8-216 Schematics, Boards Overlays, and Parts Lists: Main Board Block: UHF2 (84012616001)
R1128M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1135M11 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1136M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1137M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1138M11 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1139M11 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1140M11 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1141M11 0613952R42 RES,MF,510KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1142M11 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1143M11 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1144M11 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1145M11 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1146M11 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1151M11 0613952R05 RES,MF,15KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1152M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
R1154M11 0613952N01 RES,MF,10KOHM,1%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1158M11 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1160M11 0613952R03 RES,MF,12000,5,.0625,SM,
0402,200,PB-FREE
R1162M11 0613952R29 RES,MF,150KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1163M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1164M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1165M11 0613952Q56 RES,MF,200OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1166M11 0613952Q56 RES,MF,200OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1167M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1168M11 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R1169M11 0613952P52 RES,MF,340KOHM,1%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1170M11 0613952N88 RES,MF,80.6KOHM,1%,.06
25W,SM,0402,200PPM/
CEL,PB-FREE
R1171M11 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1172M11 0613952Q89 RES,MF,4700,5,.0625,SM,0
402,200,PB-FREE
R1174M11 0613952N01 RES,MF,10KOHM,1%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1175M11 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
Ref. Des. Part Number Description
R1176M11 0613952M01 RES,MF,1KOHM,1%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1177M11 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1178M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1180M11 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1182M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1198M11 0613952J01 RES,MF,10KOHM,5%,.1W,S
M,0603,200PPM/CEL,PB-
FREE
R1202M11 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1301M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1302M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1303M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1304M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1305M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1306M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1307M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1308M3 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1309M3 0613952Q50 RES,MF,110OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1310M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1311M3 0613952Q50 RES,MF,110OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
R1312M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1313M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1314M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1315M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1316M3 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1317M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1318M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1319M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1320M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1321M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1322M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1323M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1324M3 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1325M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1326M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1327M3 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1328M3 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1329M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1330M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
Ref. Des. Part Number Description
