8-212 Schematics, Boards Overlays, and Parts Lists: Main Board Block: UHF2 (84012616001)
D2602M13 4815897H01 DIODE,PIN,UPP9401E,SM,
DO-
216,50A,50V,2.5W,POWER-
MITE
D2603M13 4815897H01 DIODE,PIN,UPP9401E,SM,
DO-
216,50A,50V,2.5W,POWER-
MITE
D2M2 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
D3102M22 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/SC-
79,SOD-523/SC-79
D3103M22 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/SC-
79,SOD-523/SC-79
D3104M22 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/SC-
79,SOD-523/SC-79
D3105M22 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/SC-
79,SOD-523/SC-79
D3135M22 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/SC-
79,SOD-523/SC-79
D3136M22 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/SC-
79,SOD-523/SC-79
D3137M22 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/SC-
79,SOD-523/SC-79
D3138M22 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/SC-
79,SOD-523/SC-79
D3M2 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
D4001M2 4813978A25 DIODE,SWG,BAT54,SM,SO
D-323/SC-
76,200MA,30V,.2W,SHTK,P
B-FREE, W18
D6101M6 4813978A25 DIODE,SWG,BAT54,SM,SO
D-323/SC-
76,200MA,30V,.2W,SHTK,P
B-FREE, W18
Ref. Des. Part Number Description
D6401M6 4813978A25 DIODE,SWG,BAT54,SM,SO
D-323/SC-
76,200MA,30V,.2W,SHTK,P
B-FREE, W18
D6501M6 4813978A25 DIODE,SWG,BAT54,SM,SO
D-323/SC-
76,200MA,30V,.2W,SHTK,P
B-FREE, W18
D722M7 4815011H01 DIODE,SWG,SM,300MA,80
V,T RP
D723M7 4815011H01 DIODE,SWG,SM,300MA,80
V,T RP
E1101M11 2405688Z01 IDCTR,BEAD,FERR BEAD
E1921M20 2471132D14 IDCTR,25%,200MA,.6OHM,
FERR,SM,0402,IDCTR,FXD
,470OHM,200M
E201M12 7686949J14 FLTR,FERRITE
BEAD,2A,SM,0805,CHIP,22
0OHM
E2201M2 7685268E01 FLTR,FERRITE
BEAD,650MA,SM,0402,CHI
P, 8 0O H M
E2202M2 PT80LVLA03 SPARK GAP 2PIN
E2203M2 PT80LVLA03 SPARK GAP 2PIN
E2204M2 PT80LVLA03 SPARK GAP 2PIN
E2205M2 PT80LVLA03 SPARK GAP 2PIN
E2206M2 7685268E01 FLTR,FERRITE
BEAD,650MA,SM,0402,CHI
P, 8 0O H M
E2207M2 7685268E01 FLTR,FERRITE
BEAD,650MA,SM,0402,CHI
P, 8 0O H M
E2247M2 7685268E01 FLTR,FERRITE
BEAD,650MA,SM,0402,CHI
P, 8 0O H M
E2248M2 7685268E01 FLTR,FERRITE
BEAD,650MA,SM,0402,CHI
P, 8 0O H M
E2249M2 7685268E01 FLTR,FERRITE
BEAD,650MA,SM,0402,CHI
P, 8 0O H M
E2312M2 PT80LVLA03 SPARK GAP 2PIN
E2313M2 PT80LVLA03 SPARK GAP 2PIN
