Motorola APX 6000 - Expandable Memory (Emmc); Figure 6-37. Emmc: Power-On until Final Initialization Waveforms

Troubleshooting Waveforms: Expandable Memory (eMMC) 6-39
6.14 Expandable Memory (eMMC)
6.14.1 eMMC @ Power-On
Figure 6-37. eMMC: Power-On until Final Initialization Waveforms
MMC_CLK
MMC_CMD
MMC_DAT0
MMC_DAT1
Δ
X= 2.95s
