Motorola APX 3000

Schematics, Boards Overlays, and Parts Lists: Main Board Block: VHF (84012512001_A) 8-163
R6122M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6125M6 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R612M19 0613952Q94 CER CHIP RES 7500 OHM
5 0402
R613M19 0613952Q82 CER CHIP RES 2400 OHM
5 0402
R614M19 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R615M19 NOTPLACED 64AM DUMMY PART
NUMBER
R616M19 NOTPLACED 64AM DUMMY PART
NUMBER
R617M19 NOTPLACED 64AM DUMMY PART
NUMBER
R618M19 NOTPLACED 64AM DUMMY PART
NUMBER
R619M19 NOTPLACED 64AM DUMMY PART
NUMBER
R6204M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6205M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6206M6 0613952R25 CER CHIP RES 100K OHM
5% 0402
R6207M6 0613952R25 CER CHIP RES 100K OHM
5% 0402
R6208M6 0613952Q89 CER CHIP RES 4700 OHM
5 0402
R6209M6 0613952Q89 CER CHIP RES 4700 OHM
5 0402
R620M19 NOTPLACED 64AM DUMMY PART
NUMBER
R6210M6 0613952Q89 CER CHIP RES 4700 OHM
5 0402
R6211M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6212M6 NOTPLACED 64AM DUMMY PART
NUMBER
Ref. Des. Part Number Description
R6213M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6215M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6217M6 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R6218M6 0613952Q80 CER CHIP RES 2000 OHM
5 0402
R621M19 NOTPLACED 64AM DUMMY PART
NUMBER
R623M19 NOTPLACED 64AM DUMMY PART
NUMBER
R624M19 NOTPLACED 64AM DUMMY PART
NUMBER
R6301M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6304M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6306M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6310M6 0613952Q37 CER CHIP RES 33.0 OHM 5
0402
R6311M6 0613952Q37 CER CHIP RES 33.0 OHM 5
0402
R6312M6 0613952Q37 CER CHIP RES 33.0 OHM 5
0402
R6313M6 0613952Q37 CER CHIP RES 33.0 OHM 5
0402
R6314M6 0613952Q37 CER CHIP RES 33.0 OHM 5
0402
R6316M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6401M6 0613952R18 CER CHIP RES 51K OHM 5
0402
R6402M6 0613952R32 CER CHIP RES 200K OHM
5 0402
R6404M6 0613952Q81 CER CHIP RES 2200 OHM
5 0402
R6405M6 0613952Q75 CER CHIP RES 1200 OHM
5 0402
Ref. Des. Part Number Description
R6406M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6410M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6411M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6416M6 0613952Q61 CER CHIP RES 330 OHM 5
0402
R6417M6 0613952Q61 CER CHIP RES 330 OHM 5
0402
R6419M6 0613952Q37 CER CHIP RES 33.0 OHM 5
0402
R6420M6 0613952R17 CER CHIP RES 47K OHM
5% 0402
R6421M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6422M6 0613952Q51 CER CHIP RES 120 OHM 5
0402
R6423M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6425M6 0613952Q80 CER CHIP RES 2000 OHM
5 0402
R6426M6 0613952Q49 CER CHIP RES 100 OHM 5
0402
R6427M6 0613952R11 CER CHIP RES 27K OHM
5% 0402
R6428M6 0613952R25 CER CHIP RES 100K OHM
5% 0402
R6429M6 0613952R17 CER CHIP RES 47K OHM
5% 0402
R6430M6 0613952R09 CER CHIP RES 22K OHM
5% 0402
R6431M6 0613952Q81 CER CHIP RES 2200 OHM
5 0402
R6492M6 0613952Q79 CER CHIP RES 1800 OHM
5 0402
R6501M6 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R6502M6 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
Ref. Des. Part Number Description
R6503M6 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R6504M6 0613952R09 CER CHIP RES 22K OHM
5% 0402
R6505M6 0613952Q80 CER CHIP RES 2000 OHM
5 0402
R6506M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6507M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6508M6 0613952R17 CER CHIP RES 47K OHM
5% 0402
R6509M6 0613952R25 CER CHIP RES 100K OHM
5% 0402
R6510M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6511M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6512M6 0613952N01 CER CHIP RES 10.0K OHM
1 0402
R6513M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6514M6 0613952Q89 CER CHIP RES 4700 OHM
5 0402
R6515M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6516M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6517M6 0613952Q63 CER CHIP RES 390 OHM 5
0402
R6518M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6519M6 0613952Q89 CER CHIP RES 4700 OHM
5 0402
R6520M6 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R6521M6 0615049H01 KAMAYA 0.2 OHM CHIP
RESISTOR
R6522M6 0613952M66 CER CHIP RES 4750 OHM
1% 0402
Ref. Des. Part Number Description
