8-152 Schematics, Boards Overlays, and Parts Lists: Controller Board

HLN5960A Controller Board Parts List

Ref.

Des.

Part Number Description

C2104 2113946B04 CAP CER CHP 0.10UF 10V 10%

C2105 2113944A46 CAP CER CHP 330.0 PF 50V 5%

C2107 2113944A46 CAP CER CHP 330.0 PF 50V 5%

C2108 2113944A46 CAP CER CHP 330.0 PF 50V 5%

C2109 2113944A46 CAP CER CHP 330.0 PF 50V 5%

C2110 2113944A46 CAP CER CHP 330.0 PF 50V 5%

C2111 2113944A46 CAP CER CHP 330.0 PF 50V 5%

C2113 2113944A46 CAP CER CHP 330.0 PF 50V 5%

C2114 2113946B04 CAP CER CHP 0.10UF 10V 10%

C2201 2113946B04 CAP CER CHP 0.10UF 10V 10%

C2202 2113946B04 CAP CER CHP 0.10UF 10V 10%

C2203 2113946B04 CAP CER CHP 0.10UF 10V 10%

C2217 2113946S35 CAP CER CHP 1.0UF 16V 10%

C2220 2113946S35 CAP CER CHP 1.0UF 16V 10%

C2326 2113944A46 CAP CER CHP 330.0 PF 50V 5%

C2327 2113944A46 CAP CER CHP 330.0 PF 50V 5%

C2328 2113944A46 CAP CER CHP 330.0 PF 50V 5%

C2329 2113944A46 CAP CER CHP 330.0 PF 50V 5%

C2330 2113944A46 CAP CER CHP 330.0 PF 50V 5%

C4005 2113946B04 CAP CER CHP 0.10UF 10V 10%

C4006 2113946B04 CAP CER CHP 0.10UF 10V 10%

C4007 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6104 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6105 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6106 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6107 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6108 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6109 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6110 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6111 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6112 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6113 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6114 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6115 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6201 2113944A40 CAP CER CHP 100.0PF 50V 5%

C6202 2113945A09 CAP CER CHP 1000PF 50V 10%

C6203 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6301 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6302 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6303 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6304 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6305 2113946S35 CAP CER CHP 1.0UF 16V 10%

C6306 2113946S35 CAP CER CHP 1.0UF 16V 10%

C6308 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6309 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6310 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6311 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6401 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6402 2113956A51 CAP,FXD,1UF,+10%,-10%,6.3V-

DC,0402,X5R,-55DEG CMIN,

85DEG CMAX,P

C6403 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6404 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6405 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6406 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6407 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6408 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6409 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6410 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6411 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6413 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6414 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6416 2113945B04 CAP,FXD,.022UF,+10%,-10%,

25V-DC,0402,X7R,-55DEG

CMIN,125DEG CMA

C6417 2113945B04 CAP,FXD,.022UF,+10%,-10%,

25V-DC,0402,X7R,-55DEG

CMIN,125DEG CMA

C6418 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6419 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6420 2113945B04 CAP,FXD,.022UF,+10%,-10%,

25V-DC,0402,X7R,-55DEG

CMIN,125DEG CMA

C6421 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6422 2113946C02 CAP CER CHP 0.22UF 10V 10%

C6423 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6424 2113944A40 CAP CER CHP 100.0PF 50V 5%

C6425 2113944A40 CAP CER CHP 100.0PF 50V 5%

Ref.

Des.

Part Number Description

C6426 2113945B02 CAP CER CHP 10,000PF 25V

10%

C6427 2113944A50 CAP CER CHP 680.0 PF 50V 5%

C6428 2113944A40 CAP CER CHP 100.0PF 50V 5%

C6501 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6502 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6503 2113944A46 CAP CER CHP 330.0 PF 50V 5%

C6504 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6505 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6506 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6507 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6508 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6509 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6510 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6511 2113946S35 CAP CER CHP 1.0UF 16V 10%

C6512 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6513 2113946S35 CAP CER CHP 1.0UF 16V 10%

C6514 2113946S35 CAP CER CHP 1.0UF 16V 10%

C6515 2113946S35 CAP CER CHP 1.0UF 16V 10%

C6516 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6517 2113946S35 CAP CER CHP 1.0UF 16V 10%

C6518 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6519 2113946S35 CAP CER CHP 1.0UF 16V 10%

C6520 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6521 2113944A46 CAP CER CHP 330.0 PF 50V 5%

C6522 2113946S35 CAP CER CHP 1.0UF 16V 10%

C6523 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6524 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6525 2113946S35 CAP CER CHP 1.0UF 16V 10%

C6526 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6527 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6528 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6529 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6530 2113946S35 CAP CER CHP 1.0UF 16V 10%

C6531 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6532 2113946S35 CAP CER CHP 1.0UF 16V 10%

C6533 2113946B04 CAP CER CHP 0.10UF 10V 10%

Ref.

Des.

Part Number Description

C6534 2113956B33 CAP,FXD,2.2UF,+10%,-10%, 16V-

DC,0603,X5R,-55DEG

CMIN,85DEG CMAX

C6535 2113944A40 CAP CER CHP 100.0PF 50V 5%

C6536 2113944A28 CAP CER CHP 18.0PF 50V 5%

C6537 2113944A19 CAP CER CHP 5.6PF 50V +/-

0.5PF

C6538 2113956B33 CAP,FXD,2.2UF,+10%,-10%, 16V-

DC,0603,X5R,-55DEG

CMIN,85DEG CMAX

C6539 2113956B33 CAP,FXD,2.2UF,+10%,-10%, 16V-

DC,0603,X5R,-55DEG

CMIN,85DEG CMAX

C6540 2113945B02 CAP CER CHP 10,000PF 25V

10%

C6541 2113944A19 CAP CER CHP 5.6PF 50V +/-

0.5PF

C6542 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6543 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6544 2113945D04 CAP CER CHP 100,000PF 25V

10%

C6545 2113945D04 CAP CER CHP 100,000PF 25V

10%

C6546 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6547 2113944A46 CAP CER CHP 330.0 PF 50V 5%

C6549 2113944A46 CAP CER CHP 330.0 PF 50V 5%

C6550 2113945D04 CAP CER CHP 100,000PF 25V

10%

C6551 2113944A46 CAP CER CHP 330.0 PF 50V 5%

C6552 2113956E91 CAP,FXD,10UF,+10%,-10%,16V-

DC,1210,X5R,-55DEG CMIN,

85DEG CMAX,P

C6553 2113956E91 CAP,FXD,10UF,+10%,-10%,16V-

DC,1210,X5R,-55DEG CMIN,

85DEG CMAX,P

C6554 2113946B04 CAP CER CHP 0.10UF 10V 10%

C6555 2113955D45 CAP,FXD,4.7UF,+10%,-10%, 10V-

DC,1206,X7R,-55DEG

CMIN,125DEG CMAX

C6556 2113956B33 CAP,FXD,2.2UF,+10%,-10%,16V-

DC,0603,X5R,-55DEG

CMIN,85DEG CMAX

C6557 2113945D04 CAP CER CHP 100,000PF 25V

10%

Ref.

Des.

Part Number Description
