Radio Power: DC Power Routing – VOCON Board 2-3
The transceiver regulated power supplies are summarized in Table 2-2.
2.3 DC Power Routing – VOCON Board
NOTE: Refer to Table 8-2, “List of VOCON Schematics and Board Overlays,” on page 8-2 for a listing
of schematics showing the VOCON board DC power routing components.
Refer to “3.2.2 DC Distribution” on page 3-27 for details on DC Power Routing for VOCON Board.
Table 2-2. Transceiver Voltage Regulators
Reference
Designator
IC
Name
Output
Signal Name
Description
U200 LP2989 DC_LIN_5V Regulated 5.0 Vdc
U201 LP5900 DC_LIN_3V Regulated 3.0 Vdc
U202 LP5900 DC_LIN_1_8V Regulated 1.8 Vdc
U203 LP5952 DC_LIN_1_5V Regulated 1.5 Vdc
