Motorola APX 3000

Schematics, Boards Overlays, and Parts Lists: Main Board Block: UHF2 (84012616001) 8-223
R701M7 0613952Q64 RES,MF,430OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R702M7 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R703M7 0613952Q67 RES,MF,560OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R704M7 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R705M7 0613952Q71 RES,MF,820OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R706M7 0613952Q08 RES,MF,2OHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-
FREE
R707M7 0613952Q67 RES,MF,560OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R708M7 0613952Q45 RES,MF,68OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R709M7 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R710M7 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R711M7 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R721M7 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R722M7 0613952Q71 RES,MF,820OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R723M7 0613952Q79 RES,MF,1800,5,.0625,SM,0
402,200,PB-FREE
R728M7 0613952Q59 RES,MF,270OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R729M7 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
Ref. Des. Part Number Description
R730M7 0613952Q79 RES,MF,1800,5,.0625,SM,0
402,200,PB-FREE
R731M7 0613952Q86 RES,MF,3.6KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R736M7 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R741M7 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R742M7 0613952R23 RES,MF,82KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R743M7 0613952R17 RES,MF,47000,5,.0625,SM,
0402,200,PB-FREE
R744M7 0613952Q91 RES,MF,5600,5,.0625,SM,0
402,200,PB-FREE
R745M7 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R746M7 0613952Q36 RES,MF,30OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R747M7 0613952Q38 RES,MF,36OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R748M7 0613952Q47 RES,MF,82OHM,5%,.0625
W,SMD,0402,200PPM/
CEL,CER CHIP 82.0 OHM
5%
R751M7 0613952Q59 RES,MF,270OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R754M7 0613952Q69 RES,MF,680OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R757M7 0613952Q59 RES,MF,270OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R761M7 0613952Q23 RES,MF,8.2OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R762M7 0613952R08 RES,MF,20KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
R763M7 0613952R19 RES,MF,56KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R766M7 0613952Q92 RES,MF,6.2KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R769M7 0613952Q31 RES,MF,18OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R771M7 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R776M7 0613952Q67 RES,MF,560OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R785M7 0613952Q53 RES,MF,150OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R799M7 0613952Q53 RES,MF,150OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R809M7 0613952Q38 RES,MF,36OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R822M7 0613952Q55 RES,MF,180OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R823M7 0613952Q55 RES,MF,180OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
SH1 26012246001 SHLD,STL,SN PLT,SHIELD,
IF, APX CVT
SH10 26012250001 SHLD,STL,SN PLT,SHIELD,
ANTSWI, APX CVT
SH11 26012258001 SHLD,STL,SN PLT,SHIELD,
ABACUS, APX CVT
SH12 26012251001 SHLD,STL,SN PLT,SHIELD,
PAOP, APX CVT
SH13 26012260001 SHLD,STL,SN PLT,SHIELD,
DRIVER/PA, APX CVT
SH14 26012252001 SHLD,STL,SN PLT,SHIELD,
ALC/DC, APX CVT
SH15 26012261001 SHLD,STL,SN PLT,SHIELD,
VCO, APX CVT
Ref. Des. Part Number Description
SH16 26012254001 SHLD,STL,SN PLT,SHIELD,
CONTROLLER/AVR, APX
CVT
SH17 26012262001 SHLD,STL,SN PLT,SHIELD,
MACE/MAKO, APX CVT
SH2 26012253001 SHLD,STL,SN PLT,SHIELD,
MIXER, APX CVT
SH3 26012259001 SHLD,STL,SN PLT,SHIELD,
GPS/BT, APX CVT
SH4 26012247001 SHLD,STL,SN PLT,SHIELD,
2ND LO, APX CVT
SH5 26012255001 SHLD,STL,SN PLT,SHIELD,
ALC1, APX CVT
SH6 26012248001 SHLD,STL,SN PLT,SHIELD,
FGU, APX CVT
SH7 26012256001 SHLD,CAN,STL,SN
PLT,SHIELD, DC, APX CVT
SH8 26012249001 SHLD,STL,SN PLT,SHIELD,
TXFE, APX CVT
SH9 26012257001 SHLD,CAN,STL,SN
PLT,SHIELD, RXFE, APX
CVT
SPKR+M2 TPSM1_50 SINGLE PIN CONTACT
TEST POINT
SPKR-M2 TPSM1_50 SINGLE PIN CONTACT
TEST POINT
T506M21 2575851B01 XFMR,BALUN,RF XFMR
BALUN
T507M21 2575851B02 XFMR,BALUN,25,SM,RF
XFMR BALUN
TP_ATOD
_8M6
TPSM0_50 TEST POINT .020 DIA
TP_MACE
_NRDM6
TPSM0_50 TEST POINT .020 DIA
TP1 TPSM1_01ALT SINGLE PIN CONTACT
TEST POINT, 1.01 DIA
TP1301M3 TPSM1_50 SINGLE PIN CONTACT
TEST POINT
TP1303M3 TPSM0_50 TEST POINT .020 DIA
TP1304M3 TPSM0_50 TEST POINT .020 DIA
Ref. Des. Part Number Description
