Motorola APX 3000

8-166 Schematics, Boards Overlays, and Parts Lists: Main Board Block: VHF (84012512001_A)
U1148M11 5185941F56 IC SINGLE LV LP OP
AMPLIFIER
U1149M11 5109522E93 2 INPUT OR GATE IN
NANO PACKAGE (C87)
U1150M11 51009381001 LOW DROPOUT VOLTAGE
REFERENCE
U1301M3 51007377001 IC, XCVR, BLUETOOTH,
GPS, FM RX, FM TX
U1304M3 51007599001 AMP,20.0DB,1.58GHZMIN,1
.58GHZMAX,SLCN GER-
MANIUM GPS LOW NOISE
AM
U1305M3 5187344N09 LOW NOISE, 100MA LIN-
EAR REGULATOR 2.8V
U1334M3 5102836C11 IC,ANLG
SW,,FSA4157,SM,,,,SPDT,,
PB FREE
U1335M3 5102836C11 IC,ANLG
SW,,FSA4157,SM,,,,SPDT,,
PB FREE
U200M12 5188493T01 IC,VREG/
SWG,LP2989,SM,MINI SO-8
HI PRCN REG 5V
U201M12 5175771A99 LOW NOISE, 100MA LIN-
EAR REGULATOR
U202M12 5175772B02 LINEAR REGULATOR
100MA 1.8V
U203M12 5175772B01 LINEAR VOLTAGE REGU-
LATOR 350MA
U2101M2 5109522E84 IC DUAL SCHMITT TRIG
MICRO PAK
U2102M2 5109522E84 IC DUAL SCHMITT TRIG
MICRO PAK
U2202M2 5164852H47 IC, I2C LEVEL TRANSLA-
TOR
U2205M2 5188682Y01 IC, RGB LED DRIVER, I2C
CONTORL, LLP PACKAGE
U2402M3 51002923001 IC,LNR V REGLTR,3.3V
LP2989,NOPB
U2403M3 51009735001 IC, RCVR, ONE-CHAN,
QFN, LF WAKE-UP
U2406M3 5164852H16 IC TRANSCEIVER W/
LEVEL TRANSLATION
Ref. Des. Part Number Description
U2407M3 5164852H16 IC TRANSCEIVER W/
LEVEL TRANSLATION
U2408M3 5164852H16 IC TRANSCEIVER W/
LEVEL TRANSLATION
U2409M3 5164852H16 IC TRANSCEIVER W/
LEVEL TRANSLATION
U2410M3 5164852H16 IC TRANSCEIVER W/
LEVEL TRANSLATION
U2411M3 5175856M01 DUAL INVERTER
U2412M3 5114007M45 IC,NOR,1PER PKG,SOT-
353,PB-FREE
U2413M3 51007645001 IC,SDRAM,128MBIT,8MX16
,7.5NS, SCRND
U2414M3 5164852H16 IC TRANSCEIVER W/
LEVEL TRANSLATION
U2415M3 51009372001 IC MICROCONTROLLER
AT32UC3A0512
U2416M3 51009669001 IC, ACCELEROMETER,
MOTION SENSOR
U2473M3 5164852H16 IC TRANSCEIVER W/
LEVEL TRANSLATION
U2478M3 5164852H16 IC TRANSCEIVER W/
LEVEL TRANSLATION
U2510M6 5185912Y03 IC,CRYPTOGRAPHIC PRO-
CESSOR
U2525M6 5171339H01 MICROPOWER VOLTAGE
REGULATOR
U2526M6 5171988H01 CMOS COMPARATOR
U2701M13 5103535B53 IC,INVTR,DL,NC7WZ04L6X
,2PER PKG,SC70
U2702M13 5185941F45 ATTEN,VAR,14.4DBMIN,15.
