6-46 Troubleshooting Waveforms: Expandable Memory (eMMC)
6.14.8 eMMC @ Data Transfer
Figure 6-44. MMC_DAT0, MMC_DAT1, MMC_DAT2, MMC_DAT3 data lines during data transmission
between eMMC and OMAP
