Motorola Pro3100 Detailed Service Manual

Section 3: 3-32 Controller T6/T7/T9 Schematics and Parts Lists
6881091C63-F
* Motorola Depot Servicing only
Reference designators with an asterisk indicate
components which are not field-replaceable
because they need to be calibrated with
specialized factory equipment after installation.
Radios in which these parts have been replaced in
the field will be off frequency at temperature
extremes.
R0113 0613952J01 RES 10K Ohm
R0114 0613952J01 RES 10K Ohm
R0115 0613952J01 RES 10K Ohm
R0117 0613952H87 RES 3900 Ohm
R0121 0613952J25 RES 100K Ohm
R0131 0613952J73 RES 10M Ohm
R0132 0613952J37 RES 330K Ohm
R0151 0613952J10 RES 24K Ohm
R0152 0613952J10 RES 24K Ohm
R0170 0613952J01 RES 10K Ohm
R0171 0613952H89 RES 4700 Ohm
R0172 0613952J01 RES 10K Ohm
R0173 0613952H89 RES 4700 Ohm
R0174 0613952J01 RES 10K Ohm
R0175 0613952J01 RES 10K Ohm
R0176 0613952J12 RES 30K Ohm
R0177 0613952H89 RES 4700 Ohm
R0178 0613952J17 RES 47K Ohm
R0179 0613952J17 RES 47K Ohm
R0181 0613952H89 RES 4700 Ohm
R0182 0613952J17 RES 47K Ohm
R0183 0613952H89 RES 4700 Ohm
R0184 0613952J17 RES 47K Ohm
R0185 0613952H89 RES 4700 Ohm
R0186 0613952J17 RES 47K Ohm
R0201 0613952H49 RES 100 Ohm
R0202 0613952H67 RES 560 Ohm
R0203 0613952H49 RES 100 Ohm
R0204 0613952H67 RES 560 Ohm
R0205 0613952J01 RES 10K Ohm
R0206 0613952J01 RES 10K Ohm
R0207 0613952H81 RES 2200 Ohm
R0208 0613952H81 RES 2200 Ohm
R0211 0613958D85 RES 7500 Ohm
R0212 0613958D85 RES 7500 Ohm
R0221 0613952J10 RES 24K Ohm
R0222 0613952J10 RES 24K Ohm
R0223 0613952J12 RES 30K Ohm
R0224 0613952H95 RES 8200 Ohm
R0228 0613952G67 RES 0 Ohm
R0229 0613952H25 RES 10 Ohm
R0241 0613952J17 RES 47K Ohm
R0242 0613952G67 RES 0 Ohm
R0251 0613952J17 RES 47K Ohm
R0252 0613952J19 RES 56K Ohm
R0253 0613952J25 RES 100K Ohm
R0254 0613952J01 RES 10K Ohm
R0255 0613952J01 RES 10K Ohm
R0256 0613952J25 RES 100K Ohm
Circuit
Ref
Motorola
Part No.
Description
R0257 0613952H81 RES 2200 Ohm
R0261 0613952J01 RES 10K Ohm
R0262 0613952J35 RES 270K Ohm
R0265 0613952J10 RES 24K Ohm
R0267 0613952J17 RES 47K Ohm
R0268 0613952J01 RES 10K Ohm
R0269 0613952H65 RES 470 Ohm
R0273 0613952J10 RES 24K Ohm
R0275 0613952J01 RES 10K Ohm
R0276 0613952J05 RES 15K Ohm
R0323 0613952J07 RES 18K Ohm
R0324 0613952J07 RES 18K Ohm
R0331 0613952J01 RES 10K Ohm
R0332 0613952J01 RES 10K Ohm
R0333 0613952J01 RES 10K Ohm
R0335 0613952J29 RES 150K Ohm
R0341 0613952J01 RES 10K Ohm
R0342 0613952H79 RES 1800 Ohm
R0343 0613952G67 RES 0 Ohm
R0344 0613952J19 RES 56K Ohm
R0345 0613952H90 RES 5100 Ohm
