Motorola APX 3000 Detailed Service Manual

Schematics, Boards Overlays, and Parts Lists: Main Board Block: UHF2 (84012616001) 8-225
U1602M16 51012101001 IC,SM,VHF/UHF/800/900
MHZ LDMOS DRVR IC
U1932M20 4885316E32 XSTR,BIP RF SML
SGNL,SLCN,BFR380F,SM,
SMT,6V,380W,80A,14MHZ,T
R
U200M12 5188493T01 IC,VREG/
SWG,LP2989,SM,MINI SO-8
HI PRCN REG 5V
U201M12 5175771A99 IC,LNR V
REGLTR,FXD,100MA,VFBG
A,LOW NOISE, 100MA LIN-
EAR REGL
U202M12 5175772B02 IC,LNR V
REGLTR,FXD,1.8V,100MA,
VFBGA,LINEAR REGLTR
100MA 1.8
U203M12 5175772B01 IC,LNR V
REGLTR,FXD,1.5V,350MA,
VFBGA,LINEAR V REGLTR
350MA
U2101M2 5109522E84 IC,DL SCHT TRIG MICRO
PAK
U2102M2 5109522E84 IC,DL SCHT TRIG MICRO
PAK
U2202M2 5164852H47 IC,XLTR,2PER
PKG,TSSOP8,IC, I2C LEV
XLTR
U2205M2 5188682Y01 IC,POWER
DRIVER,40MA,SM,RGB
LED, I2C CONTORL, LLP
PKG
U2402M3 51002923001 IC,LNR V REGLTR,3.3V
LP2989,NOPB
U2403M3 51009735001 IC,RCVR,QFN,IC, RCVR,
ONE-CHAN, QFN, LF
WAKE-UP
U2406M3 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U2407M3 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
Ref. Des. Part Number Description
U2408M3 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U2409M3 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U2410M3 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U2411M3 5175856M01 IC,INVTR,0MHZMAX,DL
INVTR
U2412M3 5114007M45 IC,NOR,1PER PKG,SOT-
353,PB-FREE
U2413M3 51007645001 IC,SDRAM,128MB,8 MEG X
16,6NS,SM,64MSRFRSH,IC
,SDRAM,128MBIT,8
U2414M3 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U2415M3 51009372001 IC,UCNTLR,IC UCNTLR
AT32UC3A0512
U2416M3 51009669001 IC,SENSOR,SM,IC, ACCEL-
EROMETER, MOTION
SENSOR
U2473M3 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U2478M3 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U2510M6 5185912Y03 IC,MICROP,BGA,CRYPTO-
GRAPHIC PROCES-
SOR,IC,CRYPTOGRAPHIC
P
U2525M6 5171339H01 IC,MC78LC18,MICROPO-
WER V REGLTR
U2526M6 5171988H01 IC,COMPTR,CMOS
COMPTR
U2601M13 5103535B53 IC,INVTR,DL,NC7WZ04L6X
,2PER PKG,SC70
Ref. Des. Part Number Description
U2602M13 5185941F45 ATTEN,VAR,14.4DBMIN,15.
6DBMAX,0-2000 MHZ-
FREQ,50OHM,PCMT,SOT-
25
U3001M22 5171972L01 IC,SW,SP3T RF SW
U4001M2 5164852H47 IC,XLTR,2PER
PKG,TSSOP8,IC, I2C LEV
XLTR
U4003M2 5188691V01 IC,MUX/
DEMUX,NC7SB3157P6X,S
M,SC70-6,1PER
PKG,BUS,PB FREE
U4004M2 5116783H01 IC,ANLG
SW,SN74LVC2G66YZPR,S
M,2PER
PKG,0CHANNELS,BILAT-
ERAL,DL
U507M21 5164015H81 IC,MXR,SM
U601M19 5102495J14 IC,IF,IF DIGITILIZING SUB-
SYSTEM IC,AD9864,QFN
U602M19 4885316E32 XSTR,BIP RF SML
SGNL,SLCN,BFR380F,SM,
SMT,6V,380W,80A,14MHZ,T
R
U603M19 5109522E84 IC,DL SCHT TRIG MICRO
PAK
U604M19 5109522E84 IC,DL SCHT TRIG MICRO
PAK
U605M19 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U606M19 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U607M19 5186311J24 IC,BFR,1PER
PKG,NC7SZ125,ACTIVE
HIGH,BFR,3ST,SM,5.5
U6101M6 0180706J18 IC,PGM,PGM CPLD
U6102M6 5188691V01 IC,MUX/
DEMUX,NC7SB3157P6X,S
M,SC70-6,1PER
PKG,BUS,PB FREE
Ref. Des. Part Number Description
U6103M6 5175114H01 IC,SNGL AND GATE
MICROPAK
U6104M6 5175114H01 IC,SNGL AND GATE
MICROPAK
U6105M6 5175114H01 IC,SNGL AND GATE
MICROPAK
U6201M6 5185941F26 IC,COMPTR,LMV7219,SM,
SOT-23/5,IC,LM7219,COM-
PARATOR,NOPB
U6301M6 51012031001 IC,SDRAM,32MB,16 MEG
X16,6.5NS,VFBGA,64MSRF
RSH,32MB DIE SHRIN
U6302M6 5102495J13 IC,MICROP,P1710ZZGE,BG
A,12MHZ,32BITS
U6304M6 0105955U25 ASSY,ASSY,ASSY,IC,BGA
SPEC PROG, FLSH MEM
U6402M6 5115453H01 IC,OP AMP,2PER PKG,RAIL
TO RAIL OUTPUT, 8 PIN
BGA
U6404M6 5175772B38 IC,IC ANLG TEMP SENSOR
U6405M6 5188348V06 IC,AUDIO
CODEC,SM,AUDIO CODEC
U6408M6 5188521T01 IC,VREF,SM,SOT23,1PER
PKG,.5%,1.25 TO
13.75,PRCN BANDGAP
ADJUS
U6409M6 51009000001 IC,COMPTR,SC70,NANOP-
OWER, 1.8V, SC70
COMPTR
U6501M6 5185143E77 IC,CUST,BGA,IC, MAKO
ASIC, CMOS PWR MGMT
U6502M6 4871987H01 XSTR,BIP GP
POWER,12V,1A,LOW
FREQ XSTR
U6503M6 5171674H01 IC,OP AMP,SO-8,OP AMP
U6504M6 5171682H01 IC,DC TO DC CON-
VERTER,800MA BUCK
REGLTR
U6505M6 5189631P01 IC,0PER PKG,SYNC STEP-
DOWN CONV
U6506M6 5184790Y04 IC,LINEAR VOLTAGE REG-
ULATOR,400MA
Ref. Des. Part Number Description
