Motorola APX 3000

Schematics, Boards Overlays, and Parts Lists: Main Board Block: UHF2 (84012616001) 8-215
MAKO_RE
SET_XM6
TPSM0_381 TEST POINT
MIC_BIAS
M6
TPSM0_50 TEST POINT .020 DIA
MPU_IO_1
2M6
TPSM0_381 TEST POINT
OMAP_TE
MP_TPM6
TPSM0_50 TEST POINT .020 DIA
OMAP_VP
PM6
TPSM0_381 TEST POINT
Q1101M11 4813973A32 XSTR,BIP GP
SS,NPN,SM,SC-
70,SMT,50V,.202W,100MA,
PB-FREE
Q1103M11 4813970A59 XSTR,FET GP PWR,P-
CH,ENHN,SM,SOT-
23,20V,.4W,PB-FREE
Q1601M16 48012094001 XSTR,FET RF
POWER,SM,25V,MOD,XST
R,FET RF PWR, 135-
941MH
Q1920M20 4813973A32 XSTR,BIP GP
SS,NPN,SM,SC-
70,SMT,50V,.202W,100MA,
PB-FREE
Q1922M20 4813973M75 XSTR,BIP GP
SS,PNP,BC858,SOT-
563,SMT,-30V,.357W,-
100MA,100MHZ
Q201M12 4813970A59 XSTR,FET GP PWR,P-
CH,ENHN,SM,SOT-
23,20V,.4W,PB-FREE
Q202M12 4813973A32 XSTR,BIP GP
SS,NPN,SM,SC-
70,SMT,50V,.202W,100MA,
PB-FREE
Q2202M2 4815261H01 XSTR,BIP GP
SS,NPN,DTC114Y,SC-
59,SC-
59,SMT3,50V,100MA,250M
HZ
Q2537M6 4888795V06 XSTR,FET GP PWR,MOS-
FET,SM,SMT,20V,.25W,LEA
D-FREE
Ref. Des. Part Number Description
Q2547M6 4888795V06 XSTR,FET GP PWR,MOS-
FET,SM,SMT,20V,.25W,LEA
D-FREE
Q2601M13 4815055H01 XSTR,GEN PURPOSE
SMALL SIG,NPN AND
PNP,UMC5NT2G,SM,50V,10
0A
Q3123M22 4871915M01 XSTR,BIP RF SML
SGNL,NPN,SC-
75A,SMT,12V,.1W,100MA,4.
5GHZ,XST
Q3128M22 4815055H01 XSTR,GEN PURPOSE
SMALL SIG,NPN AND
PNP,UMC5NT2G,SM,50V,10
0A
Q3156M22 4871915M01 XSTR,BIP RF SML
SGNL,NPN,SC-
75A,SMT,12V,.1W,100MA,4.
5GHZ,XST
Q3161M22 4815055H01 XSTR,GEN PURPOSE
SMALL SIG,NPN AND
PNP,UMC5NT2G,SM,50V,10
0A
Q4001M2 4815261H01 XSTR,BIP GP
SS,NPN,DTC114Y,SC-
59,SC-
59,SMT3,50V,100MA,250M
HZ
Q601M19 4813973A04 XSTR,BIP GP
SS,NPN,TA13,SM,SOT-
23,SMT,30V,.225W,300MA,1
25MHZ,P
Q6101M6 4815261H01 XSTR,BIP GP
SS,NPN,DTC114Y,SC-
59,SC-
59,SMT3,50V,100MA,250M
HZ
Q6401M6 48012170001 XSTR,FET GP
PWR,N,SM,SMT,20V,.15W
Q6501M6 4813970A62 XSTR,FET GP PWR,MOS-
FET,P-CH,ENHN,CF,-
20V,1.3W,PB-FREE
Q6502M6 48012154001 XSTR,FET GP
PWR,P,SM,SMT,-
20V,.5W,FET
Ref. Des. Part Number Description
Q6504M6 4809579E77 XSTR,FET GP SS,MOS-
FET,N-
CH,SM,30V,1.2X1.2MM
PKG W18 COMP
Q6505M6 4813970A62 XSTR,FET GP PWR,MOS-
FET,P-CH,ENHN,CF,-
20V,1.3W,PB-FREE
Q6506M6 4809579E77 XSTR,FET GP SS,MOS-
FET,N-
CH,SM,30V,1.2X1.2MM
PKG W18 COMP
Q6507M6 48012170001 XSTR,FET GP
PWR,N,SM,SMT,20V,.15W
Q6508M6 48012154001 XSTR,FET GP
PWR,P,SM,SMT,-
20V,.5W,FET
Q731M7 4885061Y01 XSTR,BIP RF SMALL SIG-
NAL
Q745M7 4813973M75 XSTR,BIP GP
SS,PNP,BC858,SOT-
563,SMT,-30V,.357W,-
100MA,100MHZ
Q756M7 4805585Q32 XSTR,BIP RF SML
SGNL,NPN,NE662M04,SM,
SOT-343,3.3V,TRANSITO
Q767M7 4813973M75 XSTR,BIP GP
SS,PNP,BC858,SOT-
563,SMT,-30V,.357W,-
100MA,100MHZ
Q774M7 4805585Q32 XSTR,BIP RF SML
SGNL,NPN,NE662M04,SM,
SOT-343,3.3V,TRANSITO
Q785M7 4889394V04 XSTR,FET GEN PURPOSE
SMALL SIG,MOSFET,N-
CH,ENHN,SM,20V,.25W,P
R1101M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1102M11 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1103M11 6009259001 RES,SHUNT,.02OHM,.33W,
SMD,LOW RESISTANCE
THK FLM RES
R1104M11 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
Ref. Des. Part Number Description
R1105M11 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R1106M11 0613952Q21 RES,MF,6.8OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1107M11 0613952Q45 RES,MF,68OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1108M11 0613952N81 RES,MF,68.1KOHM,1%,.06
25W,SM,0402,200PPM/
CEL,PB-FREE
R1110M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1112M11 0613952Q42 RES,MF,51OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1114M11 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R1115M11 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R1116M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1117M11 0613952R22 RES,MF,75KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1121M11 0613952N47 RES,MF,30.1KOHM,1%,.06
25W,SM,0402,200PPM/
CEL,PB-FREE
R1122M11 0613952N85 RES,MF,75KOHM,1%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1124M11 0613952Q42 RES,MF,51OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1125M11 0613952R17 RES,MF,47000,5,.0625,SM,
0402,200,PB-FREE
R1126M11 0613952R08 RES,MF,20KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1127M11 0613952R08 RES,MF,20KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
