Motorola APX 6000 Service Manual

Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF1 8-39
NUE7365A UHF1 Transceiver (RF) Board Parts
List
Ref.
Des.
Part Number Description
C101 2113944A46 CAP,CHIP,330PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C102 2113946B04 CAP,CHIP,.1UF,+10%,-10%,10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C200 2113945B02 CAP,CHIP,.01UF,+10%,-10%,
25V-DC,0402,X7R,-55DEG
CMIN,125DEG CMA
C201 2188468Y01 CAP,CHIP,1UF,+10,-10,25V-
DC,0805,X7R
C202 2188468Y01 CAP,CHIP,1UF,+10,-10,25V-
DC,0805,X7R
C203 2188468Y01 CAP,CHIP,1UF,+10,-10,25V-
DC,0805,X7R
C204 2113955D35 CAP,FXD,4.7UF,+10%,-10%,
16V-DC,1206,X7R,-55DEG
CMIN,125DEG CMAX
C205 2113955D35 CAP,FXD,4.7UF,+10%,-10%,
16V-DC,1206,X7R,-55DEG
CMIN,125DEG CMAX
C206 2113945B02 CAP,CHIP,.01UF,+10%,-10%,
25V-DC,0402,X7R,-55DEG
CMIN,125DEG CMA
C207 2113956B91 CAP,FXD,1UF,+10%,-10%,16V-
DC,0603,X5R,-55DEG CMIN,
85DEG CMAX,PB
C208 2113956B91 CAP,FXD,1UF,+10%,-10%,16V-
DC,0603,X5R,-55DEG CMIN,
85DEG CMAX,PB
C209 2113956B91 CAP,FXD,1UF,+10%,-10%,16V-
DC,0603,X5R,-55DEG CMIN,
85DEG CMAX,PB
C210 2113956B91 CAP,FXD,1UF,+10%,-10%,16V-
DC,0603,X5R,-55DEG CMIN,
85DEG CMAX,PB
C212 2113946D07 CAP,CHIP,4.7UF,+10%,-10%,
6.3V-DC,0603,X5R,-55DEG
CMIN,85DEG CMA
C213 2113944A46 CAP,CHIP,330PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C214 2113944A31 CAP,CHIP,33PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,P
C215 2113944A46 CAP,CHIP,330PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C216 2113944A31 CAP,CHIP,33PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,P
C217 2113956B91 CAP,FXD,1UF,+10%,-10%,16V-
DC,0603,X5R,-55DEG CMIN,
85DEG CMAX,PB
C501 2115153H41 CAP,FXD,22PF,+1%,-1%,50V-
DC,0402,C0G
C502 2115153H28 CAP,CER CHIP,4PF,.1PF+/-,
+.1%,-.1%,50V-DC,0402,C0G
C506 2113946B04 CAP,CHIP,.1UF,+10%,-10%,10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C507 2115153H41 CAP,FXD,22PF,+1%,-1%,50V-
DC,0402,C0G
C508 2113945A09 CAP,CHIP,1000PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG
CMIN,125DEG CM
C509 2113945A09 CAP,CHIP,1000PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG
CMIN,125DEG CM
C510 2113944A52 CAP,CHIP,1000PF,+5%,-5%,
50V-DC,0402,C0G,-55DEG
CMIN,125DEG CMAX
C512 2113944A31 CAP,CHIP,33PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,P
C513 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C514 2113944A84 CAP,FXD,43PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,PB
C515 2113944A21 CAP,CHIP,6.8PF,.5PF+/-,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C516 2113944A63 CAP,FXD,1PF,.25PF+/-,50V-DC,
0402,C0G,-55DEG CMIN,
125DEG CMAX,P
C517 2113946B04 CAP,CHIP,.1UF,+10%,-10%,10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C518 2113945A09 CAP,CHIP,1000PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG
CMIN,125DEG CM
Ref.
Des.
Part Number Description
C519 2113944A31 CAP,CHIP,33PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,P
C520 2113945A09 CAP,CHIP,1000PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG
CMIN,125DEG CM
C521 2113945A09 CAP,CHIP,1000PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG
CMIN,125DEG CM
C522 2113944A27 CAP,CHIP,15PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,P
C523 2113944A48 CAP,CHIP,470PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C524 2113944A36 CAP,CHIP,68PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,P
C525 2113944A61 CAP,FXD,.5PF,.25PF+/-,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C528 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C529 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C601 2113945B02 CAP,CHIP,.01UF,+10%,-10%,
25V-DC,0402,X7R,-55DEG
CMIN,125DEG CMA
C602 2113945B02 CAP,CHIP,.01UF,+10%,-10%,
25V-DC,0402,X7R,-55DEG
CMIN,125DEG CMA
C603 2113945B02 CAP,CHIP,.01UF,+10%,-10%,
25V-DC,0402,X7R,-55DEG
CMIN,125DEG CMA
C604 2113945B02 CAP,CHIP,.01UF,+10%,-
10%,25V-DC,0402,X7R,-55DEG
CMIN,125DEG CMA
C605 2113944A15 CAP,CHIP,3.9PF,.25PF+/-,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMA
C606 2113946B04 CAP,CHIP,.1UF,+10%,-10%,10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C607 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
Ref.
Des.
Part Number Description
C608 2113944A12 CAP,CHIP,3PF,.25PF+/-,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C609 2113944A30 CAP,CHIP,27PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,P
C610 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C611 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C612 2113945B02 CAP,CHIP,.01UF,+10%,-10%,
25V-DC,0402,X7R,-55DEG
CMIN,125DEG CMA
C613 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C614 2113945B02 CAP,CHIP,.01UF,+10%,-10%,
25V-DC,0402,X7R,-55DEG
CMIN,125DEG CMA
C615 2113944A42 CAP,CHIP,150PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C616 2113945A11 CAP,CHIP,2200PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG
CMIN,125DEG CM
C617 2113946B04 CAP,CHIP,.1UF,+10%,-10%,10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C618 2113944A31 CAP,CHIP,33PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,P
C619 2113944A35 CAP,CHIP,62PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,P
C620 2113946B04 CAP,CHIP,.1UF,+10%,-10%,10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C621 2113946B04 CAP,CHIP,.1UF,+10%,-10%,10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C622 2113946C07 CAP,FXD,.33UF,+10%,-10%,
10V-DC,0603,X5R,-55DEG
CMIN,85DEG CMAX
C623 2113945B02 CAP,CHIP,.01UF,+10%,-10%,
25V-DC,0402,X7R,-55DEG
CMIN,125DEG CMA
Ref.
Des.
Part Number Description

Motorola APX 6000 Specifications

General

Frequency Range	700/800 MHz, VHF, UHF Range 1, UHF Range 2
IP Rating	IP67
P25 Phase 1 & 2	Yes
GPS	Yes
Encryption	AES, DES
Power Output	1-3 Watts (700/800 MHz)
Operating Temperature	-30°C to +60°C
Intrinsically Safe	Yes
Bluetooth	Yes (Bluetooth 4.0)
