Motorola APX 3000

8-162 Schematics, Boards Overlays, and Parts Lists: Main Board Block: VHF (84012512001_A)
R2808 0613952Q49 CER CHIP RES 100 OHM 5
0402
R2810 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2811 0613952Q89 CER CHIP RES 4700 OHM
5 0402
R2812 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2813 NOTPLACED 64AM DUMMY PART
NUMBER
R2817 0613952Q41 CER CHIP RES 47.0 OHM 5
0402
R310M20 0613952R22 CER CHIP RES 75K OHM 5
0402
R311M20 0613952R27 CER CHIP RES 120K OHM
5% 0402
R312M20 0613952R01 CER CHIP RES 10K OHM
5% 0402
R313M20 0613952Q37 CER CHIP RES 33.0 OHM 5
0402
R314M20 0613952Q75 CER CHIP RES 1200 OHM
5 0402
R315M20 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R316M20 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R317M20 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R3200M22 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R3201M22 0613952Q13 CER CHIP RES 3.3 OHM 5
0402
R3202M22 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R3203M22 0613952Q75 CER CHIP RES 1200 OHM
5 0402
R3204M22 0613952Q75 CER CHIP RES 1200 OHM
5 0402
R3205M22 0613952Q57 CER CHIP RES 220 OHM 5
0402
Ref. Des. Part Number Description
R3206M22 0613952Q52 CER CHIP RES 130 OHM 5
0402
R3207M22 0613952Q57 CER CHIP RES 220 OHM 5
0402
R3208M22 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R3218M22 0613952Q93 CER CHIP RES 6800 OHM
5 0402
R3222M22 0613952Q96 CER CHIP RES 9100 OHM
5 0402
R3231M22 0613952Q58 CER CHIP RES 240 OHM 5
0402
R3233M22 0613952Q53 CER CHIP RES 150 OHM 5
0402
R3257M22 0613952Q96 CER CHIP RES 9100 OHM
5 0402
R3260M22 0613952Q96 CER CHIP RES 9100 OHM
5 0402
R3271M22 0613952Q53 CER CHIP RES 150 OHM 5
0402
R3273M22 0613952Q53 CER CHIP RES 150 OHM 5
0402
R380M20 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R381M20 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R4005M2 0613952R01 CER CHIP RES 10K OHM
5% 0402
R4006M2 0613952R01 CER CHIP RES 10K OHM
5% 0402
R4007M2 0613952R01 CER CHIP RES 10K OHM
5% 0402
R4008M2 0613952R01 CER CHIP RES 10K OHM
5% 0402
R4009M2 0613952Q85 CER CHIP RES 3300 OHM
5 0402
R4010M2 0613952R32 CER CHIP RES 200K OHM
5 0402
R4011M2 0613952R17 CER CHIP RES 47K OHM
5% 0402
Ref. Des. Part Number Description
R4012M2 0613952R09 CER CHIP RES 22K OHM
5% 0402
R4013M2 0613952R09 CER CHIP RES 22K OHM
5% 0402
R4014M2 0613952Q85 CER CHIP RES 3300 OHM
5 0402
R500M21 0613952Q37 CER CHIP RES 33.0 OHM 5
0402
R502M21 0613952Q36 CER CHIP RES 30.0 OHM 5
0402
R512M21 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R525M21 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R526M21 0613958J74 CER CHIP RES 0.0 OHM
JMP 0805
R601M19 0613952Q41 CER CHIP RES 47.0 OHM 5
0402
R602M19 0613952Q63 CER CHIP RES 390 OHM 5
0402
R603M19 0613952R25 CER CHIP RES 100K OHM
5% 0402
R604M19 0613952Q63 CER CHIP RES 390 OHM 5
0402
R605M19 0613952R01 CER CHIP RES 10K OHM
5% 0402
R606M19 0613952R01 CER CHIP RES 10K OHM
5% 0402
R607M19 0613952R25 CER CHIP RES 100K OHM
5% 0402
R608M19 0613952R01 CER CHIP RES 10K OHM
5% 0402
R609M19 0613952Q81 CER CHIP RES 2200 OHM
5 0402
R6101M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6102M6 0613952R09 CER CHIP RES 22K OHM
5% 0402
R6103M6 0613952R09 CER CHIP RES 22K OHM
5% 0402
Ref. Des. Part Number Description
R6104M6 NOTPLACED 64AM DUMMY PART
NUMBER
R6105M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6106M6 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R6107M6 0613952Q55 CER CHIP RES 180 OHM 5
0402
R6108M6 0613952Q61 CER CHIP RES 330 OHM 5
0402
R6109M6 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R610M19 0613952R25 CER CHIP RES 100K OHM
5% 0402
R6110M6 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R6111M6 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R6112M6 NOTPLACED 64AM DUMMY PART
NUMBER
R6113M6 0613952Q51 CER CHIP RES 120 OHM 5
0402
R6114M6 0613952Q49 CER CHIP RES 100 OHM 5
0402
R6115M6 0613952Q49 CER CHIP RES 100 OHM 5
0402
R6116M6 NOTPLACED 64AM DUMMY PART
NUMBER
R6117M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6118M6 0613952R09 CER CHIP RES 22K OHM
5% 0402
R6119M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R611M19 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6120M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6121M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
Ref. Des. Part Number Description
