Motorola APX 3000

8-214 Schematics, Boards Overlays, and Parts Lists: Main Board Block: UHF2 (84012616001)
L1936M20 2415429H01 IDCTR,WW,1.6NH,5%,700M
A,.03OHM,CER,SM,0603,C
HIP
L200M12 2571269C01 IDCTR,COIL,1.5UH,20%,2.9
A,.059OHM,FERR,SM,WW
PWR W18 COMP
L2601M13 24012026011 IDCTR,AW,16.6NH,2%,4.4A
,AIR,SM,ULTRA-MINIA-
TURE AIR CORE
L2602M13 2415429H40 IDCTR,WW,180NH,5%,240
MA,1.25OHM,CER,SM,0603
,CHIP
L2603M13 24010062004 IDCTR,RF,10NH,2%,1.3A,.0
6OHM,CER,4.7GHZ
SRF,SM,10NH, 0402
L2604M13 24010062004 IDCTR,RF,10NH,2%,1.3A,.0
6OHM,CER,4.7GHZ
SRF,SM,10NH, 0402
L3100M22 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
L3101M22 2414032F41 IDCTR,WW,390NH,10%,200
MA,1.5OHM,CER,40
Q,730MHZ SRF,SM,PB-F
L3102M22 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
L3106M22 2478057A23 IDCTR,18NH,2%,.066OHM,
CER,41 Q,3.3GHZ
SRF,PCMT,18 NH SUR
L3112M22 2415428H03 IDCTR,AW,3.85NH,2%,1.6A
,AIR,SM,AIR WOUND
IDCTR
L3119M22 2414032F41 IDCTR,WW,390NH,10%,200
MA,1.5OHM,CER,40
Q,730MHZ SRF,SM,PB-F
L3125M22 2414032F41 IDCTR,WW,390NH,10%,200
MA,1.5OHM,CER,40
Q,730MHZ SRF,SM,PB-F
L3126M22 2414032F41 IDCTR,WW,390NH,10%,200
MA,1.5OHM,CER,40
Q,730MHZ SRF,SM,PB-F
L3134M22 2414032F41 IDCTR,WW,390NH,10%,200
MA,1.5OHM,CER,40
Q,730MHZ SRF,SM,PB-F
Ref. Des. Part Number Description
L3139M22 2478057A26 IDCTR,24NH,2%,.074OHM,
CER,42 Q,2.95GHZ
SRF,PCMT,24 NH SUR
L3145M22 2471968L10 IDCTR,AW,9NH,2%,4A,.003
4OHM,AIR,5 TURNS,120
Q,4GHZ SRF,SM,9.
L3150M22 2414032F41 IDCTR,WW,390NH,10%,200
MA,1.5OHM,CER,40
Q,730MHZ SRF,SM,PB-F
L3158M22 2414032F41 IDCTR,WW,390NH,10%,200
MA,1.5OHM,CER,40
Q,730MHZ SRF,SM,PB-F
L3159M22 2414032F39 IDCTR,WW,270NH,10%,280
MA,1OHM,CER,40
Q,800MHZ SRF,SM,PB-FRE
L500M21 2415429H43 IDCTR,WW,220NH,5%,300
MA,2.1OHM,CER,SM,0603,
CHIP
L501M21 24012011026 IDCTR,WW,18NH,2%,900M
A,.12OHM,CER,3.55GHZ
SRF,SM,0402 HI Q
L503M21 2414017N24 IDCTR,CHIP,100NH,5%,300
MA,2OHM,CER,15
Q,700MHZ SRF,SM,0603,P
L504M21 2478057A51 CHIP INDUC-
TOR,RF,270NH,2%,SM,060
3 HI Q CHIP IDCTR
L513M21 2415429H21 IDCTR,WW,22NH,5%,700M
A,.19OHM,CER,SM,0603,C
HIP
L550M21 24009331029 IDCTR,WW,15NH,5%,600M
A,SM,IDCTR,WW,15NH,5%,
600MA,SM,060
L601M19 2415429H43 IDCTR,WW,220NH,5%,300
MA,2.1OHM,CER,SM,0603,
CHIP
L602M19 2466505A01 CHIP INDUC-
TOR,CHIP,10UH,5%,150MA
,FERR,0 AWG,SM,PB-FREE
L603M19 2466505A01 CHIP INDUC-
TOR,CHIP,10UH,5%,150MA