6DBMAX,0-2000 MHZ-
FREQ,50OHM,PCMT,,SOT
U304M20 4885316E32 TRANSISTOR, RF
U3238M22 5171972L01 SP3T RF SWITCH
U4001M2 5164852H47 IC, I2C LEVEL TRANSLA-
TOR
U4003M2 5188691V01 IC,MUX/
DEMUX,,NC7SB3157P6X,S
M,SC70-6,1PER
PKG,,BUS,,PB FREE
Ref. Des. Part Number Description
U4004M2 5116783H01 SN74LVC2G66 ANALOG
SWITCH
U507M21 5164015H81 IC,MXR,DBL BAL GIL-
BERT,CELL,,,SM
U601M19 5102495J14 IC,IF,,IF DIGITILIZING SUB-
SYSTEM IC,AD9864,QFN
U602M19 4885316E32 TRANSISTOR, RF
U603M19 5109522E84 IC DUAL SCHMITT TRIG
MICRO PAK
U604M19 5109522E84 IC DUAL SCHMITT TRIG
MICRO PAK
U605M19 5164852H16 IC TRANSCEIVER W/
LEVEL TRANSLATION
U606M19 5164852H16 IC TRANSCEIVER W/
LEVEL TRANSLATION
U607M19 5186311J24 IC,BFR,1BITS,NC7SZ125,A
CTIVE HIGH,B
U6101M6 0180706J18 PROGRAMMED CPLD
U6102M6 5188691V01 IC,MUX/
DEMUX,,NC7SB3157P6X,S
M,SC70-6,1PER
PKG,,BUS,,PB FREE
U6103M6 5175114H01 SINGLE AND GATE
MICROPAK
U6104M6 5175114H01 SINGLE AND GATE
MICROPAK
U6105M6 5175114H01 SINGLE AND GATE
MICROPAK
U6201M6 5185941F26 IC,COMPTR,LMV7219,NOP
B
U6301M6 51012031001 32MB DIE SHRINK DDR
SDRAM IC
U6302M6 5102495J13 IC,MICROP,P1710ZZGE,BG
A,,,12MHZ,32BITS
U6304M6 0105955U25 ASSY,IC,BGA SPEC PROG,
FLASH MEMORY
U6402M6 5115453H01 RAIL TO RAIL OUTPUT, 8
PIN BGA
U6404M6 5175772B38 IC ANALOG TEMPERA-
TURE SENSOR
Ref. Des. Part Number Description
U6405M6 5188348V06 IC,AUDIO
CODEC,SM,,AUDIO
CODEC
U6408M6 5188521T01 IC,VREF,SM,SOT23,1PER
PKG,.5%,1.25 TO
13.75,PRCN BANDGAP
ADJUS
U6409M6 51009000001 NANOPOWER, 1.8V,
SOT23 COMPARATOR
U6501M6 5185143E77 IC, MAKO ASIC, CMOS
PWR MGMT
U6502M6 4871987H01 LOW FREQUENCY TRAN-
SISTOR
U6503M6 5171674H01 OP AMP
U6504M6 5171682H01 800MA BUCK REGULATOR
U6505M6 5189631P01 IC,SYNC STEP-DOWN
CONV
U6506M6 5184790Y04 IC,400MA ADJ VREG
LDO,SOT23
U6507M6 5171682H01 800MA BUCK REGULATOR
U6508M6 51009366001 500MA LOW DROPOUT
CMOS LINEAR REG.
U6509M6 5175114H01 SINGLE AND GATE
MICROPAK
U6510M6 5114007A47 IC,OR,17SZ32,1PER
PKG,SOT-353,PB FREE
U6511M6 5171339H01 MICROPOWER VOLTAGE
REGULATOR
U6601M6 5175114H01 SINGLE AND GATE
MICROPAK
U702M7 5164015H28 IC,TRIDENT,INTEG
SYNTH,RX/TX BSBND
U738M7 5171972L01 SP3T RF SWITCH
U746M7 4805218N63 RF TRANS SOT 323
BFQ67W
U901M16 5175143H01 WIDE SUPPLY RANGE OP
AMP
U902M16 51012101001 VHF/UHF/800/900 MHZ
LDMOS DRIVER IC
VR101M12 4813977M29 DIODE,VREF,MBZ5250,SM,
SOT-23,20V,.225W,ZEN
Ref. Des. Part Number Description
