Motorola APX 6000 Service Manual

Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: 700–800 MHz 8-95
NUF6750A 700–800 MHz Transceiver (RF)
Board Parts List
Ref.
Des.
Part Number Description
C101 2113944A46 CAP CER CHP 330.0 PF 50V
5%
C102 NOT PLACED –
C200 2113945B02 CAP CER CHP 10,000PF 25V
10%
C201 2188468Y01 CAP CER 25V X7R 0805 1UF
C202 2188468Y01 CAP CER 25V X7R 0805 1UF
C203 2188468Y01 CAP CER 25V X7R 0805 1UF
C204 2113955D35 CAP,FXD,4.7UF,+10%,-10%,
16V-DC,1206,X7R,-55DEG
CMIN,125DEG CMAX
C205 2113955D35 CAP,FXD,4.7UF,+10%,-10%,
16V-DC,1206,X7R,-55DEG
CMIN,125DEG CMAX
C206 2113945B02 CAP CER CHP 10,000PF 25V
10%
C207 2113956B91 CAP,FXD,1UF,+10%,-10%,16V-
DC,0603,X5R,-55DEG CMIN,
85DEG CMAX,PB
C208 2113956B91 CAP,FXD,1UF,+10%,-10%,16V-
DC,0603,X5R,-55DEG CMIN,
85DEG CMAX,PB
C209 2113956B91 CAP,FXD,1UF,+10%,-10%,16V-
DC,0603,X5R,-55DEG CMIN,
85DEG CMAX,PB
C210 2113956B91 CAP,FXD,1UF,+10%,-10%,16V-
DC,0603,X5R,-55DEG CMIN,
85DEG CMAX,PB
C212 2113946D07 CAP,CHIP,4.7UF,+10%,-10%,
6.3V-DC,0603,X5R,-55DEG
CMIN,85DEG CMA
C213 2113944A46 CAP CER CHP 330.0 PF 50V
5%
C214 2113944A31 CAP CER CHP 33.0PF 50V 5%
C215 2113944A46 CAP CER CHP 330.0 PF 50V
5%
C216 2113944A31 CAP CER CHP 33.0PF 50V 5%
C217 2113956B91 CAP,FXD,1UF,+10%,-10%,16V-
DC,0603,X5R,-55DEG CMIN,
85DEG CMAX,PB
C402 2113944A31 CAP CER CHP 33.0PF 50V 5%
C404 2113944A31 CAP CER CHP 33.0PF 50V 5%
C405 2113944A31 CAP CER CHP 33.0PF 50V 5%
C406 2113944A31 CAP CER CHP 33.0PF 50V 5%
C407 2113944A31 CAP CER CHP 33.0PF 50V 5%
C408 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
C409 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
C410 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
C411 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
C412 2113944A27 CAP CER CHP 15.0PF 50V 5%
C413 2113944A33 CAP CER CHP 47.0PF 50V 5%
C414 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
C415 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
C416 2113944A31 CAP CER CHP 33.0PF 50V 5%
C417 2113944A31 CAP CER CHP 33.0PF 50V 5%
C418 2113944A31 CAP CER CHP 33.0PF 50V 5%
C419 2113944A31 CAP CER CHP 33.0PF 50V 5%
C421 2113946D07 CAP,CHIP,4.7UF,+10%,-10%,
6.3V-DC,0603,X5R,-55DEG
CMIN,85DEG CMA
C422 2113944A31 CAP CER CHP 33.0PF 50V 5%
C423 2113944A21 CAP CER CHP 6.8PF 50V
+/- 0.5PF
C424 2113944A31 CAP CER CHP 33.0PF 50V 5%
C425 2113944A12 CAP CER CHP 3.0PF 50V
+/- 0.25PF
C426 2113944A63 CAP,FXD,1PF,.25PF+/-,50V-DC,
0402,C0G,-55DEG CMIN,
125DEG CMAX,P
C427 2113946D07 CAP,CHIP,4.7UF,+10%,-10%,
6.3V-DC,0603,X5R,-55DEG
CMIN,85DEG CMA
C428 2113946D07 CAP,CHIP,4.7UF,+10%,-10%,
6.3V-DC,0603,X5R,-55DEG
CMIN,85DEG CMA
C429 2113944A31 CAP CER CHP 33.0PF 50V 5%
C430 2113944A21 CAP CER CHP 6.8PF 50V
+/- 0.5PF
C431 2113944A31 CAP CER CHP 33.0PF 50V 5%
Ref.
Des.