,FERR,0 AWG,SM,PB-FREE
L604M19 2414032D16 IDCTR,WW,120NH,5%,800
MA,.26OHM,CER,42
Q,1GHZ SRF,SM,PB-FREE
Ref. Des. Part Number Description
L605M19 2414017Q54 IDCTR,FXD,3.9UH,10%,30
MA,.9OHM,FERR,45
Q,38MHZ SRF,SM,0805,P
L611M19 2414032F39 IDCTR,WW,270NH,10%,280
MA,1OHM,CER,40
Q,800MHZ SRF,SM,PB-FRE
L6502M6 2471678H01 IDCTR,10UH,20%,FERR,10
UH INDCUTOR
L6504M6 24009268001 IDCTR,PWR,10UH,20%,1.3
A,FERR,SM,10UH 2.1A
SHLD IDCTR
L6505M6 2471678H01 IDCTR,10UH,20%,FERR,10
UH INDCUTOR
L701M7 2415429H47 IDCTR,WW,390NH,5%,100
MA,CER,SM,CHIP
L702M7 2415429H47 IDCTR,WW,390NH,5%,100
MA,CER,SM,CHIP
L709M7 2475122C26 IDCTR,12UH,5%,300MA,.07
OHM,CER,4
TURNS,SM,IND, MULTI-
LAYE
L720M7 24012100001 IDCTR,FXD,2.2UH,10%,15
MA,35 Q,50MHZ
SRF,SM,IDCTR,2.2UH,1
L727M7 24012100001 IDCTR,FXD,2.2UH,10%,15
MA,35 Q,50MHZ
SRF,SM,IDCTR,2.2UH,1
L728M7 2415429H47 IDCTR,WW,390NH,5%,100
MA,CER,SM,CHIP
L729M7 2415427H24 IDCTR,WW,13NH,5%,440M
A,CER,SM,0402,CHIP
L733M7 24012100001 IDCTR,FXD,2.2UH,10%,15
MA,35 Q,50MHZ
SRF,SM,IDCTR,2.2UH,1
L735M7 24012100001 IDCTR,FXD,2.2UH,10%,15
MA,35 Q,50MHZ
SRF,SM,IDCTR,2.2UH,1
L738M7 24012100001 IDCTR,FXD,2.2UH,10%,15
MA,35 Q,50MHZ
SRF,SM,IDCTR,2.2UH,1
L739M7 2415429H47 IDCTR,WW,390NH,5%,100
MA,CER,SM,CHIP
Ref. Des. Part Number Description
L741M7 24012100001 IDCTR,FXD,2.2UH,10%,15
MA,35 Q,50MHZ
SRF,SM,IDCTR,2.2UH,1
L753M7 2415347H06 IDCTR,WW,2.2UH,5%,320M
A,1.2OHM,CER,SM,IDCTR,
2200NH
L755M7 2415429H47 IDCTR,WW,390NH,5%,100
MA,CER,SM,CHIP
L758M7 2415429H47 IDCTR,WW,390NH,5%,100
MA,CER,SM,CHIP
L759M7 2415429H47 IDCTR,WW,390NH,5%,100
MA,CER,SM,CHIP
L765M7 2415427H28 IDCTR,WW,18NH,5%,420M
A,CER,SM,0402,CHIP
L775M7 2415429H47 IDCTR,WW,390NH,5%,100
MA,CER,SM,CHIP
L778M7 2415427H24 IDCTR,WW,13NH,5%,440M
A,CER,SM,0402,CHIP
M1 1171905B02 ADHES,WHT,WHT I SHAPE
UNDERFILM COR
M101M12 39012039001 CONN,CMPRSN,3CONT,ST
,CONNECTOR, BAT CON-
TACT, WW P
M1301M3 3987977Y04 CONT,CONN,1CONT,ANT
UNIV 4.5MM,UC 1.8
M1302M3 3987977Y04 CONT,CONN,1CONT,ANT
UNIV 4.5MM,UC 1.8
M2 1171905B02 ADHES,WHT,WHT I SHAPE
UNDERFILM COR
M2533M6 3987977Y04 CONT,CONN,1CONT,ANT
UNIV 4.5MM,UC 1.8
M6502M6 0985888K02 BATTERY CONNEC-
TOR,SKT,NI,LEAP
MAKO_AD
_TRIGM6
TPSM0_381 TEST POINT
MAKO_IN
T_MICMM
6
TPSM0_381 TEST POINT
MAKO_IN
T_MICPM6
TPSM0_381 TEST POINT
MAKO_IN
T_XM6
TPSM0_381 TEST POINT
Ref. Des. Part Number Description