Ref. Des. Part Number Description
E2314M2 PT80LVLA03 SPARK GAP 2PIN
E2315M2 PT80LVLA03 SPARK GAP 2PIN
E2316M2 PT80LVLA03 SPARK GAP 2PIN
E2317M2 PT80LVLA03 SPARK GAP 2PIN
E2318M2 PT80LVLA03 SPARK GAP 2PIN
E2319M2 PT80LVLA03 SPARK GAP 2PIN
E2320M2 PT80LVLA03 SPARK GAP 2PIN
E2321M2 PT80LVLA03 SPARK GAP 2PIN
E601M19 2471132D14 IDCTR,25%,200MA,.6OHM,
FERR,SM,0402,IDCTR,FXD
,470OHM,200M
E602M19 2471132D14 IDCTR,25%,200MA,.6OHM,
FERR,SM,0402,IDCTR,FXD
,470OHM,200M
E603M19 2471132D14 IDCTR,25%,200MA,.6OHM,
FERR,SM,0402,IDCTR,FXD
,470OHM,200M
E604M19 2471132D14 IDCTR,25%,200MA,.6OHM,
FERR,SM,0402,IDCTR,FXD
,470OHM,200M
E605M19 2471132D14 IDCTR,25%,200MA,.6OHM,
FERR,SM,0402,IDCTR,FXD
,470OHM,200M
E606M19 2471132D14 IDCTR,25%,200MA,.6OHM,
FERR,SM,0402,IDCTR,FXD
,470OHM,200M
E607M19 2471132D14 IDCTR,25%,200MA,.6OHM,
FERR,SM,0402,IDCTR,FXD
,470OHM,200M
E608M19 2471132D14 IDCTR,25%,200MA,.6OHM,
FERR,SM,0402,IDCTR,FXD
,470OHM,200M
E609M19 2471132D14 IDCTR,25%,200MA,.6OHM,
FERR,SM,0402,IDCTR,FXD
,470OHM,200M
E6501M6 2480067M02 FIXED INDUC-
TOR,FXD,200MA,.4OHM,F
ERR,0805,CHK RF CHIP
BE
E6502M6 2480067M02 FIXED INDUC-
TOR,FXD,200MA,.4OHM,F
ERR,0805,CHK RF CHIP
BE
Ref. Des. Part Number Description
ENC_JTA
GSEL0M6
TPSM0_50 TEST POINT .020 DIA
ENC_JTA
GSEL1M6
TPSM0_50 TEST POINT .020 DIA
ENC_UAR
T_RXM6
TPSM0_50 TEST POINT .020 DIA
ENC_UAR
T_TXM6
TPSM0_50 TEST POINT .020 DIA
F_BOOT_
RXM6
TPSM1_50 SINGLE PIN CONTACT
TEST POINT
F_BOOT_
TXM6
TPSM1_50 SINGLE PIN CONTACT
TEST POINT
F_GCAI_1
WIREM2
TPSM1_50 SINGLE PIN CONTACT
TEST POINT
F_GCAI_U
SB+M2
TPSM1_50 SINGLE PIN CONTACT
TEST POINT
F_GCAI_U
SB-M2
TPSM1_50 SINGLE PIN CONTACT
TEST POINT
F_GNDM6 TPSM1_50 SINGLE PIN CONTACT
TEST POINT
F_MPU_B
OOTM6
TPSM1_50 SINGLE PIN CONTACT
TEST POINT
F_UNSW_
B+M6
TPSM1_50 SINGLE PIN CONTACT
TEST POINT
F_VBUS2
M2
TPSM1_50 SINGLE PIN CONTACT
TEST POINT
F_VREF_1
.875VM2
TPSM1_50 SINGLE PIN CONTACT
TEST POINT
F200M12 6575834B01 FUSE,FST
BLW,2A,32V,FUSE SUR MT
FL1301M3 9102190J23 FLTR,SAW,BAND-
PASS,1.57542GHZ
NOM,SM,1.4X1.0MM,SMD,
PB-FREE
FL1302M3 9109674L58 BAND PASS FILTER
FL1303M3 9102190J23 FLTR,SAW,BAND-
PASS,1.57542GHZ
NOM,SM,1.4X1.0MM,SMD,
PB-FREE
FL502M21 91009300001 FLTR,BAND-
PASS,109.65MHZ NOM,FIL-
TER,MONOLITHIC
CRYSTAL,BAND
Ref. Des. Part Number Description
