8-202 Schematics, Boards Overlays, and Parts Lists: Main Board Block: UHF2 (84012616001)
C1612M16 2113944C45 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX
C1613M16 2113944A30 CAP,CHIP,27PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C1614M16 2113944A32 CAP,CHIP,39PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C1615M16 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C1616M16 2113944A32 CAP,CHIP,39PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C1617M16 2113945B02 CAP,CHIP,.01UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C1618M16 2113944M42 CAP,FXD,100PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C1619M16 2113945C02 CAP,CHIP,.01UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG CMA
C1620M16 2171741M06 CAP,CER CHIP,39PF,50V-
DC,HI Q CAP, 39 PF
C1621M16 2171741M10 CAP,CER,12PF,+5%,-
5%,100V-DC,CAP, CER
CHIP, 12PF, 100V-DC,
C1622M16 2113944M20 CAP,FXD,12PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C1623M16 2113944C08 CAP,CHIP,1.2PF,.25PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMA
C1624M16 2113944M22 CAP,FXD,15PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
Ref. Des. Part Number Description
C1625M16 2113944M42 CAP,FXD,100PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C1628M16 2113944M09 CAP,FXD,4.3PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C1629M16 2113945A12 CAP,CHIP,3300PF,+10%,-
10%,50V-DC,0402,X7R,-
55DEG CMIN,125DEG CM
C1630M16 2113945A12 CAP,CHIP,3300PF,+10%,-
10%,50V-DC,0402,X7R,-
55DEG CMIN,125DEG CM
C1633M16 2113944A33 CAP,CHIP,47PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C1634M16 2113945L49 CAP,FXD,.01UF,+5%,-
5%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX,P
C1803M17 2113944C23 CAP,CHIP,5.1PF,.5PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C1804M17 2113944C17 CAP,CHIP,3PF,.25PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C1807M17 2113944C26 CAP,CHIP,6.8PF,.5PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C1820M17 2113944C18 CAP,CHIP,3.3PF,.25PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMA
C1821M17 2113944C27 CAP,CHIP,7.5PF,.5PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C1822M17 2113944C45 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX
C1826M17 2113944C12 CAP,CHIP,1.8PF,.25PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMA
C1827M17 2113944C18 CAP,CHIP,3.3PF,.25PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMA
Ref. Des. Part Number Description
C1900M20 2115153H25 CAP,CERAMIC
CHIP,8.2PF,.1PF+/-,+.1%,-
.1%,50V-DC,0402,C0G,CAP,
C1901M20 2115153H57 CAP,CERAMIC
CHIP,100PF,+1%,-1%,50V-
DC,0402,C0G,CAP,
CERAMIC,
C1903M20 2115153H28 CAP,CER CHIP,4PF,.1PF+/-
,+.1%,-.1%,50V-
DC,0402,C0G,CAP,
CERAMI
C1920M20 2113946D07 CAP,CHIP,4.7UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C1922M20 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C1923M20 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C1924M20 2113946D07 CAP,CHIP,4.7UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C1925M20 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C1926M20 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C1928M20 2115153H15 CAP,CER
CHIP,3.3PF,.1PF+/-,+.1%,-
.1%,50V-DC,0402,C0G,CAP,
CERA
C1929M20 2115153H19 CAP,FXD,4.7PF,.1PF+/-
,+.1%,-.1%,50V-
DC,0402,C0G
C1930M20 2115153H41 CAP,FXD,22PF,+1%,-
1%,50V-DC,0402,C0G,CAP,
CERAMIC, COG
C1931M20 2115153H54 CAP,CER CHIP,75PF,50V-
DC,0402,C0G
Ref. Des. Part Number Description
C1932M20 2115153H41 CAP,FXD,22PF,+1%,-
1%,50V-DC,0402,C0G,CAP,
CERAMIC, COG
C1935M20 2115153H13 CAP,FXD,2.7PF,.1PF+/-
,+3.7%,-3.7%,50V-
DC,0402,C0G,CAP,
CERAMIC
C1936M20 2115153H26 CAP,CER
CHIP,9.1PF,.1PF+/-,+.1%,-
.1%,50V-DC,0402,C0G,CAP,
CERA
C1938M20 2115153H16 CAP,CERAMIC
CHIP,3.6PF,.1PF+/-,+.1%,-
.1%,50V-DC,0402,C0G,CAP,
C1939M20 2115153H13 CAP,FXD,2.7PF,.1PF+/-
,+3.7%,-3.7%,50V-
DC,0402,C0G,CAP,
CERAMIC
C1940M20 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C1942M20 2115153H37 CAP,FXD,15PF,.15PF+/-
,+1%,-1%,50V-
DC,0402,C0G,CAP,
CERAMIC, CO
C1952M20 2115153H19 CAP,FXD,4.7PF,.1PF+/-
,+.1%,-.1%,50V-
DC,0402,C0G
C1953M20 2115153H15 CAP,CER
CHIP,3.3PF,.1PF+/-,+.1%,-
.1%,50V-DC,0402,C0G,CAP,
CERA
C1954M20 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C1955M20 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C1956M20 2115153H15 CAP,CER
CHIP,3.3PF,.1PF+/-,+.1%,-
.1%,50V-DC,0402,C0G,CAP,
CERA
C1957M20 2115153H29 CAP,FXD,5PF,.1PF+/-,50V-
DC,0402,C0G
Ref. Des. Part Number Description
To Next Page
