Schematics, Boards Overlays, and Parts Lists: Main Board Block: UHF2 (84012616001) 8-203
C1958M20 2115153H35 CAP,CERAMIC
CHIP,12PF,+1%,-1%,50V-
DC,0402,C0G,CAP,
CERAMIC, C
C1959M20 2115153H13 CAP,FXD,2.7PF,.1PF+/-
,+3.7%,-3.7%,50V-
DC,0402,C0G,CAP,
CERAMIC
C1960M20 2115153H19 CAP,FXD,4.7PF,.1PF+/-
,+.1%,-.1%,50V-
DC,0402,C0G
C1961M20 2115153H13 CAP,FXD,2.7PF,.1PF+/-
,+3.7%,-3.7%,50V-
DC,0402,C0G,CAP,
CERAMIC
C1963M20 2115153H29 CAP,FXD,5PF,.1PF+/-,50V-
DC,0402,C0G
C1964M20 2115153H15 CAP,CER
CHIP,3.3PF,.1PF+/-,+.1%,-
.1%,50V-DC,0402,C0G,CAP,
CERA
C1970M20 2115153H12 CAP,CERAMIC
CHIP,2.4PF,.1PF+/-,+.1%,-
.1%,50V-DC,0402,C0G,CAP,
C1971M20 2115153H07 CAP,FXD,1.5PF,.1PF+/-
,+6.67%,-6.67%,50V-
DC,0402,C0G
C200M12 2113945B02 CAP,CHIP,.01UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C201M12 21012118001 CAP,FXD,1UF,+10%,-
10%,25V-
DC,X7R,CAP,FXD,1UF,10%,
25V-DC,X7R
C202M12 21012118001 CAP,FXD,1UF,+10%,-
10%,25V-
DC,X7R,CAP,FXD,1UF,10%,
25V-DC,X7R
C203M12 21012118001 CAP,FXD,1UF,+10%,-
10%,25V-
DC,X7R,CAP,FXD,1UF,10%,
25V-DC,X7R
C204M12 2113955D35 CAP,FXD,4.7UF,+10%,-
10%,16V-DC,1206,X7R,-
55DEG CMIN,125DEG
CMAX
Ref. Des. Part Number Description
C205M12 2113955D35 CAP,FXD,4.7UF,+10%,-
10%,16V-DC,1206,X7R,-
55DEG CMIN,125DEG
CMAX
C206M12 2113945B02 CAP,CHIP,.01UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C207M12 2113956B91 CAP,FXD,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,PB
C208M12 2113956B91 CAP,FXD,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,PB
C209M12 2113956B91 CAP,FXD,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,PB
C2104M2 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C210M12 2113956B91 CAP,FXD,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,PB
C2114M2 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2115M2 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C212M12 2113946D07 CAP,CHIP,4.7UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C213M12 2113944A46 CAP,CHIP,330PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C214M12 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
Ref. Des. Part Number Description
C215M12 2113944A46 CAP,CHIP,330PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C216M12 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C217M12 2113956B91 CAP,FXD,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,PB
C2201M2 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2202M2 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2203M2 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2223M2 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C2224M2 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C2225M2 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2226M2 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C2227M2 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C2228M2 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
Ref. Des. Part Number Description
C2229M2 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C2331M2 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C2332M2 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C2333M2 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C2334M2 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C2335M2 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2336M2 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2337M2 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C2338M2 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C2339M2 2113945A05 CAP,CHIP,470PF,+10%,-
10%,50V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C2340M2 2113945A05 CAP,CHIP,470PF,+10%,-
10%,50V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C2341M2 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
Ref. Des. Part Number Description
