M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2467M3 0613952Q32 CER CHIP RES 20.0 OHM 5
0402
R2469M3 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R2470M3 NOTPLACED 64AM DUMMY PART
NUMBER
R2471M3 NOTPLACED 64AM DUMMY PART
NUMBER
R2472M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2473M3 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2474M3 0613952R35 CER CHIP RES 270K OHM
5% 0402
R2475M3 0613952Q53 CER CHIP RES 150 OHM 5
0402
R2476M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2477M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2478M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2479M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2480M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2481M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2484M3 0613952Q35 CER CHIP RES 27.0 OHM 5
0402
R2485M3 0613952Q35 CER CHIP RES 27.0 OHM 5
0402
R2486M3 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2487M3 0613952R01 CER CHIP RES 10K OHM
5% 0402
Ref. Des. Part Number Description
R2488M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2489M3 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2490M3 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2491M3 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2492M3 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2493M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2495M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2496M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2497M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2501M6 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2503M6 NOTPLACED 64AM DUMMY PART
NUMBER
R2505M6 0613952Q75 CER CHIP RES 1200 OHM
5 0402
R2507M6 0613952R49 CER CHIP RES 1.0M OHM
5% 0402
R2508M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2509M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2511M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2512M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2513M6 0613952Q80 CER CHIP RES 2000 OHM
5 0402
R2514M6 NOTPLACED 64AM DUMMY PART
NUMBER
R2515M6 NOTPLACED 64AM DUMMY PART
NUMBER
Ref. Des. Part Number Description
R2516M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2517M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2519M6 0613952H25 CER CHIP RES 10.0 OHM
5% 0603
R2522M6 0613952R74 RES,MF,10MOHM,5%,.0625
W,SM,0402,400PPM/
CEL,PB-FREE
R2523M6 0613952R74 RES,MF,10MOHM,5%,.0625
W,SM,0402,400PPM/
CEL,PB-FREE
R2524M6 0613952R49 CER CHIP RES 1.0M OHM
5% 0402
R2529M6 0613952P30 CER CHIP RES 200K OHM
1 0402
R2530M6 0613952P30 CER CHIP RES 200K OHM
1 0402
R2560M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2701M13 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2702M13 NOTPLACED 64AM DUMMY PART
NUMBER
R2703M13 0613952H47 CER CHIP RES 82.0 OHM 5
0603
R2704M13 0613952H47 CER CHIP RES 82.0 OHM 5
0603
R2705M13 0613952H47 CER CHIP RES 82.0 OHM 5
0603
R2706M13 0662057B47 CHIP RES 0 OHMS +-.0 50
OHMS
R2803 0613952Q37 CER CHIP RES 33.0 OHM 5
0402
R2804 0613952Q49 CER CHIP RES 100 OHM 5
0402
R2805 0613952Q49 CER CHIP RES 100 OHM 5
0402
R2806 0613952Q59 CER CHIP RES 270 OHM 5
0402
R2807 0613952Q56 CER CHIP RES 200 OHM 5
0402
Ref. Des. Part Number Description
