Motorola APX 3000

Schematics, Boards Overlays, and Parts Lists: Main Board Block: VHF (84012512001_A) 8-165
R706M7 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R708M7 0613952Q45 CER CHIP RES 68.0 OHM 5
0402
R709M7 NOTPLACED 64AM DUMMY PART
NUMBER
R710M7 0613952Q60 CER CHIP RES 300 OHM 5
0402
R711M7 0613952Q60 CER CHIP RES 300 OHM 5
0402
R721M7 0613952R01 CER CHIP RES 10K OHM
5% 0402
R722M7 0613952Q56 CER CHIP RES 200 OHM 5
0402
R723M7 0613952Q82 CER CHIP RES 2400 OHM
5 0402
R728M7 0613952Q31 CER CHIP RES 18.0 OHM 5
0402
R729M7 0613952R09 CER CHIP RES 22K OHM
5% 0402
R730M7 0613952Q75 CER CHIP RES 1200 OHM
5 0402
R734M7 0613952Q79 CER CHIP RES 1800 OHM
5 0402
R736M7 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R741M7 0613952R09 CER CHIP RES 22K OHM
5% 0402
R742M7 0613952R23 CER CHIP RES 82K OHM
5% 0402
R743M7 0613952R17 CER CHIP RES 47K OHM
5% 0402
R744M7 0613952Q91 CER CHIP RES 5600 OHM
5 0402
R745M7 0613952R09 CER CHIP RES 22K OHM
5% 0402
R747M7 0613952Q32 CER CHIP RES 20.0 OHM 5
0402
R748M7 0613952Q47 CER CHIP RES 82.0 OHM
5% 0402
Ref. Des. Part Number Description
R751M7 0613952Q59 CER CHIP RES 270 OHM 5
0402
R754M7 0613952Q71 CER CHIP RES 820 OHM 5
0402
R757M7 0613952Q59 CER CHIP RES 270 OHM 5
0402
R761M7 0613952Q23 CER CHIP RES 8.2 OHM 5
0402
R762M7 0613952R08 CER CHIP RES 20K OHM 5
0402
R763M7 0613952R19 CER CHIP RES 56K OHM
5% 0402
R766M7 0613952Q92 CER CHIP RES 6200 OHM
5 0402
R769M7 0613952Q37 CER CHIP RES 33.0 OHM 5
0402
R771M7 0613952Q49 CER CHIP RES 100 OHM 5
0402
R776M7 0613952Q67 CER CHIP RES 560 OHM 5
0402
R785M7 NOTPLACED 64AM DUMMY PART
NUMBER
R799M7 NOTPLACED 64AM DUMMY PART
NUMBER
R822M7 NOTPLACED 64AM DUMMY PART
NUMBER
R823M7 NOTPLACED 64AM DUMMY PART
NUMBER
R901M16 0613952R01 CER CHIP RES 10K OHM
5% 0402
R902M16 0613952R01 CER CHIP RES 10K OHM
5% 0402
R903M16 0613952N85 CER CHIP RES 75.0K OHM
1 0402
R904M16 0613952R13 CER CHIP RES 33K OHM
5% 0402
R905M16 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R906M16 0613952Q61 CER CHIP RES 330 OHM 5
0402
SH1 26012246001 SHIELD, IF
Ref. Des. Part Number Description
SH10 26012250001 SHIELD, ANTSWI
SH11 26012258001 SHIELD, ABACUS
SH12 26012251001 SHIELD, PAOP
SH13 26012260001 SHIELD, DRIVER/PA
SH14 26012252001 SHIELD, ALC/DC
SH15 26012261001 SHIELD, VCO
SH16 26012254001 SHIELD, CONTROLLER/
AVR
SH17 26012262001 SHIELD, MACE/MAKO
SH2 26012253001 SHIELD, MIXER
SH3 26012259001 SHIELD, GPS/BT
SH4 26012247001 SHIELD, 2ND LO
SH5 26012255001 SHIELD, ALC1
SH6 26012248001 SHIELD, FGU
SH7 26012256001 SHIELD, DC
SH8 26012249001 SHIELD, TXFE
SH9 26012257001 SHIELD, RXFE
T506M21 2575851B01 RF TRANSFORMER
BALUN
T507M21 2575851B02 RF TRANSFORMER
BALUN
U1101M11 5188032U43 IC,SENSING CIR-
CUIT,INA138,SM,SOT-23/
5,1PER PKG
U1103M11 5185070Y01 IC TEMPERATURE SEN-
SOR PB-FREE
U1104M11 5185941F56 IC SINGLE LV LP OP
AMPLIFIER
U1105M11 5180390L83 IC,CNTLR,,,SM,,1PER PKG
U1106M11 5175772B05 PRECISION RF DETEC-
TOR
U1112M11 5175772B04 1 DB LSB GAAS MMIC
ATTENUATOR
U1113M11 5185941F56 IC SINGLE LV LP OP
AMPLIFIER
U1114M11 5185941F56 IC SINGLE LV LP OP
AMPLIFIER
Ref. Des. Part Number Description
U1119M11 5109522E94 2 INPUT AND GATE IN
NANO PACKAGE (C87)
U1121M11 5114000B52 IC,XOR,LOGIC LEVEL
SHIFTER,1PER
PKG,SM,SOT-353,PB-FREE
U1125M11 5175206H01 QUAD 12-BIT DAC IC
U1126M11 5109817F77 IC COMPTR LM7275 5SC70
(D54)
U1127M11 5171779H01 SPDT ANALOG SWITCH
U1128M11 5188085K11 IC, SINGLE NAND GATE, 2-
INPUT, POSITIVE, 5
DSBGA, PB-FREE
U1129M11 5175143H01 WIDE SUPPLY RANGE OP
AMP
U1130M11 5175143H01 WIDE SUPPLY RANGE OP
AMP
U1131M11 5109817F77 IC COMPTR LM7275 5SC70
(D54)
U1132M11 5114007M28 IC,F-F/D,1PER
PKG,17SZ74,N-
I,SM,SOIC8,PB-FREE
U1133M11 5171779H01 SPDT ANALOG SWITCH
U1136M11 5109522E94 2 INPUT AND GATE IN
NANO PACKAGE (C87)
U1137M11 5164852H16 IC TRANSCEIVER W/
LEVEL TRANSLATION
U1138M11 5164852H16 IC TRANSCEIVER W/
LEVEL TRANSLATION
U1139M11 5164852H16 IC TRANSCEIVER W/
LEVEL TRANSLATION
U1141M11 5185941F56 IC SINGLE LV LP OP
AMPLIFIER
U1142M11 5185941F56 IC SINGLE LV LP OP
AMPLIFIER
U1143M11 5185941F56 IC SINGLE LV LP OP
AMPLIFIER
U1144M11 5171779H01 SPDT ANALOG SWITCH
U1146M11 5109522E93 2 INPUT OR GATE IN
NANO PACKAGE (C87)
U1147M11 5109522E94 2 INPUT AND GATE IN
NANO PACKAGE (C87)
Ref. Des. Part Number Description