Part Number Description
C432 2113944A12 CAP CER CHP 3.0PF 50V +/-
0.25PF
C433 2113944A63 CAP,FXD,1PF,.25PF+/-,50V-DC,
0402,C0G,-55DEG CMIN,
125DEG CMAX,P
C434 2113946D07 CAP,CHIP,4.7UF,+10%,-10%,
6.3V-DC,0603,X5R,-55DEG
CMIN,85DEG CMA
C435 2113944A63 CAP,FXD,1PF,.25PF+/-,50V-DC,
0402,C0G,-55DEG CMIN,
125DEG CMAX,P
C503 2113944V13 CAP,FXD,2.7PF,.1PF+/-,50V-DC,
0402,C0G,-55DEG CMIN,
125DEG CMAX
C506 2113946B04 CAP CER CHP 0.10UF 10V 10%
C507 2113944A44 CAP CER CHP 220.0 PF 50V
5%
C508 2113945A09 CAP CER CHP 1000PF 50V
10%
C509 2113945A09 CAP CER CHP 1000PF 50V
10%
C511 2113944A40 CAP CER CHP 100.0PF 50V 5%
C512 2113944A31 CAP CER CHP 33.0PF 50V 5%
C513 2113944A40 CAP CER CHP 100.0PF 50V 5%
C514 2113944A84 CAP,FXD,43PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,PB
C515 2113944A21 CAP CER CHP 6.8PF 50V
+/- 0.5PF
C516 2113944A11 CAP CER CHP 2.7PF 50V
+/- 0.25PF
C517 2113946B04 CAP CER CHP 0.10UF 10V 10%
C518 2113945A09 CAP CER CHP 1000PF 50V
10%
C519 2113944A31 CAP CER CHP 33.0PF 50V 5%
C520 2113945A09 CAP CER CHP 1000PF 50V
10%
C521 2113945A09 CAP CER CHP 1000PF 50V
10%
C522 2113944A27 CAP CER CHP 15.0PF 50V 5%
C523 2113944A48 CAP CER CHP 470.0 PF 50V
5%
C524 2113944A30 CAP CER CHP 27.0PF 50V 5%
Ref.
Des.
Part Number Description
C525 2113944A61 CAP,FXD,.5PF,.25PF+/-,50V-DC,
0402,C0G,-55DEG CMIN,
125DEG CMAX
C526 2113944V13 CAP,FXD,2.7PF,.1PF+/-,50V-DC,
0402,C0G,-55DEG CMIN,
125DEG CMAX
C527 2113944V07 CAP,FXD,1.5PF,.1PF+/-,50V-DC,
0402,C0G,-55DEG CMIN,
125DEG CMAX
C599 2113944A40 CAP CER CHP 100.0PF 50V 5%
C601 2113945B02 CAP CER CHP 10,000PF 25V
10%
C602 2113945B02 CAP CER CHP 10,000PF 25V
10%
C603 2113945B02 CAP CER CHP 10,000PF 25V
10%
C604 2113945B02 CAP CER CHP 10,000PF 25V
10%
C605 2113944A15 CAP CER CHP 3.9PF 50V +/-
0.25PF
C606 2113946B04 CAP CER CHP 0.10UF 10V 10%
C607 2113944A40 CAP CER CHP 100.0PF 50V 5%
C608 2113944A12 CAP CER CHP 3.0PF 50V +/-
0.25PF
C609 2113944A30 CAP CER CHP 27.0PF 50V 5%
C610 2113944A40 CAP CER CHP 100.0PF 50V 5%
C611 2113944A40 CAP CER CHP 100.0PF 50V 5%
C612 2113945B02 CAP CER CHP 10,000PF 25V
10%
C613 2113944A40 CAP CER CHP 100.0PF 50V 5%
C614 2113945B02 CAP CER CHP 10,000PF 25V
10%
C615 2113944A42 CAP CER CHP 150.0PF 50V 5%
C616 2113945A11 CAP CER CHP 2200PF 50V
10%
C617 2113946B04 CAP CER CHP 0.10UF 10V 10%
C618 2113944A31 CAP CER CHP 33.0PF 50V 5%
C619 2113944A35 CAP CER CHP 62.0PF 50V 5%
C620 2113946B04 CAP CER CHP 0.10UF 10V 10%
C621 2113946B04 CAP CER CHP 0.10UF 10V 10%
C622 2113946C07 CAP,FXD,.33UF,+10%,-10%,
10V-DC,0603,X5R,-55DEG
CMIN,85DEG CMAX
Ref.
Des.
Part Number Description
