Motorola APX 3000

8-224 Schematics, Boards Overlays, and Parts Lists: Main Board Block: UHF2 (84012616001)
TP1311M3 TPSM1_01ALT SINGLE PIN CONTACT
TEST POINT, 1.01 DIA
TP2 TPSM1_01ALT SINGLE PIN CONTACT
TEST POINT, 1.01 DIA
TP2413M3 TPSM1_50 SINGLE PIN CONTACT
TEST POINT
TP2414M3 TPSM1_50 SINGLE PIN CONTACT
TEST POINT
TP2415M3 TPSM1_50 SINGLE PIN CONTACT
TEST POINT
TP2416M3 TPSM1_50 SINGLE PIN CONTACT
TEST POINT
TP2417M3 TPSM1_50 SINGLE PIN CONTACT
TEST POINT
TP2419M3 TPSM0_50 TEST POINT .020 DIA
TP2435M3 TPSM0_50 TEST POINT .020 DIA
TP2436M3 TPSM0_50 TEST POINT .020 DIA
TP2437M3 TPSM0_50 TEST POINT .020 DIA
TP2450M3 TPSM0_50 TEST POINT .020 DIA
TP2451M3 TPSM0_50 TEST POINT .020 DIA
TP2452M3 TPSM0_50 TEST POINT .020 DIA
TP2453M3 TPSM0_50 TEST POINT .020 DIA
TP2466M3 TPSM1_50 SINGLE PIN CONTACT
TEST POINT
TP2502M6 TPSM0_50 TEST POINT .020 DIA
TP3100M2
2
TPSM1_01ALT SINGLE PIN CONTACT
TEST POINT, 1.01 DIA
TP601M19 TPSM0_70 TEST POINT
TP603M19 TPSM0_70 TEST POINT
TP6101M6 TPSM0_50 TEST POINT .020 DIA
TP6102M6 TPSM1_50 SINGLE PIN CONTACT
TEST POINT
TP6105M6 TPSM0_70 TEST POINT
TP6106M6 TPSM0_70 TEST POINT
TP6107M6 TPSM0_70 TEST POINT
TP6210M6 TPSM1_50 SINGLE PIN CONTACT
TEST POINT
Ref. Des. Part Number Description
TP6301M6 TPSM0_50 TEST POINT .020 DIA
TP6302M6 TPSM0_381 TEST POINT
TP6303M6 TPSM1_05SQ TESTPOINT 1.05MMSQ
TP6304M6 TPSM1_05SQ TESTPOINT 1.05MMSQ
TP6305M6 TPSM1_05SQ TESTPOINT 1.05MMSQ
TP6306M6 TPSM1_05SQ TESTPOINT 1.05MMSQ
TP6307M6 TPSM1_05SQ TESTPOINT 1.05MMSQ
TP6308M6 TPSM1_05SQ TESTPOINT 1.05MMSQ
TP6599M6 TPSM0_70 TEST POINT
TP6601M6 TPSM0_70 TEST POINT
TP6701M6 TPSM0_50 TEST POINT .020 DIA
TP6702M6 TPSM0_50 TEST POINT .020 DIA
TP6703M6 TPSM0_50 TEST POINT .020 DIA
TP6704M6 TPSM0_50 TEST POINT .020 DIA
TP6705M6 TPSM0_50 TEST POINT .020 DIA
TP701M7 TPSM0_70 TEST POINT
TP737M7 TPSM0_70 TEST POINT
U1101M11 5188032U43 IC,SENSING CIR-
CUIT,INA138,SM,SOT-23/
5,1PER PKG,PB FREE
U1103M11 5185070Y01 IC,TEMP SENS
U1104M11 5185941F56 IC,OP AMP,1PER
PKG,RAIL-RAIL,SOIC,IC
SNGL LV LP OP AMP
U1105M11 5180390L83 IC,CNTLR,SM,1PER PKG
U1106M11 5175772B05 IC,LTC5532ES6,SOT-
23,1PER PKG,PRCN RF
DET
U1112M11 5175772B04 IC,HMC468LP3E,QFN,1 DB
