Schematics, Boards Overlays, and Parts Lists: Main Board Block: UHF2 (84012616001) 8-201

C1304M3 2113944A07 CAP,CHIP,1.8PF,.25PF+/-

,50V-DC,0402,C0G,-55DEG

CMIN,125DEG CMA

C1305M3 2113944A27 CAP,CHIP,15PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,P

C1306M3 2187893N01 CAP,CER,1UF,20PF+/-

,+20%,-20%,6.3V-

DC,0402,+/-15%,-55DEG

CMIN,85

C1307M3 2113944A26 CAP,CHIP,12PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,P

C1308M3 2113945A09 CAP,CHIP,1000PF,+10%,-

10%,50V-DC,0402,X7R,-

55DEG CMIN,125DEG CM

C1309M3 2113944A26 CAP,CHIP,12PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,P

C1310M3 2187893N01 CAP,CER,1UF,20PF+/-

,+20%,-20%,6.3V-

DC,0402,+/-15%,-55DEG

CMIN,85

C1311M3 2113956A51 CAP,FXD,1UF,+10%,-

10%,6.3V-DC,0402,X5R,-

55DEG CMIN,85DEG

CMAX,P

C1312M3 2113956A51 CAP,FXD,1UF,+10%,-

10%,6.3V-DC,0402,X5R,-

55DEG CMIN,85DEG

CMAX,P

C1313M3 2187893N01 CAP,CER,1UF,20PF+/-

,+20%,-20%,6.3V-

DC,0402,+/-15%,-55DEG

CMIN,85

C1314M3 2113944M20 CAP,FXD,12PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,PB

C1315M3 2115153H02 CAP,CER

CHIP,.75PF,.1PF+/-,+.1%,-

.1%,50V-DC,C0G,CAP,

CERAMIC

Ref. Des. Part Number Description

C1316M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C1317M3 2188881Y12 CAP,CER

CHIP,1.8PF,.1PF+/-,16V-

DC,0402,NP0,-55DEG

CMIN,85DEG C

C1318M3 2115153H15 CAP,CER

CHIP,3.3PF,.1PF+/-,+.1%,-

.1%,50V-DC,0402,C0G,CAP,

CERA

C1319M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C1320M3 2113944A28 CAP,CHIP,18PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,P

C1321M3 2113944A29 CAP,CHIP,22PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,P

C1322M3 2113944A29 CAP,CHIP,22PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,P

C1323M3 2113944A29 CAP,CHIP,22PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,P

C1324M3 2115153H03 CAP,CER CHIP,1PF,.1PF+/-

,+.1%,-.1%,50V-

DC,0402,C0G

C1325M3 2113944A29 CAP,CHIP,22PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,P

C1326M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C1327M3 2113944A28 CAP,CHIP,18PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,P

Ref. Des. Part Number Description

C1328M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C1329M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C1330M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C1331M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C1332M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C1333M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C1334M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C1335M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C1336M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C1337M3 2113944A28 CAP,CHIP,18PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,P

C1339M3 2113944A08 CAP,CHIP,2PF,.25PF+/-

,50V-DC,0402,C0G,-55DEG

CMIN,125DEG CMAX

C1340M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

Ref. Des. Part Number Description

C1376M3 2113944A25 CAP,CHIP,10PF,.5PF+/-

,50V-DC,0402,C0G,-55DEG

CMIN,125DEG CMAX

C1601M16 2113944A40 CAP,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX

C1602M16 2113944M42 CAP,FXD,100PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,P

C1603M16 2113945L49 CAP,FXD,.01UF,+5%,-

5%,50V-DC,0603,X7R,-

55DEG CMIN,125DEG

CMAX,P

C1604M16 2113944A40 CAP,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX

C1605M16 2113945B02 CAP,CHIP,.01UF,+10%,-

10%,25V-DC,0402,X7R,-

55DEG CMIN,125DEG CMA

C1606M16 2113944A40 CAP,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX

C1607M16 2113944A40 CAP,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX

C1608M16 2113944M42 CAP,FXD,100PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,P

C1609M16 2113944A40 CAP,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX

C1610M16 2113944A23 CAP,CHIP,8.2PF,.5PF+/-

,50V-DC,0402,C0G,-55DEG

CMIN,125DEG CMAX

C1611M16 2113945L49 CAP,FXD,.01UF,+5%,-

5%,50V-DC,0603,X7R,-

55DEG CMIN,125DEG

CMAX,P

Ref. Des. Part Number Description
