Motorola APX 3000

Schematics, Boards Overlays, and Parts Lists: Main Board Block: UHF2 (84012616001) 8-211
C731M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C732M7 2113944A32 CAP,CHIP,39PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C733M7 2113945A09 CAP,CHIP,1000PF,+10%,-
10%,50V-DC,0402,X7R,-
55DEG CMIN,125DEG CM
C734M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C735M7 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C736M7 2113945B02 CAP,CHIP,.01UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C737M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C738M7 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C739M7 2113944A17 CAP,CHIP,4.7PF,.25PF+/-
,50V-DC,0402,C0G,-55DEG
CMIN,125DEG CMA
C740M7 2113944A44 CAP,CHIP,220PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C741M7 2115153H15 CAP,CER
CHIP,3.3PF,.1PF+/-,+.1%,-
.1%,50V-DC,0402,C0G,CAP,
CERA
C742M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
Ref. Des. Part Number Description
C743M7 2113946B06 CAP,CHIP,.22UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C744M7 2113955D37 CAP,FXD,10UF,+10%,-
10%,16V-DC,1206,X7R,-
55DEG CMIN,125DEG
CMAX
C749M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C750M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C751M7 2113945A09 CAP,CHIP,1000PF,+10%,-
10%,50V-DC,0402,X7R,-
55DEG CMIN,125DEG CM
C752M7 2113944A43 CAP,CHIP,180PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C753M7 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C754M7 2113944A34 CAP,CHIP,56PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C756M7 2113955D37 CAP,FXD,10UF,+10%,-
10%,16V-DC,1206,X7R,-
55DEG CMIN,125DEG
CMAX
C757M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C760M7 2113944A44 CAP,CHIP,220PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C764M7 2113946B06 CAP,CHIP,.22UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
Ref. Des. Part Number Description
C768M7 2115153H17 CAP,FXD,3.9PF,.1PF+/-
,50V-DC,0402,C0G,CAP,
CERAMIC, COG
C770M7 2113944A44 CAP,CHIP,220PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C772M7 2113945A09 CAP,CHIP,1000PF,+10%,-
10%,50V-DC,0402,X7R,-
55DEG CMIN,125DEG CM
C773M7 2113944A33 CAP,CHIP,47PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C777M7 2113944A44 CAP,CHIP,220PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C779M7 2115153H24 CAP,CER
CHIP,7.5PF,.1PF+/-,+.1%,-
.1%,50V-DC,0402,C0G,CAP,
CERA
C780M7 2113944A33 CAP,CHIP,47PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C781M7 2113944A44 CAP,CHIP,220PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C786M7 2113944A44 CAP,CHIP,220PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C803M7 2113944A44 CAP,CHIP,220PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C813M7 2113944A63 CAP,FXD,1PF,.25PF+/-,50V-
DC,0402,C0G,-55DEG
CMIN,125DEG CMAX,P
C816M7 2113944A35 CAP,CHIP,62PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
Ref. Des. Part Number Description
C817M7 2113944A44 CAP,CHIP,220PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C819M7 2113944A44 CAP,CHIP,220PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C823M7 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C824M7 2113944A44 CAP,CHIP,220PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
CODEC_G
PIO1M6
TPSM0_50 TEST POINT .020 DIA
D1970M20 4813974A19 DIODE
ARRAY,MXR,SM,SOT-
323,7V,.2W,SHTK,2,PB-
FREE
D1M2 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
D200M12 4813978A19 DIODE,RECT,MBR120,SM,
SOD-123,1A,20V,SHTK,PB-
FREE
D2101M2 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
D2304M2 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
D2305M2 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
D2306M2 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
D2307M2 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
D2521M6 4871785H01 DIODE,SWG,BAS116LT1G,
SOT-23/SC-59,SOT-
23,200MA,75V,.225W,SWG
DI
D2601M13 4813974A19 DIODE
ARRAY,MXR,SM,SOT-
323,7V,.2W,SHTK,2,PB-
FREE
Ref. Des. Part Number Description
