Motorola APX 3000

Schematics, Boards Overlays, and Parts Lists: Main Board Block: UHF2 (84012616001) 8-217
R1331M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1332M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1333M3 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1337M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1338M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1340M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1601M16 0613952Q96 RES,MF,9.1KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1602M16 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1603M16 0613952R23 RES,MF,82KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1604M16 0613952R13 RES,MF,33KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1605M16 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1606M16 0613952H53 RES,MF,150OHM,5%,.1W,S
M,0603,200PPM/CEL,PB-
FREE
R1651M16 0613952Q57 RES,MF,220OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1652M16 0613952Q57 RES,MF,220OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1653M16 0613952Q34 RES,MF,24OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1900M20 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
Ref. Des. Part Number Description
R1906M20 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1907M20 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1908M20 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1909M20 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1910M20 0613952Q96 RES,MF,9.1KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1911M20 0613952Q96 RES,MF,9.1KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1921M20 0613952R22 RES,MF,75KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1922M20 0613952R27 RES,MF,120KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1923M20 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1924M20 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1925M20 0613952Q11 RES,MF,2.7OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1935M20 0613952Q75 RES,MF,1.2KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1936M20 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1970M20 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R1972M20 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R1M2 0613952R17 RES,MF,47000,5,.0625,SM,
0402,200,PB-FREE
Ref. Des. Part Number Description
R2 0613952Y66 RES,MF,0OHM,5%,.05W,S
M,0201,,PB-FREE
R20 0613952Y66 RES,MF,0OHM,5%,.05W,S
M,0201,,PB-FREE
R200M12 0613952G67 RES,MF,0,1,.1,SM,0603,PB-
FREE
R201M12 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R202M12 0613952Q89 RES,MF,4700,5,.0625,SM,0
402,200,PB-FREE
R2104M2 0613952Q89 RES,MF,4700,5,.0625,SM,0
402,200,PB-FREE
R2105M2 0613952Q89 RES,MF,4700,5,.0625,SM,0
402,200,PB-FREE
R2106M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2107M2 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2109M2 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R2110M2 0613952Q33 RES,MF,22,5,.0625,SM,040
2,200,PB-FREE
R2111M2 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R2113M2 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R2114M2 0613952Q33 RES,MF,22,5,.0625,SM,040
2,200,PB-FREE
R2115M2 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R2116M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2117M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2118M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
R2120M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2197M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2198M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2199M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R21M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2201M2 0613952R32 RES,MF,200KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2204M2 0613952Q85 RES,MF,3.3KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2206M2 0613952Q85 RES,MF,3.3KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2207M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2235M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2244M2 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2245M2 0613952Q81 RES,MF,2200,5,.0625,SM,0
402,200,PB-FREE
R2246M2 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2254M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2255M2 0613952Q66 RES,MF,510OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2256M2 0613952Q66 RES,MF,510OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2257M2 0613952Q66 RES,MF,510OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
