Motorola Pro3100 Detailed Service Manual

Section 9: 1-2 Technical Specifications
Section : 6881091C63-F
1.2 PRO Series Model Chart
2.0 Technical Specifications
Data is specified for +25°C unless otherwise stated.
PRO Series, UHF (403–470 MHz) 25–40 W Bipolar
Model Description
LAM25RKC9AA1AN PRO3100, 403–470 MHz, 25–40 W, 12.5/20/25 kHz Ch Sp
LAM25RKD9AA2AN PRO5100, 403–470 MHz, 25–40 W, 12.5/20/25 kHz Ch Sp
LAM25RKF9AA5AN PRO7100, 403–470 MHz, 25–40 W, 12.5/20/25 kHz Ch Sp
Item Description
X GCN6112 Control Head, PRO3100
X GCN6113 Control Head, PRO5100
X GCN6114 Control Head, PRO7100
XXX IMUE6024 Tanapa, UHF 403–470 MHz, 25–40 W, 12.5/20/25 kHz
XXX HAE4002 Antenna, 403–430 MHz, 1/4 Wave Roof Mount (Mini U)
XXX HAE4010 Antenna, 406–420 MHz, 3.5dB Gain Roof Mount (Mini U)
X 6881091C57 User Guide, PRO3100
X 6881091C58 User Guide, PRO5100
X 6881091C59 User Guide, PRO7100
NOTE
If you wish to replace a bipolar board, you must replace it with the LDMOS tanapa (same
item number). (See
Section 92, Section 1.0: UHF Band 1 (403–470 MHz) 25–40 W LDMOS
Model Charts.)
General Specifications
Channel Capacity
CDM750/PRO3100
CDM1250/PRO5100
CDM1550 Series/PRO7100
4
64
128
Power Supply 13.2 Vdc (10.8
– 15.6 Vdc)
Dimensions: H x W x D (in./mm)
CDM750/PRO3100
CDM1250/PRO5100 and
CDM1550 Series/PRO7100
Depth excludes knobs
25 – 40 W:
2.2 in. x 6.93 in. x 7.44 in. (56 mm x 176 mm x 189 mm)
2.34 in. x 7.05 in. x 7.8 in. (59 mm x 179 mm x 198 mm)
Add 0.35 in. (9mm) for Volume Knob
Weight (All CDM and PRO models) 3.5 lb. (1590 g)
Sealing: Withstands rain testing per
MIL STD 810 C/D/E and IP54
Shock and Vibration: Protection provided via impact
resistant housing exceeding MIL STD 810-C/D/E
Dust, Salt & Fog Protection provided via environment resistant housing
exceeding MIL STD 810 C/D/E