LSB GAAS MMIC ATTEN
U1113M11 5185941F56 IC,OP AMP,1PER
PKG,RAIL-RAIL,SOIC,IC
SNGL LV LP OP AMP
U1114M11 5185941F56 IC,OP AMP,1PER
PKG,RAIL-RAIL,SOIC,IC
SNGL LV LP OP AMP
Ref. Des. Part Number Description
U1119M11 5109522E94 GATE,AND,1PER
PKG,SM,2 INPUT IN NANO
PKG
U1121M11 5114000B52 IC,XOR,LOGIC LEVEL
SHIFTER,1PER
PKG,SM,SOT-353,PB-FREE
U1125M11 5175206H01 IC,DAC,W/ 5 PPM/C INT
REF
U1126M11 5109817F77 IC,COMPTR,LMV7275,SC7
0-5
U1127M11 5171779H01 IC,ANLG SW,SC70,SC70-
6,1PER PKG,SPDT ANLG
SW
U1128M11 5188085K11 IC,NAND,SINGLE 2
INPUT,SN74LVC1G00YZPR
,SM,GATE, POS, 5 DSBGA,
U1129M11 5175143H01 IC,WIDE SPLY RANGE OP
AMP
U1130M11 5175143H01 IC,WIDE SPLY RANGE OP
AMP
U1131M11 5109817F77 IC,COMPTR,LMV7275,SC7
0-5
U1132M11 5114007M28 IC,D FLIP-FLOP,1PER
PKG,17SZ74,N-
I,SM,SOIC8,PB-FREE
U1133M11 5171779H01 IC,ANLG SW,SC70,SC70-
6,1PER PKG,SPDT ANLG
SW
U1136M11 5109522E94 GATE,AND,1PER
PKG,SM,2 INPUT IN NANO
PKG
U1137M11 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U1138M11 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U1139M11 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
Ref. Des. Part Number Description
U1141M11 5185941F56 IC,OP AMP,1PER
PKG,RAIL-RAIL,SOIC,IC
SNGL LV LP OP AMP
U1142M11 5185941F56 IC,OP AMP,1PER
PKG,RAIL-RAIL,SOIC,IC
SNGL LV LP OP AMP
U1143M11 5185941F56 IC,OP AMP,1PER
PKG,RAIL-RAIL,SOIC,IC
SNGL LV LP OP AMP
U1144M11 5171779H01 IC,ANLG SW,SC70,SC70-
6,1PER PKG,SPDT ANLG
SW
U1146M11 5109522E93 GATE,OR,SN74LVC1G32Y
ZPR,1PER PKG,SM,2
INPUT IN NANO PKG
U1147M11 5109522E94 GATE,AND,1PER
PKG,SM,2 INPUT IN NANO
PKG
U1148M11 5185941F56 IC,OP AMP,1PER
PKG,RAIL-RAIL,SOIC,IC
SNGL LV LP OP AMP
U1149M11 5109522E93 GATE,OR,SN74LVC1G32Y
ZPR,1PER PKG,SM,2
INPUT IN NANO PKG
U1150M11 51009381001 IC,MICROPOWER SOT-23
V REF
U1301M3 51007377001 IC,XCVR,NL5500,BGA,BLU-
ETOOTH, GPS, FM RX, FM
TX
U1304M3 51007599001 AMP,20.0DB,1.58GHZMIN,1
.58GHZMAX,SLCN GER-
MANIUM GPS LOW NOISE
AM
U1305M3 5187344N09 IC,LNR V
REGLTR,FXD,2.8V,100MA,L
OW NOISE
U1334M3 5102836C11 IC,ANLG
SW,FSA4157,SM,SPDT,PB
FREE
U1335M3 5102836C11 IC,ANLG
SW,FSA4157,SM,SPDT,PB
FREE
U1601M16 5175143H01 IC,WIDE SPLY RANGE OP
AMP
Ref. Des. Part Number Description
