Motorola APX 3000

Schematics, Boards Overlays, and Parts Lists: Main Board Block: VHF (84012512001_A) 8-167
VR200M12 4813977M29 DIODE,VREF,MBZ5250,SM,
SOT-23,20V,.225W,ZEN
VR601M19 4805656W87 DIODE,VCTR, @
15V,1SV279,,SOD-523/SC-
79
VR602M19 4805656W87 DIODE,VCTR, @
15V,1SV279,,SOD-523/SC-
79
Y1304M3 48014600001 OSC,TCXO,26.0
Y2475M3 48009319001 SMD CRYSTAL OSCILLA-
TOR DS0211AR
Y6501M6 93012044001 CRYSTAL UNIT SMD
5.0X3.2 24.576MHZ
Y6502M6 4809995L05 XTAL QUARTZ 32.768KHZ
CC4V-T1
Y6601M6 4802582S85 RESON,QRTZ,12MHZ,TOL
ERANCE10PPM,STABILITY
15PPM,,SM,,FUND,,LO
Y701M7 4871886H01 16.8 MHZ VCTXO .8PPM
Ref. Des. Part Number Description
