Identifying Radio Controls
English
18
Double blinking yellow – Auto roaming is enabled, radio is
actively searching for a new site. Also indicates radio has yet to
respond to a group call alert, or radio is locked.
Solid green – Radio is powering up, or transmitting. Also
indicates full charge of the battery when programmable button
is pressed.
Blinking green – Radio is receiving a non-privacy-enabled call
or data, detecting activity or retrieving Over-the-Air
Programming transmissions over the air.
Double blinking green – Radio is receiving a privacy-enabled
call or data.
NOTE: While in conventional mode, when the LED blinks
green, it indicates the radio detects activity over the air.
Due to the nature of the digital protocol, this activity
may or may not affect the radio's programmed
channel.
Audio Tones
Alert tones provide you with audible indications of the radio’s
status or the radio’s response to data received.
Continuous Tone A monotone sound. Sounds
continuously until termination.
Periodic Tone Sounds periodically depending on the
duration set by the radio. Tone starts,
stops, and repeats itself.
Repetitive Tone A single tone that repeats itself until it is
terminated by the user.
Momentary Tone
Sounds only once for a short period of
time defined by the radio.
LKP_APAC.book Page 18 Wednesday, July 18, 2012 11:01 AM