R0346 0613952J17 RES 47K Ohm
R0347 0613952J17 RES 47K Ohm
R0401 0613952H57 RES 220 Ohm
R0407 0613952Q25 RES 10 Ohm
R0408 0613952H49 RES 100 Ohm
R0409 0613952Q25 RES 10 Ohm
R0412 0613952G67 RES 0 Ohm
R0441 0613952G67 RES 0 Ohm
R0442 0613952H73 RES 1000 Ohm
R0467 0613952Q25 RES 10 Ohm
R0468 0613952J25 RES 100K Ohm
R0481 0613952G67 RES 0 Ohm
R0482 0613952G67 RES 0 Ohm
R0510 0613952H89 RES 4700 Ohm
R0511 0613952J25 RES 100K Ohm
R0512 0613952J05 RES 15K Ohm
R0525 0613952J25 RES 100K Ohm
R0529 0613952J17 RES 47K Ohm
R0530 0613952J09 RES 22K Ohm
R0531 0613952H67 RES 560 Ohm
R0533 0613952G67 RES 0 Ohm
R0535 0613952H73 RES 1000 Ohm
R0537 0613952H57 RES 220 Ohm
R0538 0613952H57 RES 220 Ohm
R0539 0613952H89 RES 4700 Ohm
R0541 0613952J11 RES 27K Ohm
R0543 0613952J25 RES 100K Ohm
R0555 0613952H49 RES 100 Ohm
Circuit
Ref
Motorola
Part No.
Description
R0556 0613952H49 RES 100 Ohm
R0591 0613952J10 RES 24K Ohm
R0592 0613952H25 RES 10 Ohm
R0593 0613952J25 RES 100K Ohm
R0611 0613952J19 RES 56K Ohm
R0612 0613952H89 RES 4700 Ohm
R0621 0613952J10 RES 24K Ohm
R0641 0613952J01 RES 10K Ohm
R0642 0613958D85 RES 7500 Ohm
R0643 0613958D09 RES 1200 Ohm
R0651 0613952H25 RES 10 Ohm
R0652 0613952H25 RES 10 Ohm
R0661 0613952H73 RES 1000 Ohm
R0662 0613952J29 RES 150K Ohm
R0671 0613952J12 RES 30K Ohm
R0672 0613952J01 RES 10K Ohm
R0681 0613952J07 RES 18K Ohm
R0682 0613952J21 RES 68K Ohm
U0101 5185143E03 68HC11FLO_PASS5 IC
U0111 5116648H01 128KBIT EEPROM
U0121 5115034H01 FLASH 4MBIT IC
U0122 5116096H01 32K X 8 SRAM 28PIN TSOP
U0141 5114000A14 DCDR/DEMUX 74HC138 IC
U0211 5114016A18 AMP_3403_ IC
U0221 5115062H01 ASFIC_CMP_R1 IC
U0251 5184704M60 CMOS 04M60 ANALOS IC
U0271 5102463J95 AUDIO PA TDA1519C
U0301 5116141H01 IC VOICE STORAGE 2 MIN
U0331 5186204B01 BUFFER/LINE DRIVER
U0341 5114005A01 LM2904DRM OP AMP
U0342 5166544A01 CMOS BILATERAL SW IC
U0351 5115012H01 LP2951CMM-3.3
REGULATOR
U0611 5164015H94 LM2941 REGULATOR
U0641 5164015H94 LM2941 REGULATOR
U0651 5114014A07 MC78M05BDTRK
REGULATOR
U0652 5114004A02 SENSING CIRCUIT IC
VR0151 4813977M11 DIODE MMBZ5232B_
VR0501 4813979C11 DIODE QUAD 20V
VR0503 4813979C11 DIODE QUAD 20V
VR0504 4813977M36 DIODE MMBZ5232B_
VR0505 4813979C11 DIODE QUAD 20V
VR0509 4813977M36 DIODE MMBZ5232B_
VR0510 4813977M36 DIODE MMBZ5232B_
VR0537 4813977M11 DIODE MMBZ5232B_
VR0541 4813977M23 DIODE MMBZ5232B_
VR0601 4813832C77 TRANSIENT SUPPRES-
SOR
Circuit
Ref
Motorola
Part No.
Description
VR0621 4813977M11 DIODE MMBZ5232B_
Y0131 4816169H01 CRYSTAL 38.4KHZ
Circuit
Ref
Motorola
Part No.
Description
